GETINGE 88-SERIES
INSTALLATION MANUAL
502404200
SEV0647139-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 88 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Getinge 88 Series

Summary of Contents for Getinge 88 Series

  • Page 1 GETINGE 88-SERIES INSTALLATION MANUAL 502404200 SEV0647139-...

  • Page 2: Table Of Contents

    Contents FOREWORD ____________________________________________3 SAFETY REGULATIONS _________________________________4 Important _________________________________________________ 4 The machine must be assembled and installed: ________________ 4 When the work is complete, check that _______________________ 5 Product liability ____________________________________________ 5 Isolator switch _____________________________________________ 5 Attention symbols __________________________________________ 5 INSTALLATION __________________________________________6 Wall-mounted model ________________________________________ 7 Fitting AGS ________________________________________________ 7 Connecting electric power ___________________________________ 8...

  • Page 3: Foreword

    FOREWORD This instruction manual is intended for users of the Getinge washer disinfector 88-5. The instruction manual describes the design and operation of the machine and the main- tenance for which the user is responsible. The purpose of the information in the manual is to ensure safe operation and optimum efficiency.

  • Page 4: Safety Regulations

    Doing this puts at risk the safety and functioning of the machine. • The electrical cabinet may only be opened by authorized and trained personnel. • Spare parts may only be obtained from Getinge EDC. The machine must be assembled and installed: • by qualified personnel.

  • Page 5: When The Work Is Complete, Check That

    Incorrect use can result in damage to objects and personal injuries Product liability Any modification or incorrect use of the equipment without the approval of Getinge Disinfection AB invalidates Getinge Disinfection AB´s product liability. This product was manufactured by: GETINGE DISINFECTION AB Ljungadalsgatan 11, Box 1505 351 15 Växjö, Sweden...

  • Page 6: Installation

    INSTALLATION • The floor where the machine is to stand must be flat and level within ±5 mm. • Pull the machine (on a transport pallet) to the location where it will be installed. • Lift the machine off the pallet. •...

  • Page 7: Wall-Mounted Model

    Wall-mounted model • If the machine is to be mounted in a wall, the distance between machine and wall must be 15 mm. • If machines are to be installed next to each other they must be adjusted to the same height on installation.

  • Page 8: Connecting Electric Power

    Connecting electric power Installation may only be done by authorized personnel. Connect electric power to the machine as follows: • Connect the power supply to the electrical connections of the machine; see the dia- gram with alternative connection arrangements. • For easier servicing and maintenance, the supply to the machine should be fitted with a lockable isolator with a 3 mm break gap.
  • Page 9 It is important that the connection has the correct overcurrent protection. The correct fuse rating is stated on the type plate. The main switch on the front of the machine disconnects the power to all components connected to the machine that are connected after the main switch of the machine. Cables for signal exchange may also be connected to the machine.
  • Page 10 Electrically-heated chamber and electrically-heated dryer 3+PE 50/60 3N+PE 50/60 3N+PE 50/60 Steam-heated chamber and electrically-heated dryer 3+PE 50/60 3+PE 50/60 3+PE 50/60 3+PE 50/60 3+PE 50/60 3N+PE 50/60 3N+PE 50/60 00-40 V, +PE 50/0 Hz 80-415V, N+PE 50/0 Hz -X01 -X01 Supply cable Supply cable...

  • Page 11: Connecting Water, Steam, Waste And Dryer

    Connecting water, steam, waste and dryer Installation may only be done by authorized personnel. • Provide water and, if required, steam connections with separate stopcocks. Flush out the water and steam pipes that are to be connected to the machine, to prevent clogging of filters and valves.
  • Page 12 Floor connection J05b Figure 5. Connections Cold water 450 mm above the floor Hot water 450 mm above the floor Distilled/de-ionized water 450 mm from floor Dryer exhaust air at roof Electrical connection 370 mm from floor S. Steam connection 60 mm above the floor C.
  • Page 13 Ceiling connection Figure 6. Connections Cold water 1905 mm above the floor Hot water 1905 mm above the floor Distilled/de-ionized water 1905 mm from floor Dryer exhaust air at roof Electrical connection 350 mm from floor S. Steam connection 1830 mm above the floor C.

  • Page 14: Model Identification

    Connect the waste as shown in Figure 5. Diameter of waste: 50 mm (2”). • Where the washer disinfector is installed against a wall, or where two machines are positioned next to each other, Getinge recommends leaving a 500 mm service area. J0b Figure 7. Connecting a dryer •...

  • Page 15: Function Check

    Function check • Check that the machine is connected to the correct voltage and the waste, water, steam and condensate connections are correctly connected. Open the valves for water and steam. • Fill the detergent and rinse aid containers and place alarm sensors in the containers. •...

  • Page 16: Technical Data

    TECHNICAL DATA Dimensions Outside dimensions Width 1270 mm Depth 990 mm Height 1870 mm Chamber, effective dimension Chamber depth 800 mm Chamber width 665 mm Chamber height 667 mm Chamber volume 340 litres Material EN1.4404, ASTM 316L Weight including water and load. Total 600 kg Loading per machine foot...
  • Page 17 Compressed air (option with loader/unloader only) Connection pressure 400-800 kPa Steam (only for a machine with steam-heated chamber) Connection ISO G-1/2 Pressure 300-500kPa Notes 3, 4. Max steam temperature 160 °C (320 °F) Consumption about 1.5 kg/min at 300 kPa Steam (only for a machine with steam-heated chamber) Connection ISO G-1/2 Note 4.
  • Page 18 Environmental requirements Air humidity max 80% at 31 °C (87 °F) Room temperature 5-40 °C (41-104 °F) Heat dissipation to the room Max 6000 W hot air during drying. Max 1500 W during disinfection at 90 °C (194 °F) Max external temperature of the machine 50 °C (123 °F) Sound level Table 1 below shows the sound power level as linear octave band values and as co-weighted, A- weighted sound power level, both equivalent L...
  • Page 19 Other points Circulation system Design pressure: 300 kPa Working pressure: max 130 kPa Design temperature 100°C (100.00°C) Working temperature 93°C (92.78°C) Material: EN1.4404, ASTM 316L Waste tank Type of vessel: not closed Material: polypropylene Volume 50 litres (13.21 gallons) Max temp 95 °C (203 °F) Process tank Type of vessel: not closed Material: polypropylene...

  • Page 20: Water Quality - Washer Disinfectors

    High concentrations of and high exposure to sanitary chemicals may cause corrosion and pitting on stainless steel. Getinge Disinfection AB therefore recommends that water used in the pre-rinsing, washing and final rinsing phases should be of drinkable quality in accordance with the guidelines.
  • Page 21 Page 1 of 4...
  • Page 22 Page  of 4...
  • Page 23 Page  of 4...
  • Page 24 Australia France South Africa Getinge Australia Pty Ltd Getinge France SAS Getinge South Africa (Pty) Ltd 154 Lytton Road BP 4, avenue du Canada P O Box 484 Bulimba Qld 4171 ZA de Courtaboeuf Hercules info@getinge.com.au Les Ulis, FR-14 Pretoria SA 000 getinge.france@getinge.fr...
