  • Page 3 Single Vertical Saw SVS Safety, Operation, Maintenance Manual SVSE11S rev.A6.05 SVSE15S rev.A6.05 Safety is our #1 concern! Read and understand all safety information and instructions before operating, setting up or maintaining this machine. This is the original language for the manual.

  • Page 4: Table Of Contents

    Table of Contents Section-Page SECTION 1 SAFETY Safety Symbols..................1-1 Safety Instructions ..................1-2 Observe Safety Instructions Wear Safety Clothing Keep the Machine And Area Around Clean Dispose Of Sawing By-Products Properly Check the Machine Before Operation Keep Persons Away Keep Hands Away Use Proper Maintenance Procedures Keep Safety Labels In Good Condition FIRE-FIGHTING...
  • Page 5 Table of Contents Section-Page SECTION 4 ALIGNMENT Alignment Procedure................4-1 Blade Installation And Tracking Blade Wheel Alignment Saw Head Tilt Adjustment The saw head blade should be perpendicular to the table. Aligning the Blade Guides Blade Deflection Blade Guide Horizontal Tilt Adjustment Blade Guide Spacing Blade Guide Vertically Tilt Adjustment SECTION 5...

  • Page 6: Safety

    SAFETY Safety Symbols SECTION 1 SAFETY Safety Symbols The following symbols and signal words call your attention to instructions concerning your personal safety. Be sure to observe and follow these instructions. indicates an imminently hazardous situation which, if not DANGER! avoided, will result in death or serious injury.

  • Page 7: Safety Instructions

    It is always the owner's responsibility to comply with all IMPORTANT! applicable national and local laws, rules and regulations regarding the ownership and operation of your Wood-Mizer TVS/SVS saw. All Wood-Mizer TVS/SVS owners are encouraged to become thoroughly familiar with these applicable laws and comply with them fully while using the machine.

  • Page 8: Wear Safety Clothing

    SAFETY Wear Safety Clothing Wear Safety Clothing Secure all loose clothing and jewelry before operating the WARNING! machine. Failure to do so may result in serious injury or death. Always wear gloves and eye protection when handling WARNING! bandsaw blades. Changing blades is safest when done by one person! Keep all other persons away from area when coiling, carrying or changing a blade.

  • Page 9: Check The Machine Before Operation

    SAFETY Check the Machine Before Operation Check the Machine Before Operation Make sure all guards and covers are in place and secured DANGER! before operating the machine. Failure to do so may result in serious injury. Fasten the machine to the floor before operating. WARNING! The machine’s operator should get training in operation IMPORTANT!

  • Page 10: Keep Hands Away

    SAFETY Keep Hands Away Keep Hands Away Always shut off the blade motor before changing the blade. DANGER! Failure to do so will result in serious injury. Motor components can become very hot during operation. DANGER! Avoid contact with any part of a hot motor. Contact with hot motor components can cause serious burns.

  • Page 11: Keep Safety Labels In Good Condition

    SAFETY Keep Safety Labels In Good Condition Consider all electrical circuits energized and dangerous. WARNING! Disconnect and lock out power supply before servicing! WARNING! Failure to do so may result in serious injury. Never assume or take the word of another person that the WARNING! power is off;...

  • Page 12: Fire-Fighting

    SAFETY FIRE-FIGHTING Fire-Fighting The machine’s work-stand should be equipped with a 4 kg CAUTION! / 8.818 lb or bigger dry powder extinguisher. Safety Labels Description See Table 1-1. Pictogram decals used to warn and inform the user about danger in the saw. TABLE 1-1 Decals View Decal No.
  • Page 13 SAFETY Safety Labels Description TABLE 1-1 099221 Keep all persons at a safe distance from work area when operating the machine. 099221 096314 Keep all persons at a safe distance from work area when operating the machine. 096316 Opening of the electric box is possible only when the switch is in the ”0”...
  • Page 14 SAFETY Safety Labels Description TABLE 1-1 096319 Always disconnect the power cord before opening the electric box. 098177 Always disconnect the power cord before performing any service. 098177 099540 CAUTION! Gear train - Keep a safe distance! 099540 MHdoc022715 Safety...
  • Page 15 SAFETY Safety Labels Description TABLE 1-1 101176 CAUTION! Compressed air in the system even after electric power disconnection. 101176 096321 Blade movement direction 500031 CAUTION! Do not adjust the turnbuckles! S12004G Always wear eye protection equipment when operating this machine. Safety MHdoc022715 1-10...
  • Page 16 SAFETY Safety Labels Description TABLE 1-1 S12005G Always wear ear protection equipment when operating this machine. 501465 CAUTION! Always wear safety boots when operating this machine. 501467 Lubrication point P11789 Blade alignment. Turn right to move the blade out on the wheel; turn left to move the blade in on the wheel.
  • Page 17 SAFETY Safety Labels Description TABLE 1-1 P85070 CE sign S20097 Motor rotation direction S20097 099504 Visible and/or invisible laser radiation. Avoid eye or skin exposure to direct or scattered radiation. 099504 505346 Tensioner Valve Handle Placement, TVS TVS 505346 505347 Tensioner Valve Handle Placement, SVS SVS 505347 505348...

  • Page 18: Operation

    General Information Thank you for choosing Wood-Mizer wood processing equipment! Wood-Mizer is committed to providing you with the latest technology, best quality and strongest customer service available on the market today. We continually evaluate our customers’ needs to ensure we’re meeting current wood-processing demands.

  • Page 19: If You Need To Order Parts

    From Europe call your local distributor or our European Headquarters and Manufacturing Facility in Kolo - Poland, Nagórna 114 St at +48-63-2626000. Please have the machine identification number and your customer number ready when you call. Wood-Mizer will accept these methods of payment: Visa, Mastercard, or Discover ...

  • Page 20: If You Need Service

    OPERATION If You Need Service: If You Need Service: From Europe call your local distributor or our European Headquarters and Manufacturing Facility in Kolo - Poland, Nagórna 114 St at +48-63-2626000. Ask to speak with a Customer Service Representative. Please have your machine identification number and your customer number ready when you call.

  • Page 21: Control Overview

    OPERATION Control Overview Control Overview 1. Control Panel See Figure 2-2. The control panel includes switches to start and stop the feed track and the saw heads. STOP START STOP FIG. 2-2 CONTROL PANEL COMPONENTS 2. Blade Drive To start the blade motor, turn the key switch to the position.
  • Page 22 OPERATION Control Overview 4. Feed Track Speed Adjustment The feed track speed switch controls the speed at which the feed track moves. Turn the switch right to increase the speed, turn left to reduce the speed. 5. Key Switch The key switch has three positions: “0”...

  • Page 23: Svs Setup

    OPERATION SVS Setup SVS Setup Before starting to use the machine you have IMPORTANT! to meet the following conditions: Set up the machine on firm and level ground. The machine must be fastened to  the floor. Failure to do so may cause the sawhead to tip, resulting in serious injury or death.
  • Page 24 OPERATION SVS Setup Standard). The power supply must meet the specifications given in the table below. SVS Model 3-Phase Fuse Suggested Wire Size Volts Disconnect 25 Amps SVSEH11 400 VAC 11 AWG / 4 mm , up to (7,5kW main 15 m/ 49 ft long motor) 32 Amps...
  • Page 25 OPERATION SVS Setup pockets shown on the picture below. svs_004_1 099855_manual_ver A.1 099855 ver E.1 FIG. 2-2 Machine Operation MHdoc022715...

  • Page 26: Replacing The Blades

    OPERATION Replacing The Blades Replacing The Blades Always shut off the machine motors before DANGER! changing the blades. Failure to do so may result in serious injury. Always wear gloves and eye protection WARNING! whenever handling bandsaw blades. Changing blades is safest when done by one person! Keep all other persons away from work area when changing blades.

  • Page 27: Tensioning The Blade

    OPERATION Tensioning The Blade Position 1 1/4” (31.75 mm) wide blades on the wheels so the gullet is 3.0 mm (0.12”) (± 1.0 mm / (0.04”)) out from the front edge of the wheel. Close the blade housing cover. Next, tension the blade as described in the following instructions. Tensioning The Blade The machine is equipped with a pressure IMPORTANT!
  • Page 28 OPERATION Tensioning The Blade tension to change. To release the blade tension set the tensioner valve to “0” position. Cant Control Blade Tension 505348 Type Indicator F[mm] E[mm] 1,07 830-850 57-59 1,14 745-765 51-53 1,07 2735 805-825 55-57 1,27 715-735 49-51 1,40 Tensioner Handle...

  • Page 29: Tracking The Blade

    OPERATION Tracking The Blade Tracking The Blade 1. Open the blade housing cover of each saw head. 2. Turn the key switch to the ”H” position. 3. Manually spin one of the blade wheels until the blade positions itself on the blade wheels. 4.

  • Page 30: Machine Start

    OPERATION Machine Start Make sure all guards and covers are in place CAUTION! and secured before operating or towing the machine. Failure to do so may result in serious injury. Be sure the blade housing cover is in place and secured. NOTE: After aligning the blade on the wheels, always check the blade guide spacing and location.
  • Page 31 OPERATION Machine Start STOP START STOP FIG. 2-5 To stop the blade motor, push the Blade Stop button shown in the figure above. The blade motor also may be stopped by pushing either of the emergency stop buttons. If either of the emergency switch has been used to stop the blade motor, rotate the switch clockwise before restarting the saw head.
  • Page 32 OPERATION Machine Start See Figure 2-6. After the saw head has been successfully started, the feed track can be started. To start the track chain motor, turn the Track Start switch (shown in Figure 2-6) left to start the track forward, turn the switch right to start the track backward. Press the STOP button to stop the track.

  • Page 33: Cutting Position Setting

    OPERATION Cutting Position Setting hard will require slower feed rates. Sharpness of blades. Dull or improperly sharpened blades will require slower feed  rates than sharp and properly maintained blades. Off-bearing capability. Your ability to feed will also determine what feed rate you can ...
  • Page 34 OPERATION Cutting Position Setting See Figure 2-7. svs_010_B Laser beam Indicates the cut position FIG. 2-7 2-17 MHdoc022715 Machine Operation...

  • Page 35: The Lubemizer System

    OPERATION The LubeMizer System The LubeMizer System Lube Mizer system is used to lubricate the blade during sawing. The LubeMizer applies lubricant on both sides of the blade as you are sawing to reduce resin buildup on the blade. The LubeMizer controls allow you to adjust the volume of lubricant for various wood types.

  • Page 36: Lube Additives

    Lube Additives Lube Additives For further benefits, add one 12oz. ( 0.35 L) bottle of Wood-Mizer Lube Additive to a 5 gallon (18.9 L) jug of water. Wood-Mizer Lube Additive enables some previously impossi- ble timbers to be cut by significantly reducing resin buildup on the blade. It helps to reduce heat buildup, wavy cuts, and blade noise.

  • Page 37: 2.10 Operation Procedure

    OPERATION Operation Procedure 2.10 Operation Procedure 1. Install a blade if necessary. Always wear gloves and eye protection when WARNING! handling bandsaw blades. Changing blades is safest when done by one person! Keep all other persons away from area when coiling, carrying or changing a blade. Failure to do so may result in serious injury.
  • Page 38 OPERATION Operation Procedure Always be aware of and take proper protective DANGER! measures against rotating shafts, pulleys, fans, etc. Always stay a safe distance from rotating members and make sure that loose clothing or long hair does not engage rotating members resulting in possible injury.

  • Page 39: Maintenance

    MAINTENANCE Wear Life SECTION 3 MAINTENANCE This section lists the maintenance procedures that need to be performed. This symbol identifies the interval (hours of operation) at which each maintenance procedure should be performed. Be sure to refer to the motor manual for maintenance procedures concerning the blade motor.

  • Page 40: Blade Guides

    MAINTENANCE Blade Guides Blade Guides 1. Check the rollers for performance and wear every blade change. Make sure the rollers are clean and spinning freely. If not, rebuild them. Replace any rollers which have worn smooth or have become cone shaped. See the Parts manual for blade guide rebuild kits and complete roller assemblies.

  • Page 41: Miscellaneous Lubrication

    MAINTENANCE Miscellaneous Lubrication Miscellaneous Lubrication 1. Using the grease nipples, lubricate chain drive bearings the infeed and outfeed tables bearings, with a lithium grease every 200 hours of operation or once a month. Never apply grease to the feed track chain. CAUTION! It causes sawdust buildup in chain links.

  • Page 42: Blade Tensioner

    MAINTENANCE Blade Tensioner Blade Tensioner 1. Grease the screw on the blade tensioner shaft with a lithium grease every fifty hours of operation, but at least once a week. See Figure 3-5. FIG. 3-6 Belts 1. Check the blade wheel belts for wear every 50 hours of operation. Replace as needed. 2.

  • Page 43: Drive Belt Adjustment

    MAINTENANCE Drive Belt Adjustment Drive Belt Adjustment Do not for any reason adjust the drive belt with WARNING! the motor running. Doing so may result in serious injury. See Table 3-2. Check the drive belt tension after the first 20 hours, and every 50 hours thereafter.
  • Page 44 MAINTENANCE Drive Belt Adjustment Next tighten the lock nuts. NOTE: Be sure to adjust the bolts evenly so the motor remains in alignment. 3. Tighten the four motor mounting bolts. Adjustment Bolts Mounting Bolts FIG. 3-8 Periodically check the belt for wear. Replace if damaged or worn. MHdoc022715...
  • Page 45 MAINTENANCE Drive Belt Adjustment See Figure 3-9. Keep the motor and drive pulleys aligned to prevent premature belt wear. To align the motor pulley to the drive pulley, loosen the mounting bolts on the motor plate and slide the motor plate in or out until it is in line with the drive pulley. After performing the alignment, make sure the drive belt tension has not been changed.

  • Page 46: Feed Chains Tension

    MAINTENANCE Feed Chains Tension Feed Chains Tension If necessary, use the adjustment bolts shown below to adjust the feed chains tension. The chains should lay freely on the upper bars. Do not over-tension the chains. Over-tensioning CAUTION! may lead to early failure of the gear, bearings, rollers and chains.
  • Page 47 MAINTENANCE Feed Chains Tension See Figure 3-13. Chain tension adjustment bolts placement. Chains Tension Adjustment Bolts FIG. 3-14 MHdoc022715...
  • Page 48 MAINTENANCE Feed Chains Tension Short Feed Chains Long Feed Chains Drive Chain FIG. 3-15 3-10 MHdoc022715...
  • Page 49 MAINTENANCE Feed Chains Tension 2. First, tension four long feed chains using appriopriate adjustment bolts. Chains Tension Adjustment Bolts 30-40mm / (1.18" - 1.57") FIG. 3-16 MHdoc022715 3-11...
  • Page 50 MAINTENANCE Feed Chains Tension 3. Next, tension two short feed chains using appriopriate adjustment bolts. FIG. 3-17 4. Finally, tension the drive chain. Drive Chain Ten- sion Adjustment Bolt FIG. 3-18 3-12 MHdoc022715...
  • Page 51 MAINTENANCE Feed Chains Tension 5. If the chain or chains are worn, replace it with the new ones. To do this first dismount the fence. See Figure 3-19. Unscrew the four bolts and remove the fence. svs_031_A FIG. 3-20 6. Remove the drive chain cover. MHdoc022715 3-13...
  • Page 52 MAINTENANCE Feed Chains Tension See Figure 3-21. svs_032_A FIG. 3-22 7. Replace the worn chain or chains. Route the new chains as shown on Figure 3-15 3-14 MHdoc022715...

  • Page 53: Lube Mizer System

    MAINTENANCE Lube Mizer System Lube Mizer System 1. Clean the lube filter as needed. To clean, Make sure the lube control is in the OFF position and the lube bottle valve is closed  all the way. Unscrew the filter reservoir and flush with water. ...

  • Page 54: 3.10 Safety Devices Inspection

    MAINTENANCE Safety Devices Inspection 3.10 Safety Devices Inspection SVS Safety Devices Inspection Before beginning a shift, the following safety devices should always be checked: E-STOP button circuit - control box  E-STOP button circuit - table  Safety switch circuit - control box arm ...
  • Page 55 MAINTENANCE Safety Devices Inspection 3. Safety Switch Circuit Inspection - Control Box Arm Start the main motor;  Open the control box arm;  The main motor should stop;  Try to start the motor using the START button. The motor cannot be started; ...
  • Page 56 MAINTENANCE Safety Devices Inspection The estimated life of the START/STOP button CAUTION! and the key switch (marked on the pictures below) is about 15 years. These components must be replaced after 15 years from the production date. See Figure 3-25. STOP START STOP...

  • Page 57: Alignment Procedure

    ALIGNMENT Alignment Procedure SECTION 4 ALIGNMENT The Wood-Mizer resaw is factory aligned. Be scrupulous when performing all alignment steps as resaw alignment determines the accuracy of your cuts. The alignment procedure should be performed approximately every 1500 hours of operation.
  • Page 58 ALIGNMENT Blade Installation And Tracking 2. Open the blade housing covers. 3. Manually spin one of the blade wheels until the blade positions itself on the wheels. See Figure 4-2. The blade wheels should be adjusted so that the gullet of 1 1/4" blades rides 3.0 mm (0.12") out from the front edge of the wheels (±...

  • Page 59: Blade Wheel Alignment

    ALIGNMENT Blade Wheel Alignment 4.1.2 Blade Wheel Alignment The blade wheels should be adjusted so they are level in the vertical and horizontal planes. If the blade wheels are tilted vertically, the blade will want to move in the tilted direction.
  • Page 60 ALIGNMENT Blade Wheel Alignment See Figure 4-4. Alignment Plate Lower Side FIG. 4-4 3. Measure the distance from the edge of the tool clipped to the blade near the chains, to the plate surface. The distances marked A and B must be equal. If the measurements are different, use the drive side blade wheel adjustement bolts to correct its alignment.
  • Page 61 ALIGNMENT Blade Wheel Alignment See Figure 4-5. Alignment Plate LTBGAT Alignment Tool Blade FIG. 4-5 MHdoc022715...
  • Page 62 ALIGNMENT Blade Wheel Alignment See Figure 4-6. Loosen the lock nuts on the horizontal plane adjustment bolt. Next, use the vertical plane adjustment bolts to adjust the drive wheel so that the adjustment tool would be parallel to the alignment plate. Horizontal Plane Adjustment Bolt Vertical Plane...
  • Page 63 ALIGNMENT Blade Wheel Alignment See Figure 4-7. Loosen the lock nuts on the horizontal plane adjustment bolt. Next, use the vertical plane adjustment bolts to adjust the idle wheel so that the adjustment tool would be parallel to the alignment plate. Horizontal Plane Adjustment Bolt Vertical Plane...
  • Page 64 ALIGNMENT Blade Wheel Alignment See Figure 4-8. The vertical tilt of the blade wheel should be adjusted so that the gullet of 1-1/4" blade is 3.0 mm out from the front edge of the wheel (± 1.0 mm). 150060 3.0 mm (0.12”) ±...
  • Page 65 ALIGNMENT Blade Wheel Alignment 6. Check the position of the blade on the drive-side blade wheel. The blade should be positioned on the wheel as described for the idle-side blade wheel. Adjust the drive-side blade wheel if necessary. See Figure 4-10. Use the cant control adjustment bolt to adjust the drive-side blade wheel.

  • Page 66: Saw Head Tilt Adjustment

    ALIGNMENT Saw Head Tilt Adjustment 4.1.3 Saw Head Tilt Adjustment The saw head blade should be perpendicular to the table. 1. Make sure the rollers do not touch the blade. Using the adjustment bolt adjust the saw head tilt to that moment when the blade is set perpendicularly to the table (check perpendicularity with a square).

  • Page 67: Aligning The Blade Guides

    Aligning the Blade Guides 4.1.4 Aligning the Blade Guides Each Wood-Mizer resaw has two blade guide assemblies that help the blade maintain a straight cut. The two blade guide assemblies are positioned on the cutting head to guide the blade on each side of the material being cut.

  • Page 68: Blade Guide Horizontal Tilt Adjustment

    ALIGNMENT Blade Guide Horizontal Tilt Adjustment See Figure 4-11. Adjustment Plate Loosen jam nuts and turn screws to adjust roller up or down Blade FIG. 4-11 4. Loosen the jam nut and tighten the appropriate screw until the blade guide deflects the blade 6.0 mm.
  • Page 69 ALIGNMENT Blade Guide Horizontal Tilt Adjustment See Figure 4-12. Clip tool to blade FIG. 4-12 Check that the blade guide does not tilt the blade left or right. A Blade Guide Alignment Tool (LTBGAT) is provided to help you measure the vertical tilt of the blade. 2.
  • Page 70 ALIGNMENT Blade Guide Horizontal Tilt Adjustment See Figure 4-13. LTBGAT FIG. 4-13 4. The two distances should be equal. If the distances A and B differ, adjust the horizontal tilt of the blade guide using the adjustment screws shown in the figure below. See Figure 4-14.
  • Page 71 ALIGNMENT Blade Guide Horizontal Tilt Adjustment 5. Attach the tool to the blade near the lower blade guide mount blocks and repeat above steps. Adjust the horizontal tilt of this guide if necessary. NOTE: Be sure that the A and A’ distances and B and B’ distances are equal.

  • Page 72: Blade Guide Spacing

    ALIGNMENT Blade Guide Spacing 4.1.7 Blade Guide Spacing HINT: When adjusting blade guide spacing, loosen the top set screw and one side set screw only. This will ensure horizontal and vertical tilt adjustments are maintained when the set screws are retightened. 1.

  • Page 73: Blade Guide Vertically Tilt Adjustment

    6. Use the set screws to adjust the horizontal tilt of the roller. 7. Repeat steps 3-7 for the lower blade guide roller. NOTE: Once the blade guides have been adjusted, any cutting variances are most likely caused by the blade. See the Wood-Mizer® Blade Handbook, Form #600. MHdoc022715 4-17...

  • Page 74: Specifications

    SPECIFICATIONS Overall Dimensions SECTION 5 SPECIFICATIONS Overall Dimensions See Figure 5-1. The major dimensions of the Single Vertical Saw are shown below (all dimensions are in millimeters). FIG. 5-1 MHdoc022715 Specifications...
  • Page 75 SPECIFICATIONS Overall Dimensions See Figure 5-2. The figure shows the locations of resaws legs. FIG. 5-2 Specifications MHdoc022715...

  • Page 76: Cutting Capacity

    Max Material Height (0-25 m / 0-82 ft)/min Feed Speed TABLE 5-2 Wood-Mizer TRU•SHARP™ offers three types of blades to provide See Table 5-3. efficient sawing. The type of wood you saw should determine which blade you choose for optimum performance.

  • Page 77: Blade Motor Specifications

    400 V/50Hz; 2,3 Amp; Motor IMB14/1-162 1380 r.p.m. TABLE 5-4 See Table 5-5. The noise levels of the Wood-Mizer SVS are listed below Noise Level L 92,3 dB (A) E15 Electric Motor TABLE 5-5 1. The noise level measurement was taken in accordance with PN-EN ISO 3746 Standard .

  • Page 78: Electrical Diagram, Svs Eb15S, Svs Eb11S, 098071-2

    SPECIFICATIONS Electrical Diagram, SVS EB15S, SVS EB11S, 098071-2 Electrical Diagram, SVS EB15S, SVS EB11S, 098071-2 FIG. 5-2 MHdoc022715 Specifications...

  • Page 79: Electrical Component List, Svs Eb15S, Svs Eb11S

    SPECIFICATIONS Electrical Component List, SVS EB15S, SVS EB11S Electrical Component List, SVS EB15S, SVS EB11S Symbol Wood-Mizer Description Manufacturer Part No. 502312 Main Switch ABB OT40 F3 090436 Motor Switch GV3 P40 (E15) SCHNEIDER ELECTRIC 088264 Motor Switch GZ1 E32 (E11)

  • Page 80: Electrical Diagram, Svs Ec15, Svs Ec11, 098071-4

    SPECIFICATIONS Electrical Diagram, SVS EC15, SVS EC11, 098071-4 Electrical Diagram, SVS EC15, SVS EC11, 098071-4 FIG. 5-2 MHdoc022715 Specifications...

  • Page 81: Electrical Component List, Svs Ec15, Svs Ec11

    SPECIFICATIONS Electrical Component List, SVS EC15, SVS EC11 Electrical Component List, SVS EC15, SVS EC11 Symbol Wood-Mizer Description Manufacturer Part No. 502312 Switch ABB OT40 F3 084330 Motor Circuit Breaker Gz1 M21 (E15, E11) SCHNEIDER ELECTRIC 1M, 2M 084306 Contactor LC1 D18B7...

  • Page 82: Electrical Diagram, Svs Eh15S, Svs Eh11S, 098071

    SPECIFICATIONS Electrical Diagram, SVS EH15S, SVS EH11S, 098071 Electrical Diagram, SVS EH15S, SVS EH11S, 098071 FIG. 5-2 MHdoc022715 Specifications...

  • Page 83: Electrical Component List, Svs Eh15S, Svs Eh11S

    SPECIFICATIONS Electrical Component List, SVS EH15S, SVS EH11S Electrical Component List, SVS EH15S, SVS EH11S Symbol Wood-Mizer Description Manufacturer Part No. 502312 Switch ABB OT40 F3 084330 Motor Circuit Breaker Gz1 M21 (E15, E11) SCHNEIDER ELECTRIC 1M, 2M 084306 Contactor LC1 D18B7...

  • Page 84: Electrical Diagram, Svs Eh15, Svs Eh11, 098071

    SPECIFICATIONS Electrical Diagram, SVS EH15, SVS EH11, 098071 5.10 Electrical Diagram, SVS EH15, SVS EH11, 098071 FIG. 5-2 5-11 MHdoc022715 Specifications...

  • Page 85: 5.11 Electrical Component List, Svs Eh15, Svs Eh11

    SPECIFICATIONS Electrical Component List, SVS EH15, SVS EH11 5.11 Electrical Component List, SVS EH15, SVS EH11 Symbol Wood-Mizer Description Manufacturer Part No. 502312 Switch ABB OT40 F3 084330 Motor Circuit Breaker Gz1 M21 (E15, E11) SCHNEIDER ELECTRIC 1M, 2M 084306...

  • Page 86: 5.12 Dust Extractor Specifications

    SPECIFICATIONS Dust Extractor Specifications 5.12 Dust Extractor Specifications See Table 5-6. Specifications of the dust extractors used on the SVS are listed below Airflow 1200 m 3937 ft 150 mm / 5,9” Inlet diameter 1,5 kW Motor power 2 pcs Number of sacks Sack capacity 0.25 m...

  • Page 87: Laser Information

    Laser Information SECTION 6 LASER INFORMATION Specifications MHdoc022715...
  • Page 88 Laser Information MHdoc022715 Specifications...
  • Page 89 Laser Information Specifications MHdoc022715...

  • Page 90: Motor Brake

    Motor brake Maintenance/repair SECTION 7 MOTOR BRAKE Maintenance/repair Wear of spring − applied brakes INTORQ spring − applied brakes are wear−resistant and designed for long maintenance intervals. The friction lining and the mechanical brake components are subject to function−related wear. For safe and trouble−free operation, the brake must be checked and readjusted at regular intervals, and, if necessary, be replaced.

  • Page 91: Maintenance

    Motor brake Maintenance Maintenance Brakes with defective armature plates, cheese head IMPORTANT! screws, springs or flanges must be replaced completely. Please observe the following for inspections and maintenance operations: Remove impurities through oil and grease using brake cleaning agents, if necessary, replace brake ...
  • Page 92 Motor brake Maintenance If necessary, adjust air gap to "s ". Lürated  Brake Type sLürated sLümax Max. Rotor thickness Excess of the +0.1mm Service adjustment adjuster nut max. [mm] min. [mm] -0.05mm Brake permissible Emax. wear [mm] INTORQ BFK458-25 TABLE 8-1 EGdoc022715 specifications...
  • Page 93 EC declaration of conformity according to EC Machinery Directive 2006/42/EC, Annex II, 1.A We herewith declare, Wood-Mizer Industries Sp. z o.o. 114 Nagorna street, 62-600 Kolo; Poland. That the following described machine in our delivered version complies with the appropriate basic safety and health requirements of the EC Machinery Directive 2006/42/EC based on its design and type, as brought into circulation by us.
