Summary of Contents for Wood-mizer SHR-T Series

  • Page 1 Table of Contents Section-Page Table of Contents SW-07doc0515121...
  • Page 3 Single Head Resaw SHR-T Safety, Operation, Maintenance & Parts Manual SHRE11S-T rev. A4.00 SHRE15S-T rev.A4.00 Safety is our #1 concern! Read and understand all safety information and instructions before oper- ating, setting up or maintaining this machine. January 2005 Form #999...

  • Page 4: Table Of Contents

    Table of Contents Section-Page SECTION 1 SAFETY Safety Symbols..................1-1 Safety Instructions ..................1-2 SECTION 2 OPERATION Control Overview ...................2-1 Resaw Setup ...................2-3 Replacing The Blade ................2-5 Tensioning The Blade................2-6 Tracking The Blade ................2-7 Machine Start..................2-8 Blade Height Location Setting .............2-11 Tilt ......................2-12 Clamp Roller Guide Setting ..............2-13 2.10 Water Lube Operation ................2-14...
  • Page 5 Table of Contents Section-Page Cutting Capacity..................5-3 Blade Motor Specifications ..............5-4 Electrical Diagram, CE version..............5-5 Electrical Component List, SHR-T ............5-6 Electrical Diagram, African version............5-7 V-Belt Sizes....................5-8 SECTION 6 REPLACEMENT PARTS How To Use The Parts List ..............6-1 Sample Assembly ...................6-1 Blade Guide Assembly, Idle Side............6-2 Blade Guide Assembly, Drive Side............6-3 Blade Guide Arm Assembly..............6-4 Blade Wheel Assembly, Drive Side ............6-5...
  • Page 6 General Contact Information Getting Service Wood-Mizer is committed to providing you with the latest technology, best quality and strongest customer service available on the market today. We continually evaluate our customers’ needs to ensure we’re meeting current wood-processing demands. Your com- ments and suggestions are welcome.
  • Page 7 Introduction Branches & Authorized Sales Centers Branches & Authorized Sales Centers EUROPE UNITED STATES European Headquarters World Headquarters Wood-Mizer Industries Sp. z o.o. Wood-Mizer LLC Nagórna 114, 62-600 Koło, Poland 8180 West 10th Street Tel.: +48-63-26-26-000 Indianapolis,Indiana 46214-2400, Fax: +48-63-27-22-327 www.woodmizer.eu...
  • Page 8 Introduction Branches & Authorized Sales Centers BULGARIA Kalin Simeonov HUNGARY Wiktor Turoczy RUSSIA Far East Wladimir Głazaczew Ecotechproduct Wood-Mizer Hungary K.F.T. “WM Service” 38 Star Lozenski pat str. Szonyi Ut 67., 2921 Komárom Krasnoretchenskaya Str.111 Sofia 1186 Tel.:/Fax: +36-34-346-255 680006 Khabarovsk Tel.: +359-2-462-7035...
  • Page 9 Tel.: +49-5883-9880-12 GSM: +49-17-298-55-892 e-mail: KLongmuss@woodmizer.de Subagents: ROMANIA Adrian Echert Regional Manager - Asia DENMARK Brian Jensen SC WOOD-MIZER RO SRL Wood-Mizer Asia Pte Ltd. Arnborgvej 9, 7330 Brande- Fasterholt TRANSILVANIEI Nr. 5 James Wong Tel.: +45-971-88-265 Sibiu, Cisnadie 555300...

  • Page 10: Section 1 Safety

    Safety Safety Symbols SECTION 1 SAFETY Safety Symbols The following symbols and signal words call your attention to instructions concerning your personal safety. Be sure to observe and follow these instructions. DANGER! indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. WARNING! suggests a potentially hazardous situation which, if not avoided, could result in death or serious injury.

  • Page 11: Safety Instructions

    Wood-Mizer resaw. All Wood-Mizer resaw owners are encouraged to become thoroughly familiar with these applicable laws and comply with them fully while using the machine.
  • Page 12 Safety Wear Safety Clothing Wear Safety Clothing WARNING! Secure all loose clothing and jewelry before operating the resaw. Failure to do so may result in serious injury or death. WARNING! Always wear gloves and eye protection when handling bandsaw blades. Changing blades is safest when done by one person! Keep all other persons away from area when coiling, carrying or changing a blade.
  • Page 13 Safety Check Resaw Before Operation Check Resaw Before Operation DANGER! Make sure all guards and covers are in place and secured before operating the resaw. Failure to do so may result in serious injury. Keep Persons Away DANGER! Keep all persons out of the path of moving equipment and lumber when operating the resaw.
  • Page 14 Safety Keep Hands Away Keep Hands Away DANGER! Always shut off the blade motor before changing the blade. Failure to do so will result in serious injury. DANGER! Motor components can become very hot during operation. Avoid contact with any part of a hot motor. Contact with hot motor components can cause serious burns.
  • Page 15 Safety Use Proper Maintenance Procedures Use Proper Maintenance Procedures DANGER! Make sure all electrical installation, service and/or maintenance work is performed by a qualified electrician and is in accordance with applicable electrical codes. DANGER! Hazardous voltage inside the electric boxes and at the motor can cause shock, burns, or death.
  • Page 16 Safety Keep Safety Labels In Good Condition CAUTION! Always wear gloves when handling the blade. Never grab the blade with bare hands! CAUTION! If the blade breaks during sawmill operation, push the EMERGENCY STOP button to stop the blade motor and wait 10 seconds before you open the blade housing cover.
  • Page 17 Safety Keep Safety Labels In Good Condition TABLE 1-1 099220 CAUTION! Close all guards and covers before starting the machine. 099220 099219 Blade tension. Turning the bolt clockwise will increase the blade tension and turning the bolt counterclockwise will decrease the tension.
  • Page 18 Safety Keep Safety Labels In Good Condition TABLE 1-1 096321 Blade movement direction S12004G CAUTION! Always wear safety goggles when operating the sawmill! S12005G CAUTION! Always wear protective ear muffs when operating the sawmill! 501465 CAUTION! Always wear safety boots when operating the sawmill 501467 Lubrication Point...
  • Page 19 Safety Keep Safety Labels In Good Condition TABLE 1-1 P11789 Aligning the blade on the wheels 092597 Setting the blade tension indicator 092597 P85070 CE safety certification 099401 Russian safety certification 099401 S20097 Motor rotation direction S20097 Safety HRdoc051512 1-10...

  • Page 20: Section 2 Operation

    Control Overview SECTION 2 OPERATION Control Overview 1. Control Panel See Figure 2-1. The control panel includes switches to start and stop the feed track and the saw head. “0” EMERGENCY STOP START STOP STOP FIG. 2-1 CONTROL PANEL COMPONENTS 2.
  • Page 21 Control Overview 4. Feed Track Speed Adjustment The feed track speed switch controls the speed at which the feed track moves. Turn the TRACK FEED switch clockwise to increase the speed, counterclockwise to reduce the speed. 5. Key Switch The key switch has three positions: “0”...

  • Page 22: Resaw Setup

    Resaw Setup Resaw Setup IMPORTANT! Before starting to use the resaw you have to meet the following conditions: Set up the resaw on firm and level ground. The resaw can be operated with the sawdust collection system only. The resaw can be operated under roof only. The resaw can be operated in temperature range from 5 C to 40 C only.
  • Page 23 Resaw Setup below. 3-Phase Fuse Suggested Wire Size Volts Disconnect 400 VAC 32 Amps 4 mm , up to 15 m long TABLE 2-0 IMPORTANT! When starting the machine for the first time, check that main motor rotation direction is as indicated by the arrow located on the motor body (fan guard).

  • Page 24: Replacing The Blade

    Replacing The Blade Replacing The Blade DANGER! Always shut off the resaw motor before changing the blade. Failure to do so may result in serious injury. WARNING! Always wear gloves and eye protection whenever handling bandsaw blades. Changing blades is safest when done by one person! Keep all other persons away from work area when changing blades.

  • Page 25: Tensioning The Blade

    Tensioning The Blade Close the blade housing cover. Next, tension the blade as described in the following instructions. Tensioning The Blade See Figure 2-3. Place the provided ratchet on the blade tensioner shaft. Turn the ratchet clockwise until the outside face of the rubber spring washer is even with the indicator (see the figure below).

  • Page 26: Tracking The Blade

    Tracking The Blade Tracking The Blade 1. Open the blade housing cover. 2. Turn the key switch to the ”H” position. 3. Manually spin one of the blade wheels until the blade positions itself on the blade wheels. 4. Check that the blade is properly positioned on the blade wheels. See Figure 2-4.

  • Page 27: Machine Start

    Obs³uga maszyny Machine Start to do so may result in serious injury. Be sure the blade housing cover is in place and secured. NOTE: After aligning the blade on the wheels, always check the blade guide spacing and location. Machine Start DANGER! Before starting the resaw, perform these steps to avoid injury and/or damage to the equipment:...
  • Page 28 Obs³uga maszyny Machine Start To stop the blade motor, push the Blade/Track Stop button shown in the figure above. The blade motor also may be stopped by pushing either of the emergency stop buttons. If either of the emergency stops has been used to stop the blade motor, rotate the switch clockwise before restarting the saw head.
  • Page 29 Obs³uga maszyny Machine Start See Figure 2-7. The speed at which the feed track moves is adjustable. The feed track “0” EMERGENCY STOP START STOP STOP FIG. 2-7 speed switch, located on the control panel, allows the operator to adjust the feed rate from 0 to ca.

  • Page 30: Blade Height Location Setting

    Obs³uga maszyny Blade Height Location Setting Blade Height Location Setting 1. Install a blade if needed and check for correct blade tension. (Section 2.4) 2. Set the saw head at the desired height. (The blade height scale shows the height of the blade above the feed track.) See Figure 2-8.

  • Page 31: Tilt

    Obs³uga maszyny Tilt Tilt See Figure 2-9. The saw head may be tilted to produce siding. Loosen the locking bolt. Turn the tilt adjustment screw clockwise to tilt the saw head upward or counterclockwise to tilt the saw head downward. rs_008 Tilt Adjustment Screw Locking Bolt...

  • Page 32: Clamp Roller Guide Setting

    Obs³uga maszyny Clamp Roller Guide Setting Clamp Roller Guide Setting Release the clamp. Turn the crank clockwise to move the clamping rollers in; counterclockwise to move the clamping rollers out. Release the Clamp rs_010 Indicates width of material to be cut FIG.

  • Page 33: Water Lube Operation

    Obs³uga maszyny Water Lube Operation 2.10 Water Lube Operation See Figure 2-10. The Water Lube System keeps the blade clean. Water flows from a 5-gallon (18.9 liter) bottle through a hose to the blade guide where the blade enters the log.

  • Page 34: Operation Procedure

    Obs³uga maszyny Operation Procedure 2.11 Operation Procedure 1. Install a blade if necessary. WARNING! Always wear gloves and eye protection when handling bandsaw blades. Changing blades is safest when done by one person! Keep all other persons away from area when coiling, carrying or changing a blade. Failure to do so may result in serious injury.
  • Page 35 Obs³uga maszyny Operation Procedure 11. Place the test material on the feed track and start the feed track. DANGER! Always be aware of and take proper protective measures against rotating shafts, pulleys, fans, etc. Always stay a safe distance from rotating members and make sure that loose clothing or long hair does not engage rotating members resulting in possible injury.

  • Page 36: Maintenance

    MAINTENANCE Wear Life SECTION 3 MAINTENANCE This section lists the maintenance procedures that need to be performed. This symbol identifies the interval (hours of operation) at which each maintenance procedure should be performed. Be sure to refer to the motor manual for maintenance procedures concerning the blade motor.

  • Page 37: Blade Guides

    MAINTENANCE Blade Guides Blade Guides 1. Check the rollers for performance and wear every blade change. Make sure the rollers are clean and spinning freely. If not, rebuild them. Replace any rollers which have worn smooth or have become cone shaped. See the Parts manual for blade guide rebuild kits and complete roller assemblies.

  • Page 38: Miscellaneous Lubrication

    MAINTENANCE Miscellaneous Lubrication Miscellaneous Lubrication 1. Apply a thin film of a lithium grease to the blade guide arm to help prevent it from rusting. 2. Lubricate the feed track chain with an easily penetrating oil such as WD-40. CAUTION! Never apply grease to the feed track chain.

  • Page 39: Blade Tensioner

    MAINTENANCE Blade Tensioner Blade Tensioner 1. Grease the screw on the blade tensioner shaft with a lithium grease every fifty hours of operation, but at least once a week. See Figure 3-1. Tensioner Handle Screw 20_006 FIG. 3-1 Belts 1. Check the blade wheel belts for wear every 50 hours of operation. Replace as needed. 2.

  • Page 40: Drive Belt Adjustment

    MAINTENANCE Drive Belt Adjustment Drive Belt Adjustment WARNING! Do not for any reason adjust the drive belt with the motor running. Doing so may result in serious injury. See Table 3-2. Check the drive belt tension after the first 20 hours, and every 50 hours thereafter.
  • Page 41 MAINTENANCE Drive Belt Adjustment turn appropriately the left one.) NOTE: Be sure to adjust the bolts evenly so the motor remains in alignment. 4. Tighten the four motor mounting bolts. Left Adjutment Bolt Right Adjutment Bolt Motor Mounting Bolts (4) rs_013 FIG.
  • Page 42 MAINTENANCE Drive Belt Adjustment After performing the alignment, make sure the drive belt tension has not been changed. rs_023 FIG. 3-2 25doc051512 MAINTENANCE...

  • Page 43: Feed Track Chain Tension

    MAINTENANCE Feed Track Chain Tension Feed Track Chain Tension See Figure 3-3. If necessary, use the adjustment bolts shown below to adjust the feed track chain tension. NOTE:The bolts must be adjusted evenly. See Figure 3-4. Adjustment Bolts FIG. 3-4 MAINTENANCE 25doc051512...

  • Page 44: Up/Down System

    MAINTENANCE Up/Down System 3.10 Up/Down System 1. Lubricate the two acme screws, shown below, with a lithium grease every fifty hours of operation, but at least once a week. See Figure 3-5. Blade Height Adjustment Screw rs_015 Mast Tilt Adjustment Screw FIG.

  • Page 45: Section 4 Alignment

    SECTION 4 ALIGNMENT Alignment Procedures The Wood-Mizer resaw is factory aligned. This section includes instructions on how to realign the resaw completely. Be scrupulous when performing all alignment steps as resaw alignment determines the accuracy of your cuts. The alignment procedure should be performed approximately every 1500 hours of operation.

  • Page 46: Blade Installation And Tracking

    Blade Installation And Tracking Blade Installation And Tracking See Figure 4-1. Install a blade and apply the proper tension as shown below. Section 2.4 Outside face of washer even with indicator Cant Control Blade Tensioner Blade Tension Handle Indicator rs_006 Rubber Spring FIG.
  • Page 47 Blade Installation And Tracking [0.04"]). Do not let the teeth ride on the belt. SM0044D 3.0 mm (0.12”) ± 1 mm (0.04”) 4.5 mm (0.18”) 1 1/4" ± 1 mm (0.04”) Blade 1 1/2" Blade FIG. 4-2 To adjust where the blade travels on the idle-side blade wheel, use the cant control shown in Figure 4-7.

  • Page 48: Blade Wheel Alignment

    Blade Wheel Alignment Blade Wheel Alignment The blade wheels should be adjusted so they are level in the vertical and horizontal planes. If the blade wheels are tilted up or down, the blade will want to travel in the tilted direction.
  • Page 49 Blade Wheel Alignment See Figure 4-4. Use the vertical adjustment screws (marked with the blue and yellow arrows in the figure below) to adjust the drive-side blade wheel. Before adjusting the wheel, loosen the drive belt using the adjustment bolts marked with the orange arrows in the figure.
  • Page 50 Blade Wheel Alignment 4. Recheck the vertical tilt of the drive-side blade wheel with the blade guide alignment tool. Readjust the blade wheel as necessary until the front and rear of the tool are the same distance from the feed track (± 1.0 mm). 5.
  • Page 51 Blade Wheel Alignment 8. Check the position of the blade on the idle-side blade wheel. See Figure 4-6. The horizontal tilt of the blade wheel should be adjusted so that the gullet of an 1-1/4" blade is 3.0 mm out from the front edge of the wheel (± 1.0 mm). 150060 3.0 mm (0.12”) ±...
  • Page 52 Blade Wheel Alignment 9. Check the position of the blade on the drive-side blade wheel. The blade should be positioned on the wheel as described for the idle-side blade wheel. Adjust the drive-side blade wheel if necessary. See Figure 4-8. Use the horizontal adjustment screws (marked with the blue and yellow arrows in the figure below) to adjust the drive-side blade wheel.

  • Page 53: Saw Head Adjustment

    Saw Head Adjustment Saw Head Adjustment See Figure 4-9. The saw head should be set perpendicular to the vertical mast. Using the two sets of adjustment screws in the mast slide pads, you can adjust the saw head in relation to the mast. To raise or lower the outside of the saw head, loosen the locking nuts on either of the sets of screws.

  • Page 54: Blade Guide Arm Vertical Adjustment

    Blade Guide Arm Vertical Adjustment Blade Guide Arm Vertical Adjustment 1. Adjust the blade guide arm out to within 1/2" (15 mm) of full open. 2. Measure the distance from the top surface of the feed track to the arm. See Figure 4-10.
  • Page 55 Blade Guide Arm Vertical Adjustment Repeat adjustments until the arm is the same distance from the track feed in the open and closed position. 6. The blade guide arm should be snug, but not too tight, in the rollers. You should be able to move it in and out with firm hand pressure.

  • Page 56: Blade Guide Arm Horizontal Adjustment

    Blade Guide Arm Horizontal Adjustment Blade Guide Arm Horizontal Adjustment 1. Put the blade guide assembly back in the arm (if you took it out). Put the assembly back so that the flanged collar on the roller is about 3.0 mm (0.04") from the back of the blade when the arm is 15 mm (0.6") from full open.
  • Page 57 Blade Guide Arm Horizontal Adjustment See Figure 4-12. Adjustment Nuts Adjustment Nuts SM0066 FIG. 4-12 4. Adjusting the outside two rollers inward will cause the flange to move away from the blade. 5. Adjusting the two outside rollers outward will cause the flange to move toward the blade. 6.

  • Page 58: Aligning The Blade Guides

    Aligning the Blade Guides Aligning the Blade Guides Each Wood-Mizer resaw has two blade guide assemblies that help the blade maintain a straight cut. The two blade guide assemblies are positioned on the cutting head to guide the blade on each side of the material being cut.

  • Page 59: Blade Deflection

    Blade Deflection Blade Deflection Perform the following steps to achieve proper blade deflection with the blade guides. 1. Raise the carriage until the blade is 200 mm above the feed track. Measure the actual distance with a tape from the top of the track to the bottom of the blade. 2.

  • Page 60: Blade Guide Vertical Tilt Adjustment

    Blade Guide Vertical Tilt Adjustment Blade Guide Vertical Tilt Adjustment Check that the blade guide does not tilt the blade up or down. A Blade Guide Alignment Tool (BGAT) is provided to help you measure the vertical tilt of the blade. 1.
  • Page 61 Blade Guide Vertical Tilt Adjustment recheck the tilt of the blade. Loosen jam nuts and turn screws to tilt roller up or down SM0070 FIG. 4-15 5. Measure the distance from the bottom of the tool to the top of the feed track chain at the rear end of the tool.

  • Page 62: Blade Guide Spacing

    Blade Guide Spacing 4.10 Blade Guide Spacing HINT: When adjusting blade guide spacing, loosen the top set screw and one side set screw only. This will ensure horizontal and vertical tilt adjustments are maintained when the set screws are retightened. 1.

  • Page 63: Blade Guide Horizontal Tilt Adjustment

    6. Use the side set screws to adjust the horizontal tilt of the roller. 7. Repeat steps 3-7 for the inner blade guide roller. NOTE: Once the blade guides have been adjusted, any cutting variances are most likely caused by the blade. See the Wood-Mizer® Blade Handbook, Form #600. MHdoc051512 4-19...

  • Page 64: Clamp Roller Alignment

    Clamp Roller Alignment 4.12 Clamp Roller Alignment Clamp Roller Arm Tilt Check that for the first and the third clamping rollers the end closest to the infeed table is 5 mm (±1mm) from the top surface of the feed track chain (see the figure below). If the distance is different, adjust the tilt of the roller arm using the adjustment screws in the clamp roller guide.
  • Page 65 Clamp Roller Horizontal Adjustment Clamp Roller Horizontal Adjustment Make sure the clamping rollers are aligned. See Figure 4-19. Use the adjustment bolts, shown below, to move each roller in or out FIG. 4-19 until the rollers are in line. MHdoc051512 4-21...

  • Page 66: Blade Height Scale Adjustment

    Blade Height Scale Adjustment 4.13 Blade Height Scale Adjustment After the entire resaw has been aligned and all adjustments made, check that the blade height scale indicates the true distance from the blade to the feed track chain. 1. Measure from the bottom edge on a down-set tooth of the blade to the top of the feed track chain.

  • Page 67: Section 5 Specifications

    Specyfikacje Overall Dimensions SECTION 5 SPECIFICATIONS Overall Dimensions See Figure 5-1. The major dimensions of the resaw are shown below (all dimensions are in millimeters). FIG. 5-1 See Table 5-1. The overall dimensions of the resaw are listed in the table below. Weight 855 kg Height...
  • Page 68 Specyfikacje Overall Dimensions See Figure 5-2. The figure shows the locations of resaw legs. FIG. 5-2 MHdoc051512 Specyfikacje...

  • Page 69: Cutting Capacity

    Maximum Cutting Height 200 mm TABLE 5-2 See Table 5-3. Wood-Mizer TRU•SHARP™ offers three types of blades to provide efficient sawing. The type of wood you saw should determine which blade you choose for optimum performance. Recommended Blade Type Motor Size...

  • Page 70: Blade Motor Specifications

    Pssg 132M-4A 11kW 400 V/50Hz; 23 Amp; 1450 r.p.m. TABLE 5-4 See Table 5-5. The noise levels of the Wood-Mizer resaw are listed below Noise level Resaw Equipped With Electric Motor = 96,4 dB (A) TABLE 5-5 1. The noise level measurement was taken in accordance with PN-EN ISO 3746 Standard .

  • Page 71: Electrical Diagram, Ce Version

    Specyfikacje Electrical Diagram, CE version Electrical Diagram, CE version FIG. 5-2 Specyfikacje MHdoc051512...

  • Page 72: Electrical Component List, Shr-T

    Specyfikacje Electrical Component List, SHR-T Electrical Component List, SHR-T Symbol Wood-Mizer Description Manufacturer Part No. 094487 Transformer, TMM/63/A 240/400/440/24 BREVE 088265 Switch, ABB OT32E3 084330 Motor Switch, GZ1 M21 SCH- NEIDER ELECTRIC 093904 Circuit Breaker, C60N 2P C16 24337 SCH-...

  • Page 73: Electrical Diagram, African Version

    Specyfikacje Electrical Diagram, African version Electrical Diagram, African version FIG. 5-2 Specyfikacje MHdoc051512...

  • Page 74: V-Belt Sizes

    Specyfikacje V-Belt Sizes V-Belt Sizes See Table 5-6. Belt sizes for the resaw are shown. Belt Description Belt Size Wood-Mizer Part No. Drive Belt (E11) 095079 Drive Belt (E15) 2BX70 P04857-2 Blade Wheel Belt B72.5 017922 TABLE 5-6 Dust Extractor Specifications See Table 5-7.

  • Page 75: Section 6 Replacement Parts

    +48-63-2626000 or +48-3912-1319. From the continental U.S., call our toll-free Parts hotline 1-800-448-7881. Have your customer number, vehicle identification number, and part numbers ready when you call. From other international locations, contact the Wood-Mizer distributor in your area for parts. Replacement Parts SHRdoc051512...

  • Page 76: Blade Guide Assembly, Idle Side

    Replacement Parts Blade Guide Assembly, Idle Side Blade Guide Assembly, Idle Side rs_033 DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. BLADE GUIDE ASSEMBLY, HR IDLE SIDE 500500 BLADE GUIDE ROLLER, HR STANDARD COMPLETE 500499 NUT, M12-8 HEX NYLON ZINC LOCK F81034-2 ROLLER, BLADE GUIDE NARROW 500098...

  • Page 77: Blade Guide Assembly, Drive Side

    Replacement Parts Blade Guide Assembly, Drive Side Blade Guide Assembly, Drive Side HR0001B DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. BLADE GUIDE ASSEMBLY, HR DRIVE SIDE 500501 BLADE GUIDE ROLLER, HR STANDARD COMPLETE 500499 NUT, M12-8 HEX NYLON ZINC LOCK F81034-2 ROLLER, BLADE GUIDE NARROW 500098...

  • Page 78: Blade Guide Arm Assembly

    Replacement Parts Blade Guide Arm Assembly Blade Guide Arm Assembly DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. ARM, RESAW BLADE GUIDE 093243-1 ROLLER ASSEMBLY, V-GROOVE A09059 Roller, V-Groove S07989 Bearing, 6203-2 NSL 5/8 P06030-1 Ring, Retaining F04254-8 WASHER, 5/8"...

  • Page 79: Blade Wheel Assembly, Drive Side

    Replacement Parts Blade Wheel Assembly, Drive Side Blade Wheel Assembly, Drive Side RS_035D DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. WHEEL, RESAW BLADE DRIVE SIDE 500100-1 V-BELT, B72.5 017922 BUSHING, 45 SPLIT TAPER 500099 BOLT, M10X35 8.8 HEX HEAD FULL THREAD F81003-17 WASHER, 10.2 SPLIT LOCK ZINC F81055-2...
  • Page 80 Replacement Parts Blade Wheel Assembly, Drive Side Nut, M12-8 Hex Nylon Zinc Lock F81034-2 Screw, M8x25 A2-70 DIN 913 Set Stainless Steel F81014-3 Nut, M8-8-B Hex Nylon Zinc Lock F81032-2 Ring, W90 Inside Retaining F81090-29 Washer, 8.4 Flat Zinc F81054-1 PULLEY, SPB Φ224X2/Φ38 (F02312+T31124) 500177 PULLEY, SPB Φ190X2/Φ38 (F02347+T31124)

  • Page 81: Idle Side Blade Wheel Assembly

    Replacement Parts Idle Side Blade Wheel Assembly Idle Side Blade Wheel Assembly RS_36B DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. WHEEL ASSEMBLY, IDLE SIDE BLADE 088764 Wheel, Idle Side Blade 088419-1 Ring, W100 Inside Retaining F81090-10 Bearing, 3309B.2RSR.TVH FAG 086428 V-BELT, B72.5 017922...
  • Page 82 Replacement Parts Idle Side Blade Wheel Assembly WASHER, FLANGED ZINC-PLATED 086769-1 NUT, M12X1.25 8.8 HEX THIN ZINC F81034-5 WASHER, Z12.2 SPLIT LOCK ZINC F81056-2 BOLT, M12X1.25X40-8.8 HEX HEAD FULL THREAD ZINC F81004-42 WASHER, 13 FLAT ZINC F81056-1 BOLT, M5X12-5.8-FE/ZN5, PN-M/82105 F81000-5 WASHER, M5 SPLIT LOCK F81052-2...

  • Page 83: Blade Tensioner Assembly

    Replacement Parts Blade Tensioner Assembly Blade Tensioner Assembly 20_043c DESCRIPTION Indicates Parts Available In Assemblies Only) PART# QTY. BLADE TENSIONER ASSEMBLY 090587 Wrench, LT20 Blade Tension 091620 Pin, 5 x 30 Zinc Roll F81044-21 Bracket, Tension Handle Mount w/Bushing 096729 Bushing GFM-1618-17(IGUS) 089589 Bracket, Painted...

  • Page 84: Middle Throat Screw

    Replacement Parts Middle Throat Screw Middle Throat Screw rs_038 DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. SCREW, M10X40-45H HEX SOCKET SET CONE POINT ZINC F81003-61 NUT, M10-8-B HEX ZINC F81033-6 WASHER, 10.5 FLAT ZINC F81055-1 GROMMET, 22mm DIA. 087400 6-10 SHRdoc051512...

  • Page 85: Water Lube Assembly

    Replacement Parts Water Lube Assembly Water Lube Assembly 20_022c DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. WATER LUBE ASSEMBLY 091036 Tray, Water Lube Bottle 091033-1 Strap, 20" Rubber w/Hook P11668 Nut, M6-8-B Hex Nylon Lock Zinc F81031-2 Washer, 6.5 Special Flat Zinc F81053-11 Bolt, M6x25-8.8 Carriage Head Zinc...
  • Page 86 Replacement Parts Water Lube Assembly Reducer, 5/8" NPT to 3/8" Hose Barb 014113 Tubing, 3/8" I.D. Water Lube R01885 2.1 m 6-12 SHRdoc051512 Replacement Parts...

  • Page 87: Electric Box & Decals

    Replacement Parts Electric Box & Decals 6.10 Electric Box & Decals TBCE03B DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. DECAL, HIGH VOLTAGE INSIDE THE ELECTRIC BOX (PICTOGRAM) 096316 DECAL, REMOVE THE PLUG BEFORE OPENING THE BOX (PICTOGRAM) 096319 ELECTRIC BOX W/SPEED CONTROLLER 087926...

  • Page 88: Shr-T Saw Head Safety Decals

    Replacement Parts SHR-T Saw Head Safety Decals 6.11 SHR-T Saw Head Safety Decals 099220 099221 099222 Rs_064 DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. ZESTAW NALEPEK-PIKTOGRAMÓW RESAW, KOMPLETNY 094944 DECAL, SAWMILL COVERS CAUTION 099220 DECAL, BLADE TENSION (PICTOGRAM) 099219 DECAL, BLADE MOVEMENT DIRECTION (PICTOGRAM) 096321...
  • Page 89 Replacement Parts SHR-T Saw Head Safety Decals DECAL, READ OPERATOR’S MANUAL (PICTOGRAM) 096317 DECAL, BLADE ALIGNMENT P11789 DECAL, EYE PROTECTION WARNING (PICTOGRAM) S12004G DECAL, EAR PROTECTION WARNING (PICTOGRAM) S12005G DECAL, KEEP AWAY DANGER, PICTOGRAM 099221 DECAL, BLADE TENSION INDICATOR ADJUSTMENT 092597 DECAL KIT, SHR-T MACHINE NAME 099588...

  • Page 90: Blade Housing Cover

    Replacement Parts Blade Housing Cover 6.12 Blade Housing Cover rs_039 DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. COVER WELDMENT, RESAW BLADE HOUSING 093251-1 LATCH, FLEXIBLE DRAW 014829 BOLT, M5 X 16-5.8 HEX HEAD FULL THREAD ZINC F81000-51 NUT, M5-8 DIN 985 ZINC F81030-2 WASHER, 5.3 FLAT ZINC...
  • Page 91 Replacement Parts Blade Housing Cover NUT, M4-B HEX NYLON ZINC LOCK F81029-1 GUARD, BLADE GUIDE ROLLER PAINTED 094737-1 BOLT, M6X16 8.8 HEX HEAD FULL THREAD ZINC F81001-15 CHUTE, RESAW SAWDUST 094059-1 Replacement Parts SHRdoc051512 6-17...

  • Page 92: Control Panel

    Replacement Parts Control Panel 6.13 Control Panel RS_065 DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. CONTROL BOX, RESAW & HR 093458 Box, M22-I6 (216540) Control 093750 Potentiometer, M22-R1K (229489) 093749 Connector, DP 16/H F81096-7 Switch, M22 - 3 Position 091360 Operator, M22-WRS3 Key Switch 095001...

  • Page 93: Saw Head Height Adjustment Screw

    Replacement Parts Saw Head Height Adjustment Screw 6.14 Saw Head Height Adjustment Screw DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. SCREW, ACME ZINC-PLATED (SAW HEAD HEIGHT ADJUSTMENT) 093263-1 NUT, ACME SCREW FLANGED ZINC-PLATED 093264-1 BOLT, M10X25 8.8 HEX HEAD FULL THREAD F81003-31 WASHER, 10.2 SPLIT LOCK ZINC F81055-2...

  • Page 94: Mast Tilt Adjustment Screw

    Replacement Parts Mast Tilt Adjustment Screw 6.15 Mast Tilt Adjustment Screw rs_043 DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. ACME SCREW, MAST TILT ADJUSTMENT 093509-1 NUT, ACME SCREW FLANGED ZINC-PLATED 093264-1 BOLT, M10X35-8.8 HEX HEAD FULL THREAD ZINC F81003-17 WASHER, 10.5 FLAT ZINC F81055-1...

  • Page 95: Vertical Mast Slide Pads

    Replacement Parts Vertical Mast Slide Pads 6.16 Vertical Mast Slide Pads DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. ANGLE, VERTICAL MAST TUBE 093890 BOLT, M10X125-8.8 HEX HEAD ZINC F81003-18 WASHER, 10.5 FLAT ZINC F81055-1 Replacement Parts SHRdoc051512 6-21...
  • Page 96 Replacement Parts Vertical Mast Slide Pads NUT, M10-8-B HEX NYLON ZINC LOCK F81033-1 PADS, DELRIN UP/DOWN SLIDE M04096 PLATE, SLIDE PAD MOUNTING PAINTED 093246-1 NUT, SLIDE PAD ADJUSTMENT ZINC-PLATED 086683 BOLT, M8X35-8.8 HEX HEAD FULL THREAD ZINC F81002-13 NUT, M8-8-B HEX NYLON ZINC LOCK F81032-2 BOLT, M8X25-8.8-B HEX HEAD FULL THREAD ZINC F81002-5...

  • Page 97: Motor Assembly

    Replacement Parts Motor Assembly 6.17 Motor Assembly DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. MOTOR, 7.5kW Sg132M-4B - HM 094996 MOTOR, 11kW Sg132M-4PC-HM 093219 PULLEY, SPB Φ100X2/Φ38 (F02312+T31079) 500176 PULLEY, SPB Φ125X2/Φ38 (F02320+F31109) 500570 SCREW, M8X8-33H HEX SOCKET SET FLAT POINT ZINC F81014-1 BOLT, M10X45-8.8 HEX HEAD FULL THREAD ZINC F81003-3...

  • Page 98: Feed Track Assembly (Shr-T)

    Replacement Parts Feed Track Assembly (SHR-T) 6.18 Feed Track Assembly (SHR-T) DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. MOTOR & GEAR BOX, RA-06/39/D4/SN/V6 092075 Box, MRA-06/39/160/19/i4/S+N/V6 Gear 094833 Motor, SKh80X-4C1 IMB14/1-162 Induction 090104 BOLT, M8X25-8.8-B HEX HEAD FULL THREAD ZINC F81002-5 WASHER, 8.2 SPLIT LOCK ZINC F81054-4...
  • Page 99 Replacement Parts Feed Track Assembly (SHR-T) RING, Z25 OUTSIDE RETAINING F81090-8 IDLE PULLEY ASSEMBLY 092322 Pulley, Feed Track Idle Zinc-Plated 092320-1 Bearing, 6005 2RS CX 089652 Ring, W47 Inside Retaining 089653 Ring, Z24 Outside Retaining 089654 SHAFT, FEED TRACK IDLE 092323-1 PAD, FEED TRACK 092080...

  • Page 100: Clamp Roller Assembly (Shr-T)

    Replacement Parts Clamp Roller Assembly (SHR-T) 6.19 Clamp Roller Assembly (SHR-T) RS_048B DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. ACME SCREW, CLAMP ROLLER GUIDE 093521-1 COVER, BEARING ZINC-PLATED 088040-1 BLOCK, BEARING HOUSING ZINC-PLATED 088028-1 BAR, CLAMP ROLLER GUIDE CRANK ZINC-PLATED 087443-1 HANDLE, 12992M10 CRANK 086338...
  • Page 101 Replacement Parts Clamp Roller Assembly (SHR-T) BOLT, M16X110-8.8 HEX HEAD ZINC F81006-24 WASHER, 17 FLAT ZINC F81058-1 BUSHING, MOUNTING ZINC-PLATED 093507-1 NUT, M16-8 HEX NYLON ZINC LOCK F81036-2 ARM ASSEMBLY, FRONT PIVOT 094072 Roller, Clamp Zinc-Plated 092028-1 Bearing 6205.2RSR FAG 087353 Washer, 21 Flat Zinc F81059-2...

  • Page 102: Infeed, Outfeed & Return Tables

    Replacement Parts Infeed, Outfeed & Return Tables 6.20 Infeed, Outfeed & Return Tables DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. TABLE ASSEMBLY, RESAW RETURN 094721 Table Weldment, Return Painted 094515-1 Roller, 76 Dia. x 400 w/Internal Thread Table Painted 093787-1 Bolt, M10x35-8.8 Hex Head Full Thread Zinc F81003-17...
  • Page 103 Replacement Parts Infeed, Outfeed & Return Tables BRACKET, RESAW CONTROL BOX MOUNT PAINTED 094075-1 BOLT, M8X55 8.8 HEX HEAD ZINC F81002-8 WASHER, 8.4 FLAT ZINC F81054-1 TUBE, RESAW CONTROL BOX SPACER PAINTED 094738-1 Replacement Parts SHRdoc051512 6-29...

  • Page 104: Section 7 Dc Electromagnetic Brake

    DC Electromagnetic Brake Design and Principle of Operation SECTION 7 DC ELECTROMAGNETIC BRAKE 1 - Electromagnet, 2 - Armature complete with brake linings, 3 - Fan, 4 - Retaining bolt 5 - Central spring, 6 - Special washer, 7 - Set screw, 8 - Self-locking nut, 9 - Sealing ring, 10 - Output cable.

  • Page 105: Service

    DC Electromagnetic Brake Service Service During normal operation and at the routine inspections verify the air gap and check if all screws are tight. In case when any symptoms of inefficient braking are observed, then use the self-locking nut (8) to re-adjust the air gap to the value corresponding to Table 1. Such readjustment may be repeated until the brake linings are completely worn out.
  • Page 106 DC Electromagnetic Brake Service EAdoc051512 DC Electromagnetic Brake...
  • Page 107 DC Electromagnetic Brake Service DC Electromagnetic Brake EAdoc051512...
  • Page 108 DC Electromagnetic Brake Service EAdoc051512 DC Electromagnetic Brake...
  • Page 109 DC Electromagnetic Brake Service DC Electromagnetic Brake EAdoc051512...
  • Page 110 EC declaration of conformity according to EC Machinery Directive 2006/42/EC We herewith declare, Wood-Mizer Industries sp. z o.o. 114 Nagorna street, 62-600 Kolo; Poland. That the following described machine in our delivered version complies with the appropriate basic safety and health requirements of the EC Machinery Directive 2006/42/EC based on its design and type, as brought into circulation by us.
