Step #3
Each diagram/step may not applicable to your product configuration.
Insert a motion arm or fixed arm into a stem arm.
motion arm
F
fixed arm
1. Rotation tension adjustment
2. Secure arms
2mm Allen key
(included)
14

Attach arms

Step 1
Insert motion arm or fixed arm
to stem arm.
Step 2
Secure the screw using the
2mm Allen key.
