- Page 1 Owner’s Manual. Studio Pro 2000 Olympic Barbell Weight Bench. www.viavito.com Manual version 1.1...
-
Page 2: Table Of Contents
Manufacturer’s Warranty For more information, or if you require any assistance please email us at Technical Information 24/26 support@viavito.com Exploded Diagram Safety Standards: Parts List Space Required The weight bench conforms to the following standard:... -
Page 3: Safety Information
Use only spare bench are adequately informed of all parts supplied by Viavito. precautions. 12 Unauthorized repairs or altering the 03 The weight bench is intended for bench’s design or functions may be... - Page 4 16 Always wear appropriate workout those with pre-existing health problems. clothing when exercising. Sports shoes are required when using this Viavito assumes no responsibility for equipment. personal injury and/or property damage sustained by or through the use of this 17 Always place an equal amount of product.
- Page 5 Warning Decal Placement 130 kg 141 kg 68 kg Keep hands and 60 kg fingers clear of this area. www.viavito.com...
-
Page 6: Assembly
Assembly Product Overview Thank you for selecting the Viavito Studio Pro 2000 Olympic barbell weight bench. This manual will guide you through the assembly process. ASSEMBLED DIMENSIONS：204x125x152cm Upright Leg Lever Weight Rest Knob Seat Bracket www.viavito.com... -
Page 7: Part Identification Chart
Parts List on page 25. Note: Some small parts may have been preattached. If a part is not in the hardware kit, check if it has been preattached. M4 x 19mm Self-tapping Screw (30) M10 x 59mm Bolt Set (48) www.viavito.com... -
Page 8: Before You Begin
- 2 adjustable wrenches assembly is completed. - 1 rubber mallet - 1 Phillips screwdriver Assembly may be easier if you have a set of wrenches. To avoid damaging parts, do not use power tools. www.viavito.com... -
Page 9: Assembly Instructions
Assembly Instructions Step One. 01 Orient the Crossbar (3) as shown. 02 Attach the Crossbar (3) to the Uprights (6) with four M10 x 80mm Screws (29), do not tighten the Screws yet. www.viavito.com... - Page 10 01 Slide the end of the Frame (1) onto the 02 See Step 1.02,Tighten the four M10 x Crossbar (3). Attach the Frame with 80mm Screws (29). four M10 x 20mm Screws (21) and four M10 Washers (20). Start all four Screws, and then tighten them. www.viavito.com...
- Page 11 Orient the three parts as shown. 02 Attach the Left Seat Frame (10) to the Seat Bracket (2) with two M8 x 42mm Bolts (22), two M8 Washers (23) and two M8 Locknuts (34); do not tighten the Bolts yet. www.viavito.com...
- Page 12 Backrest Frames (7, 8) to the Frame (1) adjustment hole in the Seat Bracket. with an M12 x 132mm Bolt (26) and an M12 Locknut (27). Do not overtighten the Locknut; the Seat Frames and the Backrest Frames must be able to pivot. www.viavito.com...
- Page 13 Step Five. 01 Attach the Seat (11) to the Seat Frames (9, 10) with four M6 x 65mm Screws (25) and four M6 Washers (24). Start all four Screws, and then tighten them. www.viavito.com...
- Page 14 01 Attach the Backrest (47) to the 02 See Step 3.02, tighten the eight M8 x Backrest Brackets (7, 8) with four 42mm Bolts (22). M6 x 65mm Screws (25) and four M6 Washers (24). Start all four Screws, and then tighten them. www.viavito.com...
- Page 15 Frame (1), and align one of the holes and the Leg Support (16) and tighten in the Leg Support (16) with the hole the Knob. in the Frame . 03 Attach Leg Lever (14) to Leg Support (16) with one M10 x 59mm Bolt Set (48). www.viavito.com...
- Page 16 03 Slide a Foam Pads (17) onto each end of Leg Support (16). the Long Pad Tube (33) and Short Pad Tubes (15). 02 Insert the Short Pad Tubes (15) into the Leg Lever (14). 04 Then, press a Pad Cap (39) into each Pad Tubes (15, 33). www.viavito.com...
- Page 17 03 Make sure that all parts are properly 01 Attach the Weight Rests (5) to the tightened before the weight bench is Uprights (6) as shown. used. 02 Make sure that both Weight Rests (5) are at the same height. www.viavito.com...
-
Page 18: Conditioning Guidelines
• Control appetite injuries, joint problems, obesity and • Boost self-image asthma. • Improve muscle tone and strength • Improve flexibility • Lower blood pressure • Relieve insomnia www.viavito.com... -
Page 19: Beginner's Guide To Exercise
• Start slowly and build up your time, speed and resistance gradually; doing too much too soon can lead to injuries. • If you are sore or tired, give yourself a few extra days to recover. www.viavito.com... -
Page 20: Stretching Guide
• Stretch at least three times a week to injury. Stretching develops flexibility and maintain flexibility. reduces muscles soreness. Stretches should be held for 15 to 30 seconds. www.viavito.com... - Page 21 The purpose of cooling down is to return the body to its normal or near normal, resting state at the end of each exercise session. A proper cool-down slowly lowers your heart rate, allows blood to return to the heart and helps prevent muscle soreness caused by the build-up of lactic acid in the muscles. www.viavito.com...
-
Page 22: Customer Support
• Precise description of the issue or defect. IMPORTANT! Please retain your sales receipt. Viavito Customer Care may request proof of purchase to validate eligibility for warranty service. Warranty cover starts from the date shown on the proof of purchase. -
Page 23: Manufacturer's Warranty
Manufacturer's Warranty Viavito warrants this product to be free Viavito is not responsible or liable for of defects of material and workmanship, direct, indirect, or consequential losses under normal use and conditions, for a arising out of or in connection with the use... -
Page 24: Technical Information
Technical Information Exploded Diagram www.viavito.com... -
Page 25: Parts List
Leg Bumper Weight Clip M10 Washer M10 x 20mm Screw M8 x 42mm Bolt M8 Washer M6 Washer M6 x 65mm Screw M12 x 132mm Bolt M12 Locknut Pad Cover M10 x 80mm Bolt M4 x 19mm Self-tapping Screw www.viavito.com... -
Page 26: Space Required
Annex 1: Space Required For safety reasons, minimum clearance for the equipment is 0.6m in all directions. 1245 www.viavito.com... - Page 27 www.viavito.com...
