To attach ground wires to the probe head tip
11

InfiniiMode Measurements and Available Bandwidth

In an InfiniiMode setup, the best bandwidth is possible with the minimum length
direct ground wires that are close to probe tip's and DUT's PC boards. Poor ground
connections can reduce the available bandwidth for single-ended and
common-mode measurements in an InfiniiMode setup.
For common-mode measurements, the available bandwidth is lesser than other
measurement modes. The bandwidth limit applicable for a measurement mode is
automatically applied in the Infiniium software GUI.
InfiniiMax Ultra Series Probe Amplifiers & Probe Heads User's Guide
Align and solder these ground wires to
the DUT.
In case you have attached ground wires and do not wish to make
NOT E
InfiniiMode measurements, then just fold these or leave as is. These won't
affect your non-InfiniiMode single-ended or differential measurements.
12
Making Measurements
155
