Table 16 MX0105A Probe Head Components
SMA Shorting Adapter
Extending the MX0105A Probe Head's Cable Length
You can extend the cable length of the MX0105A SMA probe head and add
flexibility and convenience to the probing setup by using the N5448B (25cm) /
N2823A (1m) phase matched cable pair. You can easily replace the supplied
semi-rigid SMA cables of the MX0105A probe head with these cables. These
cables support 2.92 mm male-to-2.92 mm male connection.
For detailed specifications of these cables, refer to the user's guide available in the
Document Library tab of www.keysight.com/find/N5448B.

InfiniiMode Capable

The MX0105A probe head is InfiniiMode capable when used with an InfiniiMax
Ultra series probe amplifier. See
measurements.
InfiniiMax Ultra Series Probe Amplifiers & Probe Heads User's Guide
Component
The SMA shorting adapter connects one side of resistances on both
SMA inputs to ground.
For signaling standards such as HDMI and MIPI MPhy that require the
resistances to be referenced to a common DC voltage rather than a
ground, you can remove this shorting adapter and apply a common dc
termination voltage (± 4 V) using the supplied cable and a DC power
supply. You can also control the termination voltage internally through
the oscilloscope.
MX0105A InfiniiMax Ultra Differential SMA Probe Head
Description / Usage
page 150 for details on how to make InfiniiMode
