ADTRAN Express L1.5 Specifications

P R O D U C T F E A T U R E S
HDSL remote access at 1.5 Mbps
RFC 1490 Frame Relay encapsula-
tion for virtual dedicated access
IP and IPX routing
Concurrent bridging
Internet and central site LAN
access via Frame Relay
Campus connectivity
Frame Relay or PPP mode
Six levels of security
NIC/HUB switch eliminates
need for cross-over cables
SNMP management
Extensive logs provide opera-
tional feedback
PAP, CHAP, EAP, Radius,
Caller-ID, password protection
Five-year warranty
EXPRESS L1.5
H D S L C A M P U S C O N N E C T I V I T Y
The ADTRAN Express L1.5 is an HDSL bridge/router that connects LAN
segments or provides remote access to a computer or network over two
twisted pairs of copper. The ADTRAN Express L1.5 is designed to work
back-to-back as a cost-effective LAN extension device.
The Express L1.5 provides a cost-effective campus connectivity solution.
When used in a leased copper setting, the Express L1.5 delivers 1.536 Mbps
bi-directionally over two twisted pairs of copper. The Express L1.5 is also
capable of transmitting at sub-rates ranging from 128 kbps to 1.536 Mbps.
This solution can be used to extend a LAN or provide remote access to a
single user or LAN segment. When used in the sub-rate mode, the Express
L1.5 can be used with a single pair of twisted copper.
Six levels of security in the Express L1.5 provide a wide selection of secu-
rity options. Network Address Translation (NAT) allows a single IP address
to be downloaded through Dynamic Host Configuration Protocol (DHCP)
to the Express L1.5. Up to ten users can have a private IP network address
downloaded from the L1.5.
The Express L1.5 can route IP and IPX packets and bridge all other pro-
tocols. Routing and bridging can be performed independently or concur-
rently. The Express L1.5 can operate in the Frame Relay mode providing up
to ten PVCs or in a PPP mode over the LAN.
Five LEDs provide constant feedback about the L1.5's operation. A
unique slide switch on the rear panel eliminates the need for separate
cables when connecting to a HUB or NIC card. Extensive logs are provided
to monitor the operation of the Express L1.5.
Telnet, SNMP, and a serial EIA-232 port provide multiple methods of
configuration and management.
