COLOCAÇÃO EM OPERAÇÃO
7
Colocação em operação
7.1

Alinhamento

pt
124
M A N U A L D E I N S T R U Ç Õ E S | RAY10
Tabela 77: Alarme
Alinhamento
NOTA
Dica: o alinhamento correto pode ser verificado com base no indicador de potência do
sinal no lado posterior do sensor.
Figura 81: Alinhamento
Alarme (≤ 100 mA)
+ (L+)
Alarm
– (M)
+ (L+)
Alarm
– (M)
8022198.1BXN / 2021-05-26 | SICK
Sujeito a alteração sem aviso prévio
