Read before using! Read and follow all instructions and warnings before use. Save these instructions for future reference. • Use this product only in the manner intended by the manufacturer. If you have questions, contact the manufacturer. • This product contains small items that could be a choking hazard if swallowed. Keep away from children. • Make sure the desk or mounting surface can support the combined weight of the mount and the screens. • Do not extend monitors behind the base. • Never exceed the maximum load capacity. • Minimum load capacity must be reached for each motion arm. • Load capacity may vary depending on the type of installed monitor or accessory. • There can be no more than two monitor arms in a monitor arm assembly. • The motion arm is always the final arm in a monitor arm assembly; there can be no fixed arms after a motion arm is used. • Hand tighten screws only. Do not use power tools. • When connecting and routing monitor cables and power cords, make sure the cables and cords are long enough to accommodate the full range of motion of the monitor arms. • Check joint parts every two months to make sure the screws have not loosened. • This product is only compatible with Fellowes Edge monitor arm accessories. • This product is intended for indoor use only. Page 2...
Edge2 Components and tools PLEASE REVIEW these instructions before beginning the assembly and adjustment procedures. Check that all the parts and tools listed below were provided with your order. Contact your supplier if any materials are missing. Do not discard the packaging until satisfied that the product operates to y our satisfaction. Components and tools monitor arm assembly ( ) optional grommet mounting monitor arm assembly ( ) optional grommet mounting grommet bolt ( ) grommet bolt ( ) grommet mount plate ( ) grommet mount plate ( ) base assembly ( ) base assembly ( )
Page 4
Edge2 Clamp mount Two Base Assembly Attachment Methods • Clamp method. The base assembly is clamped to • Grommet method. The base assembly is secured through a a table or desk surface that is between 0.6" (15mm) thick grommet hole in the work surface, with a diameter between and 3" (76mm) thick. See below. 0.78" (20mm) and 2" (51mm). Surface thickness must be between 0.6" (15mm) and 1.4" (36mm). See page 5. clamp grommet clamp method grommet method method method Clamp Method The base assembly is shipped with the bottom clamp in the “upper attachment position.” To change to the lower attachment position” for thicker work surface, follow this procedure (see illustrations): • Use the 4mm Allen key to remove the two screws holding the bottom clamp in position. • Reattach the bottom clamp to the lower two holes. Tighten the screws securely using the Allen wrench. CAUTION: Do not use a power drill. Clamp screws are rated at 102 in-lbs. upper attachment lower attachment to change: ) remove ) re-install screws with position (standard)
Page 5
Edge2 Grommet mount Grommet Method This method can be used for work surfaces that have a grommet hole in an appropriate position. Surface thickness must be between 0.6" (15mm) and 1.4" (36mm), and the grommet hole diameter must be between 0.78" (20mm) . " – . " and 2" (51mm). ( mm – Remove Clamp Assembly • Remove the standard clamp assembly from the base assembly. Use the 4mm Allen key to remove the three screws holding the clamp assembly in position. Retain the three screws. Attach Grommet Assembly remove attach • Place the grommet bolt in the large center hole on the clamp grommet grommet mount plate. assembly assembly • With the grommet bolt in position, fasten the grommet mount plate and bolt to the monitor arm base with the three screws previously removed. As before, use the 4mm Allen key.
Page 6
Edge2 Assembly Install Monitor Arm Assemblies Install Monitors • Insert the monitor arms into the base assembly. • Remove the VESA plate from each VESA mount by pressing down on the plastic tab to release the lock. Pull the plate upward to • Secure each monitor arm by tightening the set screws remove. using the 2mm Allen key. Adjust the tightness to allow for the desired ease of monitor arm rotation. VESA plate tighten set screw . " VESA plate screw VESA plate • Place each of the LCD monitors face down on a flat surface. Align the VESA plate holes with the holes on the back of the monitor. Attach the VESA plates using the eight VESA plate screws provided (four screws per monitor). " —There are two sets of four holes on each VESA plate. One set has holes 3.9" (100mm) apart, the other set has holes 3" (75mm) apart. Use the set that matches the holes on the monitor. monitor (face down) •...
Edge2 Cable management, adjustments and storage Cable Management Use the cable clip and cable cover to help manage the monitor cables. motion • Pinch the cable clip to remove it from the motion arm, and again when re-installing it with the cables captured. fixed • Slide the cable cover out from the fixed arm. Slide it back in with the cables cable captured. clip cable cover 180° Lock-Out Feature • Use the 2mm Allen key to secure the 180° locking screws into the base of each monitor arm assembly to limit the fixed monitor arm rotation to 180°. Fully tighten the screws, then back out one full turn. ° locking screws Tension Adjustments There are five possible swivel and tilt tension adjustments for each of the two monitor arms: 1. Monitor swivel adjustment —Use the 2mm Allen key to adjust the set screw for the desired ease of monitor rotation. tension 2.
