- Page 1 Evolve ™ monitor arm series UNIVERSAL INSTALLATION INSTRUCTIONS...
- Page 2 • Check joint parts every two months to make sure the screws have not loosened. • This product is only compatible with Fellowes Evolve monitor arm accessories. • This product is intended for indoor use only.
-
Page 3: Components And Tools
Evolve Components and tools Please review these instructions before beginning the installation. Check that all the components needed for installation were provided with your order. Refer to the illustrations for component identification and the table for component quantity for the model you are installing. Contact your supplier if any parts are missing. Do not discard the packaging until the product works to your satisfaction. -
Page 4: Configuration Pages
Evolve2-FM Evolve2-FMS Evolve3-FMS Evolve4-FM BUILD 1ST BUILD 2ND Evolve4-FMS Completes Evolve1-F assembly Completes Evolve2-F assembly Evolve6-FMS Completes Evolve2-FS Evolve-Stubby assembly Assembly steps The assembly steps beginning on page 10 show the details of component assembly and also cover intermediate steps. -
Page 5: Component Assembly
6. Attach VESA plate to back of monitor. 7. Attach displays using the quick release feature. BUILD 1ST BUILD 2ND 8. Adjust tension on VESA or slider. Completes Evolve1-F assembly Completes Evolve2-F assembly Completes Evolve2-FS Evolve1-M Evolve2-MS assembly... - Page 6 Evolve Configurations Evolve1-FF Evolve4-FF Evolve2-FF Evolve6-FF Evolve3-FF Evolve1-FF Evolve4-FF Evolve2-FF Evolve6-FF Evolve3-FF Completes Evolve3-FF assembly Component assembly BUILD 3RD VESA 1. Secure pole mount to worksurface. reducer reducer bushing bushing reducer 2. Slide stem arm over pole and secure in place with the bushing 5mm Allen key.
- Page 7 Evolve Configurations and pole mount Evolve1-FM Evolve4-FM Evolve2-FM Evolve4-FMS Evolve2-FMS Evolve6-FMS Evolve3-FMS Evolve1-FM Evolve3-FMS Evolve4-FMS Evolve2-FM Evolve4-FM Evolve6-FMS Evolve2-FMS Completes Evolve3-FMS assembly Component assembly 1. Secure pole mount to worksurface. BUILD 3RD 2. Slide stem arm over pole and secure in place with the small small VESA...
- Page 8 Evolve Assembly (desk clamp) For worksurface 0.66”- 2.2” Optional adjustment Step 1 for thicker worksurfaces Adhere the adhesive pad 1.38”-2.99” underneath the base to protect the worksurface. Step 2 (optional) Adjust clamp positioning to accommodate a thicker worksurface. Step 3 Slide onto worksurface to desired position.
- Page 9 Evolve Assembly (grommet mount) For worksurface up to 1.5” Step 1 Step 2 Remove the 3 screws with Insert the large screw to the 4mm Allen key. the grommet plate and reattach the 3 screws with the 4mm Allen key. 4mm Allen key (Included) Step 3 Step 4 Adhere the adhesive pad...
-
Page 10: Single Display Configuration
Evolve Stem arm Each diagram/step may not applicable to your product configuration. Single display configuration Step 1 Slide stem arm over pole and secure with the 5mm Allen key. 5mm Allen key (Included) Dual display configuration Step 2 Reverse the second stem arm over pole as shown NOTE and secure with the... - Page 11 Evolve Attach arms Each diagram/step may not applicable to your product configuration. Insert a motion arm or fixed arm into a stem arm. motion arm Step 1 Insert motion arm or fixed arm to stem arm. Step 2 Secure the screw using the 2mm Allen key.
- Page 12 Evolve Assembly Insert VESA to a stem arm. Step 1 Step 2 Step 3 Attach reducer bushing onto VESA Insert VESA mount to arm stem. Secure the screw using the mount. For detailed instructions on 2mm Allen key. how to attach the reducer bushing please reference the slider mount instructions.
- Page 13 Evolve Attach display VESA plate is pre-drilled to accommodate varying monitor standards. Step 1 100mm Pull the tab to release the quick release VESA plate. Two options of pre-drilled Step 2 holes to accommodate Pull the quick release VESA varying monitor standards plate upward to detach.
- Page 14 Evolve Adjust tension Adjusting the tension on your motion arm allows for smooth adjustments. Tension adjustment supports monitors weighing 6.6 - 17.6 lbs. Adjust motion arm tension Step 1 Use the 5mm Allen key to adjust the tension to correspond to the weight of the monitor.
-
Page 15: Lock Features
Evolve Lock features Optional features 180° lock monitor arm The 180 lock-out feature allows º rotation towards the user, but º prevents 90 rotation away from the º user. Step 1 Fasten the screw with the 2mm Allen key on the arm stem and then move the Allen key backward one circle motion to limit arm rotation. - Page 16 Evolve Lock features If desired, the slider mount can be Lock slider plate secured to prevent the slider function. This will lock a monitor in position. lock screw lock screw Prevent VESA mount quick release Step 1 To prevent the quick release function, insert the screw to the back of the VESA mount.
-
Page 17: Cable Management
Evolve Cable management Optional features Step 1 Slide cable tray outward to detach from fixed arm. Step 2 Route cables through fixed arm tray and reattach. pole clips Step 1 Step 1 Detach pole clip Squeeze clip then pull to and route cables. -
Page 18: Additional Features
Evolve Additional features Allen key storage Once assembly is complete, place the Allen keys in the slots located on the back side of the VESA and slider mounts. Insert the two smaller Allen keys simultaneously. Page 18... - Page 20 To contact a Fellowes service representative, call 1-800-833-3746 © 2022 Fellowes, Inc. | Part #412822 ® Warranty information can be found by contacting customer service, your sales representative or by visiting www.fellowes.com...
