Chauvet ALIEN CH-209 User Manual

Caution
Do not obstruct the air vents.
Do not touch unit or lamps while hot.
No user serviceable parts inside, please refer to CHAUVET for service.
Power Connections
The unit is supplied with a power plug appropriate to its voltage and destination. Should any other
connections be required they must be carried out with the following configuration.
Earth = Green/Yellow cable
Neutral = Blue cable
Live = Brown cable
In the USA & Europe, it is required that all plugs are 3-pin type i.e. with Earth/Ground connection.
In the UK, it is required that all mains plugs are fitted with 5A fuses.
Technical Specifications
Power 120V~60Hz AC
Fuse 20mm Glass 3.15A Fast Blow
1 x 120V 300W
Lamps
Part No 64514
Dimensions 203 x 254 x 254mm / 8in x 10in x 10in
Weight
User Information
(Please complete for your records)
Date Purchased: / /
Dealer Stamp:
230V~50Hz AC
20mm Glass 1.6A Fast Blow
1 x 230V 300W
Part No 64516
3.6kg / 7.92lbs
Serial No:
Model: CH-209 ALIEN
A l i e n
CH-209
Users Guide
Please read these instructions carefully before use
World-wide Headquarters:
3000 North 29 Ct., Hollywood, Florida, USA, FL 33020
th
Tel: +1-954-929-1115 Fax: +1-954-929-5560
www.ChauvetLighting.com
