Desk clamp assembly
Step 1
Adhere the adhesive pad
underneath the base to protect
the worksurface.
Step 2 (optional)
Adjust clamp positioning
to accommodate a thicker
worksurface.
Step 3
Slide onto worksurface
to desired position.
Step 4
Twist to tighten the desk clamp
on the worksurface.
For worksurface 0.66"- 2.2"
Optional adjustment
for thicker worksurfaces
1.38"-2.99"
Step 2A
Remove the clamping
component from the
upper position with the
4mm Allen key.
Step 2B
Replace the clamping component
in the lower position and secure
with the 4mm Allen key.
11
