ADJ DOTZ MATRIX User Instructions page 20

DMX CHANNELS / VALUES / FUNCTIONS (11 DMX Channels)
MODE / CHANNEL
CH 3 CH 6
4
5
6
When Channel 49 is being used between the values of 136-247, Channel 53 can control program
dimming.
When Channel 49 is being used between the values of 136-247, Channel 50 will control the
speed of the programs.
SUPPORTS SOFTWARE VERSION ≥ 1.07
CH7 CH 48 CH 53
4
5
6
7
VALUE
COLOR MACROS & PROGRAMS
0 - 15 NO FUNCTION
16 - 23 RED
24 - 31 GREEN
32 - 39 BLUE
40 - 47 RED & GREEN
48 - 55 GREEN & BLUE
56 - 63 RED, GREEN, & BLUE
64 - 71 COLOR 1
72 - 79 COLOR 2
80 - 87 COLOR 3
88 - 95 COLOR 4
96 - 103 COLOR 5
104 - 111 COLOR 6
112 - 119 COLOR 7
120 - 127 COLOR 8
49
128 - 135 COLOR FADE 1
136 - 143 COLOR SNAKE
144 - 151 COLOR FADE 2
152 - 159 COLOR CHANGE
160 - 167 COLOR FLOW 1
168 - 175 COLOR FLOW 2
176 - 183 COLOR FLOW 3
184 - 191 COLOR FLOW 4
192 - 199 COLOR FLOW 5
200 - 207 COLOR FLOW 6
208 - 215 COLOR FLOW 7
216 - 223 COLOR FLOW 7
224 - 231 COLOR FLOW 8
232 - 239 COLOR FLOW 9
240 - 247 COLOR FLOW 10
248 - 255 N/G
MASTER DIMMER/PROGRAM SPEED
50 0 - 255 MASTER DIMMER 0% - 100%
0 - 255 PROGRAM SPEED SLOW - FAST
STROBING
51
0 - 255 SLOW - FAST
DIMMER CURVES
0 - 41 STANDARD
42 - 84 STAGE
52 85 - 127 TV
128 - 170 ARCHITECTURAL
171 - 213 THEATER
214 - 255 DEFAULT TO UNIT CURVE SETTING
PROGRAM DIMMING
53
0 - 255 DIMMING 0% - 100%
20
FUNCTION
