Chauvet CH-140B User Manual

Troubleshooting
If the unit is not functional - check that the main power supply is 'on' and check fuses.
If the unit is functional but lamp does not light - lamp may require replacing.
If after trying the above, you still have a problem contact CHAUVET.
Caution
Do not obstruct the air vents.
Do not touch unit or lamps while hot.
No user serviceable parts inside. Please refer to CHAUVET for service.
Power Connections
The unit is supplied with a power plug appropriate to its voltage and destination. Should any other connec-
tions be required, they must be carried out with the following configuration.
Earth = Green/Yellow cable
Neutral = Blue cable
Live = Brown cable
In the USA & Europe, it is required that all plugs are 3-pin type i.e. with Earth/Ground connection.
In the UK, it is required that all mains plugs are fitted with 5A fuses.
Technical Specifications
Power 120V~60Hz AC
Fuse
5A 125V
24v 250W
Lamps
Part No ELC3 24V 250W
Dimensions
508 x 178 x 165mm / 20 x 7 x 6.5in
Weight 9.6kg / 21.2lbs
User Information (Please complete for your records)
Date Purchased: / /
Dealer Stamp:
230V~50Hz AC
3.15A 250V
24v 250W
Part No ELC3 24V 250W
508 x 178 x 165mm / 20 x 7 x 6.5in
9.6kg / 21.2lbs
Serial No: ________________
Model: CH-140B Nebula 250
CH-140PY Pizzazz 250
N N e e b b u u l l a a 2 2 5 5 0 0
P P i i z z z z a a z z z z 2 2 5 5 0 0
User Guide
Please read these instructions carefully before use
World-wide Headquarters:
3000 North 29th Ct.
Hollywood, Florida, USA 33020
Tel: +1-954-929-1115 Fax: +1-954-929-5560
www.ChauvetLighting.com
CH-140B
CH-140PY
