33502A 2-Channel Isolated Amplifier User/Service Guide Quick Start This chapter gives you a quick overview of the 33502A amplifier’s front panel and basic features. The examples will help you become familiar with your amplifier and its basic operation. The Front Panel at a Glance... -
Page 8: The Front Panel At A Glance
1 Quick Start The Front Panel at a Glance The Keysight 33502A is a two-channel, isolated amplifier. Both channels can either propagate a signal directly or with 5x amplification. The channel inputs are on the rear panel of the amplifier, and the outputs are either on the front panel, as shown here, or on the rear panel (Option 001 only). -
Page 9: The Rear Panel At A Glance
3 Channel 2 Output Connector (Option 001 only) 4 Channel 2 Input Connector 5 USB Interface Connector 6 LAN Interface Connector 7 AC Power Connector 8 Chassis Ground Screw For protection from electrical shock, the power cord ground must not be defeated. Keysight 33502A User/Service Guide... -
Page 10: The Display At A Glance
Channel 1 Status Shown in yellow Channel 2 Status Shown in green Softkey Labels Shown at the bottom of the screen. Keysight 33502A User/Service Guide... -
Page 11: Basic Amplifier Operations
Quick Start Basic Amplifier Operations This section introduces the basics of the 33502A amplifier, and how to use it. Preparing the Amplifier for Use To verify that your 33502A amplifier is ready for use: Check the list of supplied items. -
Page 12: Using The Front Panel
(Option 001). When you turn a channel on, the number on the button illuminates, as shown below for channel 1. Keysight 33502A User/Service Guide... - Page 13 The front panel also includes six softkeys at the bottom of the display that allow you to select various functions and options. Each softkey selects the option shown on the front panel display immediately above the softkey. Keysight 33502A User/Service Guide...
-
Page 14: Basic Amplifier Troubleshooting
When you turn the amplifier on, the LED should be illuminated and green. If the amplifier still does not come up, or if the LED does not light up in the presence of known-good power, your amplifier is in need of repair. Keysight 33502A User/Service Guide... -
Page 15: To Adjust The Carrying Handle
Quick Start To Adjust the Carrying Handle To adjust the position, grasp the handle by the sides and pull outward. Then, rotate the handle to the desired position. Bench-Top Viewing Positions Carrying Position Keysight 33502A User/Service Guide... -
Page 16: To Rack Mount The Amplifier
Any Keysight System II (half-width, 2U height) instrument of either the 272.3 mm or the 348.3 mm depth can be rack mounted side–by–side with the 33502A. For example, a 33502A and a 33210A, or two 33502As, can be mounted side–by–side, as shown below. -
Page 17: Features And Functions
In this chapter you will find a detailed description of the amplifier’s capabilities and operation. This chapter presents both front-panel and remote interface operation of the instrument. Refer to the Keysight 33502A Programmer’s Reference Help for a detailed description of the SCPI commands. SCPI Programming Introduction... -
Page 18: Scpi Programming Introduction
Features and Functions SCPI Programming Introduction The Keysight 33502A complies with the syntax rules and conventions of SCPI . For complete SCPI command (Standard Commands for Programmable Instruments) syntax information, refer to the Keysight 33502A Programmer’s Reference Help. This is a standard Windows help system, provided on the Keysight 33502A Product Reference CD-ROM that came with your instrument. -
Page 19: Front Panel Features
Front Panel Features Front Panel Display The Keysight 33502A provides an alphanumeric display to indicate the status of the channels and the amplifier’s overall configuration. The display also includes a menu section at the bottom that allows you to configure the instrument and perform certain operations. -
Page 20: Front Panel Main Menu
Direct Specifies whether the selected channel should go directly through the Amplified 33502A, or whether it should get 5x amplification. If you select Amplify, the Impedance and Coupling softkeys (below) become active. Impedance Specifies whether the selected channel should have 50 or 1,000,000 ohms 50Ω... - Page 21 File Allows you to manipulate files and folders in the mass memory subsystem, including internal storage and USB. Help Presents a menu of help topics and access to help on the most recently displayed message(s). Keysight 33502A User/Service Guide...
-
Page 22: File Menu
(Perform The label on this softkey will change to one of the four choices shown, Action) depending on what is selected by the Action key above. When you press this softkey, that action will be performed. Keysight 33502A User/Service Guide... -
Page 23: System Menu
Allows you to specify whether you want the help to appear in English, French, German, Japanese, Korean, or Chinese. NISPOM Allows you to secure the amplifier to National Industrial Security Program Secure Operating Manual (NISPOM) specifications. Options Allows you to configure the display and beeper. Keysight 33502A User/Service Guide... -
Page 24: I/O Config Menu
The features under the front panel I/O Config menu are shown below. Enables or disables the amplifier’s LAN connection. LAN Settings Allows you to configure the amplifier’s local area network (LAN) settings. LAN Reset Resets the amplifier’s LAN settings to factory defaults and resets the connection. Keysight 33502A User/Service Guide... -
Page 25: Annunciators
The following command queries the display setting: DISPlay? The query returns 0 (OFF) or 1 (ON). Sending a DISPlay:TEXT “<string>” command when the display is turned off will keep the display off with the exception of displaying the “<string>”. Keysight 33502A User/Service Guide... -
Page 26: Front Panel Alphanumeric Character Entry
• Errors are cleared as you read them. When you have read all errors from the interface–specific and global error queues, the ERROR annunciator turns off and the errors are cleared. Keysight 33502A User/Service Guide... -
Page 27: Reading The Error Queue
Remote Interface Operation: The following command reads and clears one error from the error queue in first-in, first-out order. SYSTem:ERRor? Refer to the for a complete Keysight 33502A Programmer’s Reference Help description and syntax for this command. Keysight 33502A User/Service Guide... -
Page 28: Mass Memory (Mmemory) Subsystem
For example, you may choose to store a file on the 33502A that lists the tests that use the amplifier, which signals are attached to which channels, and the configured state of each channel. -
Page 29: Power-On And Reset State
System Version 2009.0 Input/Output Configuration Factory Setting Enable Interfaces: Enabled Enabled LXI Identification State LAN Settings: DHCP IP Address 169.254.5.2 Default Gateway 0.0.0.0 DNS Server 0.0.0.0 Host Name A-33502A-nnnnn LAN Services Enable All Telnet Prompt “33502A>” Keysight 33502A User/Service Guide... - Page 30 Input/Output Configuration Factory Setting Telnet Welcome Message “Welcome to Keysight 33502A 2-Channel Isolated Amplifier” 1 Interface enable or LAN service changes take effect only after you cycle power. 2 LAN setting changes require a LAN restart. From SCPI you must cycle power.
-
Page 31: Remote Interface Configuration
33502A 2-Channel Isolated Amplifier User/Service Guide Remote Interface Configuration This chapter describes how to connect the amplifier using a remote interface. Configuring the USB Interface Configuring the LAN Interface Configuring LAN Parameters DHCP IP Address Subnet Mask Default Gateway Host Name... -
Page 32: 3 Remote Interface Configuration
Remote Interface Configuration This chapter tells how to configure the Keysight 33502A for remote interface communication. For additional information, refer to the: • Keysight 33502A Programmer’s Reference Help for information on programming the instrument using SCPI commands. This help file is found on the Keysight 33502A Product Reference CD–ROM. -
Page 33: Configuring The Usb Interface
The following command queries the state of the USB interface: SYSTem:COMMunicate:ENABle? USB This query returns a “0” (disabled) or a “1” (enabled). Refer to the for complete Keysight 33502A Programmer’s Reference Help description and syntax for these commands. Keysight 33502A User/Service Guide... -
Page 34: Configuring The Lan Interface
Configuring the LAN Interface By default, LAN connectivity with DHCP (Dynamic Host Configuration Protocol) is enabled on the 33502A. In many cases you can simply let DHCP assign the necessary parameters for a LAN connection. However, you can also turn off DHCP and set parameters manually. -
Page 35: Ip Address
Subnet Mask. • Changing the Subnet Mask setting will cause an automatic LAN reset. • The default Subnet Mask for the 33502A amplifier is “255.255.0.0”. • A value of “0.0.0.0” or “255.255.255.255” indicates that subnetting is not being used. -
Page 36: Default Gateway
• The default for the amplifier is “0.0.0.0” (no gateway, and subnetting is not being used). • The Default Gateway is stored in non–volatile memory, and does not change when power has been off, after a Factory Reset (*RST) command, or after an Instrument Preset (SYSTem:PRESet) command. Keysight 33502A User/Service Guide... -
Page 37: Host Name
IP address. • Changing the Host Name will cause an automatic LAN reset. • The default Host Name for the amplifier is “A–33502A–nnnnn”, where nnnnn is the last five digits of the instrument’s serial number representation. • If Dynamic Domain Name System (DNS) is available on your network and your amplifier uses DHCP, the Host Name is registered with the Dynamic DNS service at power–on. -
Page 38: Dns Server
Instrument Preset (SYSTem:PRESet) command. Instrument Unexpectedly Goes into Remote If your 33502A unexpectedly goes into remote mode, it is likely because you have the instrument configured to the LAN on someone else’s host controller. Operations on that host controller can query your instrument causing it to go into remote mode. -
Page 39: Setting Up A Lan Connection From The Front Panel
• Gateway – (Only shown if DHCP is disabled) Set gateway in dot notation using softkeys. • DONE – Return to the previous menu level. • MORE – (Only shown if DHCP is disabled) Opens an additional menu that allows you to enter DSN, WINS and host name information. Keysight 33502A User/Service Guide... -
Page 40: Setting Up A Lan Connection From The Remote Interface
• To assign a LAN Host Name: SYSTem:COMMunicate:LAN:HOSTname “<name>” • To assign the LAN a static DNS address: SYSTem:COMMunicate:LAN:DNS “<address>” Query forms of these commands are also available. Refer to the Keysight 33502A for complete command description and syntax. Programmer’s Reference Help Keysight 33502A User/Service Guide... -
Page 41: Keysight 33502A Web Interface
Remote Interface Configuration Keysight 33502A Web Interface The 33502A provides a built–in Web Interface. You can use this interface over LAN for remote access and control of the amplifier using a Java–enabled Web browser, such as Microsoft® Internet Explorer. To access and use the 33502A Web Interface: Establish a LAN interface connection from your computer to the amplifier. - Page 42 Remote Interface Configuration Keysight 33502A User/Service Guide...
-
Page 43: Service Information And Typical Characteristics
33502A 2-Channel Isolated Amplifier User/Service Guide Service Information and Typical Characteristics This chapter describes how to verify instrument functionality, how to obtain service, and describes the instrument’s typical characteristics. Service Information Verifying Amplifier Functionality Gain, Flatness, and Full Power Bandwidth Tests... -
Page 44: Service Information
Service Information Verifying Amplifier Functionality This simple procedure allows you to verify that your 33502A amplifier is functioning properly. To begin, set up the amplifier in the following configuration, which includes a function generator and a digital multimeter (DMM) connected via shielded BNC cable. -
Page 45: Gain, Flatness, And Full Power Bandwidth Tests
Configure the DMM for AC voltage with 10 Hz bandwidth or less. Configure the 33502A for 1 MΩ input impedance, with the channel turned on and amplified. You will need to repeat the test for both channels. For each of the combinations shown in the following table, measure V... -
Page 46: Output Current Tests
Serice Information Output Current Tests To avoid causing a false result by overheating the 33502A, be sure to disconnect the DMM from the amplified output of the 33502A until you are ready to take the measurements. When you do connect to take the... -
Page 47: Internal Switching Tests
Configure the function generator to generate 1 VDC into a high impedance load. Configure the DMM for DCV. For each of the 33502A configurations shown in the following table, measure (the amplified signal). Compare your values of V to the typical values for operation shown in the two columns on the right side of the table. -
Page 48: Types Of Service Available
Serice Information Types of Service Available If your instrument fails during the warranty period, Keysight Technologies will repair or replace it under the terms of your warranty. After your warranty expires, Keysight offers repair services at competitive prices. Extended Service Contracts Many Keysight products are available with optional service contracts that extend the covered period after the standard warranty expires. -
Page 49: Repackaging For Shipment
Before cleaning the amplifier, remove power from the amplifier. Clean the outside of the instrument with a soft, lint–free, slightly dampened cloth. Do not use detergent. Disassembly is not required or recommended for cleaning. Be sure that the amplifier is dry before restoring power. Keysight 33502A User/Service Guide... -
Page 50: To Order Replaceable Parts
LAN Connector 53200-61608 Line Filter 33250-68501 33502-80002 Power Supply Kit* * The fuses used in the power supply are 3.15A / 250V radial-leaded, time lag fuses. If the fuse blows, replace the entire power supply assembly. Keysight 33502A User/Service Guide... -
Page 51: Typical Characteristics
Service Information Typical Characteristics These characteristics apply when using the 33502A amplifier in an environment that is free of electromagnetic interference and electrostatic charge. When using the amplifier in an environment where electromagnetic interference or significant electrostatic charge is present, measurement accuracy may be reduced. -
Page 52: General Characteristics
Cet appareil ISM est conforme à la norme NMB-001 du Canada. Safety: Complies with European Low Voltage Directive and carries the CE-marking. Conforms to UL 61010-1, CSA C22.2 61010-1, and IEC 61010-1:2001. Acoustic Noise: Normal operating mode SPL 35 dB(A) Keysight 33502A User/Service Guide... - Page 53 LXI Compliance: LXI Class C, Version 1.0 Number of Channels: Channel to Channel Ground Not connected in BYPASS ON. Connection: Connected with both channels OFF or in Gain of 5x Floating Voltage: ±42 Vpk to earth Keysight 33502A User/Service Guide...
-
Page 54: Input Configuration
> 300 kHz (-3dB) Full Power Bandwidth 100 kHz @ 50 Vpp output Input Bypass Bandwidth for 50Ω system > 300 MHz (-3dB) Maximum current 0.2 A Noise Input referred noise < 40nV/ rt-Hz @ 1 kHz Keysight 33502A User/Service Guide... -
Page 55: Output Configuration
Output Protection Continuous short circuit protection. Thermal overload shutdown. Over temperature status flag. For all loads >250 and <400 pF of capacitance. Ω Measured with >= 1 M load and 1 M input selection. Ω Ω Keysight 33502A User/Service Guide... - Page 56 Serice Information Dimensions All dimensions are shown in millimeters Keysight 33502A User/Service Guide...
-
