Wood-Mizer
Safety, Setup, Operation
& Maintenance Manual
1992 LT30HD
1992 LT40HD
Safety is our #1 concern! Read and understand all
!
safety information and instructions before operating, set-
ting up or maintaining this machine.
October 1996
®
Sawmill
rev. C7 - F7
rev. C7 - F7
Form #625

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1992 LT30HD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wood-mizer 1992 LT30HD

Summary of Contents for Wood-mizer 1992 LT30HD

  • Page 1 ® Wood-Mizer Sawmill Safety, Setup, Operation & Maintenance Manual 1992 LT30HD rev. C7 - F7 1992 LT40HD rev. C7 - F7 Safety is our #1 concern! Read and understand all safety information and instructions before operating, set- ting up or maintaining this machine.
  • Page 2 If You Need To Order Parts... From the continental U.S., call our toll-free Parts hotline at 1-800-448-7881. Please have the vehicle identification number and your customer number ready when you call. Wood-Mizer will accept these methods of payment: Visa, Mastercard, or Select Purchase Prepayment Net 15 (with approved credit) Be aware that shipping and handling charges may apply.
  • Page 3 Take notice of all safety warnings throughout this manual and those posted on the machine. Keep this manual with this machine at all times, regardless of ownership. ® *Wood-Mizer is a registered trademark of Wood-Mizer Products, Inc. HD92doc042701iii...
  • Page 4 Your Vehicle Identification Number And Customer Number Each Wood-Mizer sawmill has a 17-digit Vehicle Identification Number (VIN). See the fig- ure below for VIN locations. See the chart at the right for VIN description. Each sawmill is also identified with a model number which includes the base model and the engine/motor configuration.
  • Page 5 V.I.N. DESCRIPTION. MODEL NUMBER DESCRIPTION. HD92doc042701...

  • Page 7: Table Of Contents

    Table of Contents Section-Page SECTION 1 SAFETY & GENERAL INFORMATION Blade Handling ......................1-1 Sawmill Setup......................1-1 Sawmill Operation..................... 1-2 Belt Sizes ........................1-4 Blade Sizes ........................ 1-5 Cutting Capacity ......................1-6 Engine/Motor Specifications ..................1-7 Overall Dimensions ....................1-8 Components .......................
  • Page 8 Table of Contents Section-Page SECTION 3 MAINTENANCE Wear Life........................3-1 Blade Guides ......................3-2 Hydraulic Log Loader ....................3-3 Blade Housing ......................3-4 Carriage Track, Wiper & Scrapers ................3-5 Track Rollers ......................3-6 Vertical Mast Rails ....................3-7 Drum Switches ......................3-8 Miscellaneous Lubrication ..................
  • Page 9 Table of Contents Section-Page SECTION 5 SAWMILL ALIGNMENT Pre-Alignment Procedures..................5-1 Frame Setup....................... 5-2 Blade Installation And Alignment................5-3 Saw Head Slide Pad Adjustment ................5-5 Adjusting The Lower Track Rollers................5-7 Adjusting Main Bed Rails To Blade ................. 5-9 Blade Guide Arm Vertical Adjustment ..............

  • Page 11: Safety & General Information

    Safety & General Information Blade Handling SECTION 1 SAFETY & GENERAL INFORMATION This symbol calls your attention to instructions concerning your personal safety. Be sure to observe and follow these instructions. This symbol accompanies a signal word. The word DANGER refers to hazards that can cause death or serious, irreversible personal injury.

  • Page 12: Sawmill Operation

    Safety & General Information Sawmill Operation Sawmill Operation DANGER! Never operate or tow the sawmill without all guards and covers in place and secured. Be sure the blade housing and pulley covers are in place and secure. If applicable, use the safety retainer pin and cable to fasten blade housing covers.
  • Page 13 Wood-Mizer sawmill. All Wood-Mizer mill owners are encouraged to become thoroughly familiar with these applicable laws and comply with them fully while using or towing the mill.

  • Page 14: Belt Sizes

    Safety & General Information Belt Sizes Belt Sizes See Table 1-1. Belt sizes for the LT30HD/40HD are shown. Description Belt Size Wood-Mizer Part # 24hp Gas Engine Drive Belt P10277-2 2BX74 20hp Diesel Engine Drive Belt P12139-2 2BX68 15hp Electric Motor Drive Belt...

  • Page 15: Blade Sizes

    Blade Sizes Blade Sizes See Table 1-2. Wood-Mizer TRU•SHARP™ offers three types of blades to provide effi- cient sawing for all models of sawmills. The engine/motor size of your sawmill and the type of wood you saw should determine which blade you choose for optimum perfor- mance.

  • Page 16: Cutting Capacity

    Safety & General Information Cutting Capacity Cutting Capacity See Table 1-3. The log size capacities of the LT30HD and LT40HD sawmills are listed below. Max. Max. Diameter Length LT30HD 16' 8" (5.1 m) 36" (91.5 cm) LT40HD 21' (6.4 m) 36"...

  • Page 17: Engine/Motor Specifications

    Safety & General Information Engine/Motor Specifications Engine/Motor Specifications See Table 1-5. The power options available for the LT30HD and LT40HD sawmills are listed below. Engine/Motor Manufacturer Model Type Number 24HP Gasoline Onan P224 20HP Diesel Acme ADX740 15HP Electric Baldor Custom TABLE 1-5 Safety &...

  • Page 18: Overall Dimensions

    Safety & General Information Overall Dimensions Overall Dimensions See Table 1-6. The overall dimensions of the LT30HD sawmill are listed below. LT30HD LT30HD with Surge Brake Trailer Pkg. Length 19' 11" (5.3 m) 21' 9" (6.6 m) Width 8' (2.4 m) 8' 2"...

  • Page 19: Components

    Safety & General Information Components Components See Figure 1-1. The major components of the Wood-Mizer LT30HD/LT40HD are shown below. Engine/Drive Assembly Water Lube Outer Blade Guide Arm Control Blade Tensioner Operator Hydraulic Side Support Hydraulic Seat Option Log Turner Log Clamp...

  • Page 20: Hydraulic Schematic

    Safety & General Information Hydraulic Schematic 1.10 Hydraulic Schematic FIG. 1-2 HYDRAULIC SCHEMATIC (REVISIONS E7+). 1-10 HD92doc042701 Safety & General Information...
  • Page 21 Safety & General Information Hydraulic Schematic FIG. 1-3 HYDRAULIC SCHEMATIC (REVISIONS C7 - E6). Safety & General Information HD92doc042701 1-11...

  • Page 22: Hydraulic Components

    Safety & General Information Hydraulic Components 1.11 Hydraulic Components REVISIONS E7+ Compo- Mfg. Part No. Manufacturer Wood-Mizer Description nent Part.# A09665 Wood-Mizer A09665 Hydraulic Cylinder, 1.5" Bore X 3.5" Stroke, Spring Return A09665 Wood-Mizer A09665 Hydraulic Cylinder, 1.5" Bore X 3.5" Stroke,...
  • Page 23 REVISIONS C7 - E6 Compo- Manufacturer Manufacturer Wood-Miz Description nent Part No. er Part A09665 Wood-Mizer A09665 Hydraulic Cylinder, 1.5" Bore X 3.5" Stroke, Spring Return A09665 Wood-Mizer A09665 Hydraulic Cylinder, 1.5" Bore X 3.5" Stroke, Spring Return TQ3008 Q0002 Monarch Can.

  • Page 24: Hydraulic Hoses

    Safety & General Information Hydraulic Hoses 1.12 Hydraulic Hoses REVISIONS F5+ Compo- Color Application Wood-Mize Description nent Code r Part No. Plain Log Turner Cylinder Base P12533 Hose, 1/4" X 14" Hydraulic W/Fittings Orange Log Turner Cylinder Top P12535 Hose, 1/4" X 27" Hydraulic W/Fittings Yellow Front Toe Board (LT30HD)
  • Page 25 Safety & General Information Hydraulic Hoses REVISIONS F5+ Blue Loading Arm Cylinder Top P12545 Hose, 1/4" X 151" Hydraulic (LT30HD) W/Fittings Blue Loading Arm Cylinder Top P12549 Hose, 1/4" X 173" Hydraulic (LT40HD) W/Fittings Loading Arm Cylinder Bottom P12545 Hose, 1/4" X 151" Hydraulic (LT30HD) W/Fittings Loading Arm Cylinder Bottom...
  • Page 26 Safety & General Information Hydraulic Hoses REVISIONS C7 - F4 Compo- Color Application Wood-Mize Description nent Code r Part No. Brown Toe Board Return (Rev. C7- E6 P12534 Hose, 1/4" X 22" Hydraulic Only) W/Fittings Brown Toe Board Return (Rev. C7- E6 P12534 Hose, 1/4"...
  • Page 27 Safety & General Information Hydraulic Hoses REVISIONS C7 - F4 Blue Loading Arm Cylinder Top P12545 Hose, 1/4" X 151" Hydraulic (LT30HD) W/Fittings Blue Loading Arm Cylinder Top P12549 Hose, 1/4" X 173" Hydraulic (LT40HD) W/Fittings Loading Arm Cylinder Bottom P12545 Hose, 1/4"...

  • Page 29: Setup & Operation

    Setup & Operation Stationary Sawmill Setup SECTION 2 SETUP & OPERATION Stationary Sawmill Setup See Figure 2-1. Set up the mill on firm footing. Level by eye. Fasten the mill to the floor or platform, or tie down to footing to stop any creep after prolonged use. NOTE: Make sure the unit is level before securing.

  • Page 30: Portable Sawmill Setup

    Setup & Operation Portable Sawmill Setup Portable Sawmill Setup WARNING! If the sawmill is to be set up on inclines of more than 10 degrees, put blocks under one side of the mill, or dig holes to prevent the mill from tipping over. DANGER! Chock the trailer wheels to prevent movement before unhitching it from the towing vehicle.
  • Page 31 Setup & Operation Portable Sawmill Setup Provided Adjustment Wrench Height Adjustment Nut Existing Outrigger Guide Locking Pin FAO Base SM0213 FIG. 2-2. BASE HEIGHT ADJUSTMENT (FOR FINE ADJUST OUTRIGGER ONLY). 3. Unhook the carriage safety chain. 4. Start the engine to enable the battery-operated accessories ( See Section 2.7 ).
  • Page 32 Setup & Operation Portable Sawmill Setup 6. Level the sawmill by adjusting the outriggers to raise or lower each end of the sawmill. Adjust all outriggers evenly to avoid twisting the mill frame by jacking one outrigger higher than the others. For FAO(s), fine tune the outrigger base height as necessary.

  • Page 33: Preparing The Sawmill For Operation

    Setup & Operation Preparing The Sawmill For Operation Preparing The Sawmill For Operation 1. TUV Trailers only: See Figure 2-4. Disassemble the perimeter fence. Remove the six locking pins and two hold-down nuts. Unplug the tail light board from the auxiliary adapter. Remove all four sections of the perimeter fence.

  • Page 34: Replacing The Blade

    Setup & Operation Replacing The Blade Replacing The Blade WARNING! Always wear gloves and eye protection when- ever handling bandsaw blades. Changing blades is safest when done by one person! Keep all other persons away from work area when changing blades. Do not change the blade with the engine running.

  • Page 35: Tensioning The Blade

    Setup & Operation Tensioning The Blade Tensioning The Blade See Figure 2-5. Tension the blade by turning the hydraulic tensioning handle clockwise until the tension gauge indicates the recommended tension. Blade Tensioner Gauge Blade Tensioner Handle Cant Control Handle SM0043 FIG.

  • Page 36: Tracking The Blade

    Setup & Operation Tracking The Blade Tracking The Blade Make sure the middle blade housing cover is closed and all persons are clear of the open side of the saw head. Start the engine (or motor). Pull lightly on the clutch handle, rotating the blade until the blade positions itself on the wheels.
  • Page 37 Setup & Operation Tracking The Blade Retension the blade to the recommended tension to compensate for any adjustments you have made in the cant control. Replace the covers. DANGER! Never operate the sawmill without all guards and covers in place and secured. Be sure the blade housing and pulley covers are in place and secure.

  • Page 38: Starting The Engine (Or Motor)

    See the appropriate manual supplied with your specific engine/motor configuration for starting and operating instructions. DANGER! Read the entire manual before operating your Wood-Mizer sawmill. DANGER! Never operate the sawmill without all guards and covers in place and secured. Be sure the blade housing and pulley covers are in place and secure before starting the sawmill.

  • Page 39: Hydraulic Control Operation

    Setup & Operation Hydraulic Control Operation Hydraulic Control Operation Revisions E7+ See Figure 2-7. Use the five control levers to do the following steps. This gets the mill ready to load a log. Loader Turner Rear Toe Board Front Toe Board Clamp HD0027 FIG.
  • Page 40 Setup & Operation Hydraulic Control Operation Revisions C7 - E6 See Figure 2-8. Use the four control levers to do the following steps. This gets the mill ready to load a log. FIG. 2-8 CAUTION! Never operate the hydraulic controls without the engine running.
  • Page 41 Setup & Operation Hydraulic Control Operation clamp. See Section 2.10 FIG. 2-9 2. Raise the log loader lever to extend the legs of the log loader out as far as they will go. 3. The chain securing the log loading arm to the log turner arm will be tight. Raise the log turner lever to raise the turner arm until there is slack in the chain.
  • Page 42 Setup & Operation Hydraulic Control Operation 8. Lower the loader lever to lower the loading arm as far as it will go. Logs must be rolled onto the loading arm one at a time for loading onto the bed of the mill. 9.

  • Page 43: Loading, Turning, And Clamping Logs

    Setup & Operation Loading, Turning, And Clamping Logs Loading, Turning, And Clamping Logs CAUTION! Be sure the pivot end rails (if applicable), turn- ing arm, clamp, and toe boards are out of the way before loading a log onto the bed. Be sure logs are positioned on the bed so that they will not damage the manual winch when loaded.
  • Page 44 Setup & Operation Loading, Turning, And Clamping Logs To Turn Logs 1. Raise the turner lever to engage the log turner arm. Let the arm rise until it touches the log and starts to turn it. 2. Spin the log against the side supports until it is turned the way you want it for the first cut. If you want to turn the log more, do the following steps.
  • Page 45 Setup & Operation Loading, Turning, And Clamping Logs To Level A Tapered Log Use the toe board lever(s) to raise either end of a tapered log, if desired. Revisions E7+ Raise the appropriate lever to raise the front or rear toe board until the heart of the log measures the same distance from the bed rails at each end of the log.

  • Page 46: Clamp Extension

    Setup & Operation Clamp Extension 2.10 Clamp Extension The clamp extension stored in the battery box or at the end of the clamp tube can be used for clamping small cants or logs. The clamp extension is used with the hydraulic clamp in its down position.

  • Page 47: Up/Down Operation

    Setup & Operation Up/Down Operation 2.11 Up/Down Operation See Section 2.5. 1. Install a blade, if needed, and check for correct blade tension. 2. Set the cutting head to the desired height. (The blade height sight gauge and scale show the height of the blade above the bed rails.) See Figure 2-12.

  • Page 48: Blade Guide Arm Operation

    Setup & Operation Blade Guide Arm Operation 2.12 Blade Guide Arm Operation 1. Look down the length of the log to see its maximum width. The outer blade guide should be adjusted to clear the widest section of the log by less than 1" (25.4 mm). 2.

  • Page 49: Clutch/Brake Operation

    Setup & Operation Clutch/Brake Operation 2.13 Clutch/Brake Operation 1. Clear any loose objects from the area of the blade, motor, and drive belt. 2. Make sure the clamp and side supports are adjusted below the level of your first few cuts. 3.

  • Page 50: Power Feed Operation

    Setup & Operation Power Feed Operation 2.14 Power Feed Operation See Figure 2-15. The power feed system moves the carriage forward and backward by using two switches on the control panel. FIG. 2-15 Carriage Feed Rate The carriage feed rate switch controls the speed at which the carriage travels forward. Turn the switch clockwise to increase speed.
  • Page 51 Setup & Operation Power Feed Operation DANGER! Make sure the carriage fwd/rev switch is in the neutral position before turning the key switch to the on or ACC position. This prevents unintended carriage move- ment. Using The Power Feed HINT: To get a straight cut in the first part of the board, feed the blade into the log at a slow speed.

  • Page 52: Cutting The Log

    Cutting The Log 2.15 Cutting The Log The following steps guide you through normal operation of the Wood-Mizer sawmill. 1. Once the log is placed where you want it and clamped firmly turn the key switch to the ACC position.

  • Page 53: Edging

    Setup & Operation Edging 2.16 Edging The following steps guide you through edging boards on the Wood-Mizer sawmill. 1. Raise the side supports to 1/2 the height of the flitches, or the boards that need to be edged. 2. Stack the flitches on edge against the side supports.

  • Page 54: Blade Height Sight Gauge

    Setup & Operation Blade Height Sight Gauge 2.17 Blade Height Sight Gauge See Figure 2-16. The sight gauge is provided on the cutting head carriage to help you decide where to make the first cuts on a log. Sight gauge eye-level SM0047 with bottom of blade FIG.

  • Page 55: Blade Height Scale

    Setup & Operation Blade Height Scale 2.18 Blade Height Scale See Figure 2-17. The blade height scale is attached to the carriage head frame. It includes: a blade height indicator an inch scale a quarter scale Blade Height Indicator Quarter Scale Inch Scale...
  • Page 56 Setup & Operation Blade Height Scale The Inch Scale The horizontal red line on the blade height indicator shows how many inches the bottom of the blade is above the bed of the mill. If you know the height of your blade at each cut, you can determine the thickness of lumber you are sawing.
  • Page 57 Setup & Operation Blade Height Scale The Quarter Scale See Table 2-2. Two quarter scales are provided with four sets of marks. Each set repre- sents a specific lumber thickness. Saw kerf and shrinkage allowance are included, but actual board thickness will vary slightly depending on blade thickness and tooth set. To choose which scale to use, determine what finished thickness you want to end up with.

  • Page 58: Water Lube Operation

    Setup & Operation Water Lube Operation 2.19 Water Lube Operation See Figure 2-18. The Water Lube System keeps the blade clean. Water flows from a 5-gallon (18.9 liter) bottle through a hose to the blade guide where the blade enters the log.

  • Page 59: Preparing The Sawmill For Towing

    Preparing The Sawmill For Towing 2.20 Preparing The Sawmill For Towing The Wood-Mizer trailer package makes transporting your sawmill easy and convenient. To get your sawmill ready for towing, follow these instructions. 1. Move the saw carriage to the front end of the sawmill. Raise the rear outriggers.
  • Page 60 Setup & Operation Preparing The Sawmill For Towing 7. Continue lowering the head 3/4" (19mm). until it contacts the stop blocks on the mast rails. CAUTION! Failure to properly secure the saw head can result in severe machine damage. Lower the saw head onto the rest pin until it contacts the rest pin collar, then lower the saw head 3/4"...
  • Page 61 Setup & Operation Preparing The Sawmill For Towing See Figure 2-21. FIG. 2-21 11. Remove all loose objects from the bed of the mill. Store the outrigger jack handle in the bracket provided on the rear/loading-side outrigger guide. Reel in the winch cable. Remove the winch handle.

  • Page 63: Maintenance

    Maintenance Wear Life SECTION 3 MAINTENANCE This section lists the maintenance procedures that need to be performed. The Short Interval Maintenance Schedule lists procedures that need to be performed every 4, 8 or 25 hours.The Maintenance Log lists procedures that need to be performed every 50, 100, 200, 300, 500, or 1000 hours.

  • Page 64: Blade Guides

    Maintenance Blade Guides Blade Guides See Figure 3-1. 1. Lubricate the blade guide rollers every four hours of operation. Use one squeeze of a NLGI No. 2 grade lithium grease from a grease gun to lubricate the bearings and remove any sawdust.

  • Page 65: Hydraulic Log Loader

    Maintenance Hydraulic Log Loader Hydraulic Log Loader Remove all sawdust and debris from around the velocity fuse valves every 8 hours of operation. The valves are located at the bottom of the log loader cylinders. Maintenance HD92doc042701...

  • Page 66: Blade Housing

    Maintenance Blade Housing Blade Housing 1. Remove the excess sawdust from the blade wheel housings and sawdust chute every blade change. See Figure 3-2. 2. Make sure the blade screw (or cam bearing on machines before 11/91) in the top center of the C-frame is 1/16"...

  • Page 67: Carriage Track, Wiper & Scrapers

    Maintenance Carriage Track, Wiper & Scrapers Carriage Track, Wiper & Scrapers See Figure 3-3. 1. Clean the upper and lower track rails to remove any sawdust and sap buildup every eight hours of operation. Lubricate the lower track rail by wiping it with Dexron III ATF. NOTE: If the top rail is not factory painted, apply a rust inhibitor such as Sherwin-Williams P.D.R.P #710 when the sawmill is not in use.

  • Page 68: Track Rollers

    Maintenance Track Rollers Track Rollers See Figure 3-4. 1. Lubricate the greasable track roller bearings every fifty hours of operation. Use a NLGI No. 2 grade lithium grease. FIG. 3-4 HD92doc042701 Maintenance...

  • Page 69: Vertical Mast Rails

    Maintenance Vertical Mast Rails Vertical Mast Rails Clean and lubricate the vertical mast rails every 50 hours of operation. Clean with solvent and remove any rust with a light-grade sand paper or emery cloth. Lubricate the mast with motor oil or automatic transmission fluid (ATF). CAUTION! Never use grease on the mast rails as it will col- lect sawdust.

  • Page 70: Drum Switches

    Lubricate the up/down and power feed drum switch contacts inside the control panel every fifty hours of operation. Use only contact grease supplied by Wood-Mizer. Remove the control panel cover. Use a cotton swab to apply grease to the switch contact ends.

  • Page 71: Miscellaneous Lubrication

    Maintenance Miscellaneous Lubrication Miscellaneous Lubrication 1. Apply a thin film of a NLGI No. 2 grade lithium grease to the blade guide arm every fifty hours of operation to help prevent it from rusting. 2. Grease the clamp mechanism, loading arm, and side supports with a NLGI No. 2 grade lithium grease every fifty hours of operation.

  • Page 72: Blade Tensioner

    Maintenance Blade Tensioner 3.10 Blade Tensioner 1. Lubricate the chrome rods of the tensioner system with a heavy duty teflon spray lubri- cant, such as Gunk L508, every fifty hours of operation. 2. Lubricate the tensioner screw handle with a NLGI No. 2 grade lithium grease as needed. See Figure 3-5.

  • Page 73: Blade Wheel Belts

    Maintenance Blade Wheel Belts 3.11 Blade Wheel Belts 1. Rotate the blade wheel belts and check them for wear. Rotating the belts every 50 hours will give you longer belt life. Replace belts as necessary. Use only B57 belts manufac- tured by Goodyear or Browning.

  • Page 74: Brake Strap Adjustment

    Maintenance Brake Strap Adjustment 3.12 Brake Strap Adjustment Hydraulic Sawmills Revisions F2+: Check the brake strap for wear every 200 hours of operation. Replace if damaged or worn. Also check and adjust the brake strap if the blade does not stop quickly, unusual sounds occur when the brake is applied, or a sudden change is noticed in the clutch handle posi- tion when the clutch is disengaged.
  • Page 75 Maintenance Brake Strap Adjustment See Figure 3-6. Metal-backed brake strap Brake strap clamping bolts (2) Lower clamping plate SM0056B FIG. 3-6 Maintenance HD92doc042701 3-13...

  • Page 76: Hydraulic System

    Maintenance Hydraulic System 3.13 Hydraulic System 1. Check the hydraulic fluid level every fifty hours of operation. Add fluid as necessary. The level in the hydraulic pump should be 4 1/2" (114 mm) with all cylinders collapsed. If humidity is a problem or the mill is used outside in humid weather, drain and replace two quarts (.95 liters) of fluid every six months.
  • Page 77 Maintenance Hydraulic System To check for excessive end play, as listed in step H, perform the following: Remove the rear head assembly. Position (push) the armature shaft to assure that it's drive tab is fully engaged with the pump shaft slot. Position (push) the stator frame so it is tight against the pump.

  • Page 78: Drive Bearing

    Maintenance Drive Bearing 3.14 Drive Bearing Refill the fluid in the drive-side cylinder bearing housing every 1000 hours of operation. Remove the top and bottom oil plugs. Pour an Automatic Transmission Fluid (ATF) such 1000 as Dexron III ATF into the top hole until it begins to flow from the bottom hole. Reinstall the square oil plug to the bottom hole and the vented oil plug to the top hole.

  • Page 79: Up/Down System

    Maintenance Up/Down System 3.15 Up/Down System 1. Grease the up/down gear reducer shaft bearing with a NLGI No. 2 grade lithium grease 1000 every 1000 hours of operation. See Figure 3-9. FIG. 3-9 Maintenance HD92doc042701 3-17...
  • Page 80 Maintenance Up/Down System 2. Adjust the up/down belt as needed. Remove the up/down housing cover. To tighten the belt, loosen the two motor mount nuts. Adjust the bolt underneath the motor upward so there is 3/8" (9.5 mm) deflection with a 7 lb. (3.2 Kg) deflection force. Tighten the jam nut to secure the bolt in place.
  • Page 81 Drain and refill the gearbox with 14 - 16 ounces of oil after the first 100 hours of sawmill operation. Repeat every 5000 hours or once a year, whichever comes first. Wood-Mizer offers replacement gear oil in 8 ounce bottles (2 required for complete oil replacement).

  • Page 82: Power Feed

    Maintenance Power Feed 3.16 Power Feed 1. Adjust the power feed belt as needed. When the power feed belt gets loose, it will begin slipping. This causes the carriage to not move forward when cutting. To retighten the belt, remove the feed motor cover. Loosen the three motor mounting bolts. See Figure 3-12.
  • Page 83 Maintenance Power Feed See Figure 3-13. 3H0018B Feed Chain Adjustment Nuts FIG. 3-13 Maintenance HD92doc042701 3-21...

  • Page 84: Miscellaneous Maintenance

    Maintenance Miscellaneous Maintenance 3.17 Miscellaneous Maintenance See Section 5, Alignment. 1. Check the mill alignment every setup. 2. Make sure all safety warning decals are readable. Remove sawdust and dirt. Replace any damaged or unreadable decals immediately. Order decals from your Customer Service Representative.

  • Page 93: Troubleshooting Guide

    Troubleshooting Guide Sawing Problems SECTION 4 TROUBLESHOOTING GUIDE Sawing Problems PROBLEM CAUSE SOLUTION Blades Dull Quickly Dirty logs Clean or debark logs, especially on entry side of the cut When grinding teeth, heating Grind just enough metal to restore too much and causing teeth to sharpness to the teeth.
  • Page 94 Troubleshooting Guide Sawing Problems Boards Thick Or Thin On Stress in log which causes log After log has been squared, take Ends Or Middle Of Board to not lay flat on the bed equal cuts off opposing sides. Take a board off the top.

  • Page 95: Electrical Problems

    "off" position. Replace drum switch or remove control panel cover and clean and lubricate contacts NOTE: Use only contact grease supplied by Wood-Mizer. Drum switch spring broken Manually move the power feed or up/down switch back to neutral or "off" position. Replace drum switch...
  • Page 96 Troubleshooting Guide Electrical Problems Bad fuse Replace Bad connection in battery Check connections Corrosion on battery post Remove connection and clean posts Battery Will Not Stay Charged Key switch left ON Turn switch OFF when not in use Short in system Visually check for bare wires and/or have checked Charging system not function-...

  • Page 97: Power Feed Problems

    Components are loose or Inspect PC board for loose connec- wires are broken tions and components; Send PC board to Wood-Mizer for guaranteed repair Power Feed Is Jerky When Variable speed switch is bad - Replace variable speed switch Shaft Of Feed Rate Dial Is...
  • Page 98 Troubleshooting Guide Power Feed Problems Chain is dragging Make sure chain is centered on cam follower bearing; Clean and lubricate chain; Adjust chain tension. Allow motor to cool before restarting Chain is improperly tensioned Adjust chain tension. Allow motor to cool before restarting Seat load is excessive Check seat bearings for freedom of...

  • Page 99: Power Feed Circuit Troubleshooting

    IL - This light indicates the circuit board has detected a failure of the output circuit protec- tion or that the power feed motor has been replaced with a motor not provided by Wood-Mizer. The light will flash about once every second and will deactivate the output Troubleshooting Guide...
  • Page 100 Troubleshooting Guide Power Feed Circuit Troubleshooting circuit. If the power feed motor is a Wood-Mizer replacement, replace the circuit board. CL - This light indicates an extreme overload condition of the power feed motor or a short in the wiring between the motor and circuit board. The light will flash about once every second and deactivate the feed system until the problem is corrected.

  • Page 101: Hydraulic Problems

    See Monarch manual for trou- solenoid is not a standard automotive bleshooting solenoid type. Order from Monarch or Wood-Mizer only Low or dead battery Test battery. Replace or recharge as necessary Defective pump motor Remove motor from pump and inspect.
  • Page 102 Troubleshooting Guide Hydraulic Problems Pump Motor Runs With Little Low battery Test battery. Recharge or replace as Or No Response From The necessary Cylinders See Mon- Debris clogging pressure relief Clean pressure relief valve. valve (Revisions C7 - E6 arch manual. Only) Low fluid level Check fluid level.
  • Page 103 Troubleshooting Guide Hydraulic Problems Fluid Leak Around Pump Box Loose seal or fitting Wipe pump off completely to locate cause of lead. You may have to unbolt the pump to wipe behind it. NOTE: Movement of the sawmill can cause fluid to slosh up into the foam filter in the reservoir cap, and subse- quently spray out, giving the appear- ance that fluid is leaking from the...

  • Page 104: Engine/Motor And Drive Pulleys Alignment

    Troubleshooting Guide Engine/Motor and Drive Pulleys Alignment Engine/Motor and Drive Pulleys Alignment 1. Install the drive belt. 2. Use a straight edge to align the engine/motor pulley to the drive pulley. Also check that the engine pulley is within 1/8" square with the drive pulley. Loosen the engine mounting bolts and rotate the engine if necessary.

  • Page 105: Power Feed Variable Speed Switch Test

    Troubleshooting Guide Power Feed Variable Speed Switch Test Power Feed Variable Speed Switch Test With the feed rate dial switch all the way down, move the shaft of the dial back and forth to see if there is a jerky response. Turn the dial and move the shaft back and forth again. Repeat several times.

  • Page 106: Power Feed Preliminary Test

    Troubleshooting Guide Power Feed Preliminary Test Power Feed Preliminary Test This test will determine if the problem is a mechanical or electrical. 1. Remove the drive belt from the power feed drive pulley. 2. Turn the key switch to the ACC position. Put the carriage fwd/rev switch into the forward position and turn the feed rate dial through all speeds.

  • Page 107: Power Feed Mechanical Test

    Troubleshooting Guide Power Feed Mechanical Test Power Feed Mechanical Test 1. Remove the weight from the track rollers. They should turn smoothly and easily with very little play. 2. Make sure the middle track cover is not bent or touching the top rail. 3.

  • Page 108: Hydraulic Pressure Test

    Troubleshooting Guide Hydraulic Pressure Test 4.10 Hydraulic Pressure Test To check hydraulic pressure on E7+ revision LT30HD/LT40HD mills: 1. Disconnect power from the pump by moving the saw head forward until it no longer con- tacts the power strip. 2. Locate the loading arm port fitting on the hydraulic valve body. See Figure 4-2.
  • Page 109 Troubleshooting Guide Hydraulic Pressure Test To check hydraulic pressure on C7 - E6 revision LT30HD/LT40HD mills: 1. Disconnect power from the pump by moving the saw head forward until it no longer con- tacts the power strip. 2. Locate the fitting on the front toe board cylinder. Disconnect the hydraulic hose from the fitting and install a gauge to the fitting.

  • Page 111: Sawmill Alignment

    SECTION 5 SAWMILL ALIGNMENT Pre-Alignment Procedures The Wood-Mizer sawmill is factory aligned. Periodically check the sawmill alignment and adjust if necessary. This chapter explains how to align the entire sawmill. Care should be taken in performing these steps. Sawmill alignment determines the accuracy and square- ness of your cuts.

  • Page 112: Frame Setup

    Sawmill Alignment Frame Setup Frame Setup Stationary sawmills should be setup on firm, level ground before proceeding with align- ment. Shim the feet so the weight of the sawmill is evenly supported. Portable sawmills should also be setup on firm, level ground. Adjust the two middle out- riggers on the main frame tube down just enough to lift weight from the trailer tire.

  • Page 113: Blade Installation And Alignment

    Sawmill Alignment Blade Installation And Alignment Blade Installation And Alignment See Figure 5-1. Install a blade and apply the appropriate tension (See Section 2.5 Ten- sioning The Blade). Blade tension is adjusted with the tension handle shown. 1/8" (3.0 m) ±...
  • Page 114 Sawmill Alignment Blade Installation And Alignment To adjust where the blade travels on the idle-side blade wheel, use the cant control shown in Figure 5-1. 1. Start the engine. Pull lightly on the clutch handle to rotate the blade until it locates itself on the blade wheels.

  • Page 115: Saw Head Slide Pad Adjustment

    Sawmill Alignment Saw Head Slide Pad Adjustment Saw Head Slide Pad Adjustment There are eight nylon pads positioned between the saw head frame and vertical mast. The spacing of the pads is factory set and rarely needs adjusting. To check the pad spac- ing, perform the following steps.
  • Page 116 Sawmill Alignment Saw Head Slide Pad Adjustment FIG. 5-3 5. Loosen the lower locking bolts and turn the adjusting bolt as necessary to provide the pad spacing described in Step 4. CAUTION! Due to variations in the vertical mast, the pad spacing may vary throughout the travel of the saw head.

  • Page 117: Adjusting The Lower Track Rollers

    Sawmill Alignment Adjusting The Lower Track Rollers Adjusting The Lower Track Rollers Making these adjustments correctly will give you square cuts and accurate dimensions across the width of your boards. 1. Move the saw carriage so the blade is over the rear main bed rail. See Figure 5-4.
  • Page 118 Sawmill Alignment Adjusting The Lower Track Rollers 5. Repeat this step with the blade over the front main bed rail. 6. Move the carriage from the front of the mill to the back. Watch the lower rollers and stop blocks. Make sure the gap between the rail and both stop-blocks never goes over the 1/16-1/8"...

  • Page 119: Adjusting Main Bed Rails To Blade

    Sawmill Alignment Adjusting Main Bed Rails To Blade Adjusting Main Bed Rails To Blade 1. Move the clamp all the way out to flip the clamp down if neccesary. Adjust the clamp until it is positioned under the outer blade guide. 2.
  • Page 120 Sawmill Alignment Adjusting Main Bed Rails To Blade See Figure 5-7. Blade 15“ (375.0 mm) 15“ (375.0 mm) Bed Rail Clamping Bolt Clamping Bolt Adjustment Adjustment Bolt Bolt SM0064 FIG. 5-7 5. Measure the distance between the bottom of the blade and the bed rail at each end of the bed rail.

  • Page 121: Blade Guide Arm Vertical Adjustment

    Sawmill Alignment Blade Guide Arm Vertical Adjustment Blade Guide Arm Vertical Adjustment 1. Move the saw head so that the blade guide arm is directly over a bed rail. 2. Adjust the blade guide arm out to within 1/2" (15 mm) of full open. 3.

  • Page 122: Blade Guide Arm Horizontal Adjustment

    Sawmill Alignment Blade Guide Arm Horizontal Adjustment Blade Guide Arm Horizontal Adjustment 1. Put the blade guide assembly back in the arm (if you took it out). Put the assembly back so that the flanged collar on the roller is about 1/8" (3.0 mm) from the back of the blade when the throat is 1/2"...
  • Page 123 Sawmill Alignment Blade Guide Arm Horizontal Adjustment See Figure 5-10. Adjustment Nuts Adjustment Nuts SM0066 FIG. 5-10 4. Adjusting the outside two rollers (furthest from the arm motor) inward will cause the flange to move away from the blade. 5. Adjusting the two outside rollers outward will cause the flange to move toward the blade. 6.

  • Page 124: Aligning The Blade Guides

    Aligning The Blade Guides Aligning The Blade Guides Each Wood-Mizer sawmill has two blade guide assemblies that help the blade maintain a straight cut. The two blade guide assemblies are positioned on the saw head to guide the blade on each side of the material being cut.

  • Page 125: Blade Deflection

    Sawmill Alignment Blade Deflection 5.10 Blade Deflection Perform the following steps to achieve proper blade deflection with the blade guides. 1. Raise the carriage until the blade is 15" (375 mm) above a bed rail. Measure the actual distance with a tape from the top of the rail to the bottom of the blade. 2.

  • Page 126: Blade Guide Vertical Tilt Adjustment

    Sawmill Alignment Blade Guide Vertical Tilt Adjustment 5.11 Blade Guide Vertical Tilt Adjustment Check that the blade guide does not tilt the blade up or down. A Blade Guide Alignment Tool (BGAT) is provided to help you measure the vertical tilt of the blade. 1.
  • Page 127 Sawmill Alignment Blade Guide Vertical Tilt Adjustment See Figure 5-13. Loosen jam nuts and turn screws to tilt roller up or down SM0070 FIG. 5-13 8. Move the carriage forward so the back end of the tool is over the bed rail. 9.

  • Page 128: Blade Guide Spacing

    Sawmill Alignment Blade Guide Spacing 5.12 Blade Guide Spacing HINT: When adjusting blade guide spacing, loosen the top set screw and one side set screw only. This will insure horizontal and vertical tilt adjustments are maintained when the set screws are retightened. 1.

  • Page 129: Horizontal Tilt Adjustment

    Sawmill Alignment Horizontal Tilt Adjustment 5.13 Horizontal Tilt Adjustment 1. Finally, both blade guides must be tilted horizontally. Adjust the blade guide arm half way See Figure 5-15. FIG. 5-15 2. Place Blade Guide Alignment Tool against the face of the outer blade guide roller. 3.

  • Page 130: Horizontal Adjustment Of Side Supports

    Sawmill Alignment Horizontal Adjustment Of Side Supports 5.14 Horizontal Adjustment Of Side Supports The side supports are used to clamp flats on a log to set the squareness of the next cut. The cut will only be as square as the supports. 1.

  • Page 131: Vertical Adjustment Of Side Supports

    Sawmill Alignment Vertical Adjustment Of Side Supports 5.15 Vertical Adjustment Of Side Supports 1. Place a flat board across the bed rails. 2. Swing a side support up so that it is vertical. 3. Pull back at the top of the support to eliminate slack as if a log were being clamped against it.

  • Page 132: Clamp Stop Adjustment

    Sawmill Alignment Clamp Stop Adjustment 5.16 Clamp Stop Adjustment 1. Once the side supports are aligned, pivot them down to their horizontal position. 2. Tie a string across the face of the side supports. See Figure 5-18. 3. Loosen the clamp stop bolts and adjust the clamp stop until it touches the string. FIG.

  • Page 133: Aligning The Pivot Bed Rails

    Sawmill Alignment Aligning The Pivot Bed Rails 5.17 Aligning The Pivot Bed Rails The two pivot bed rails are used when long cants are cut. (Long cants will often bend down at the ends.) The pivot bed rails need to be adjusted to the same level as the main bed rails.
  • Page 134 Sawmill Alignment Aligning The Pivot Bed Rails 7. Adjust as needed until the pivot rail measures the same distance (±1/32) from the blade in the 45°, 90°, and -45° positions. CAUTION! Do not roll logs or large cants onto pivot bed rails.

  • Page 135: Sight Gauge Adjustment

    Sawmill Alignment Sight Gauge Adjustment 5.18 Sight Gauge Adjustment After adjustments to the bed rails and blade guides are complete, adjust the sight gauge so that it accurately shows the position of the blade over the bed rails. 1. Move the saw head so the sight gauge is positioned over a bed rail. 2.

  • Page 136: Saw Head Tilt

    Sawmill Alignment Saw Head Tilt 5.19 Saw Head Tilt As the blade enters a wide log or cant, the outside of the saw head will drop down slightly. To compensate for the drop, use the lower track roller horizontal bolts to raise the outside of the saw head 1/16".

  • Page 137: Blade Height Scale Adjustment

    Sawmill Alignment Blade Height Scale Adjustment 5.20 Blade Height Scale Adjustment After the entire sawmill has been aligned and all adjustments made, check that the blade height scale indicates the true distance from the blade to the bed rails. 1. Move the saw head so the blade is positioned 14 3/4" (375 mm) above the bed rails by actual measurement with a rule.
