Installing the SDP Board Drivers
After the AD7606
complete, the ADI SDP Drivers Setup wizard window opens
for the installation of the
1. The ADI SDP Drivers Setup Wizard opens. Click Next to
begin the driver installation process (see Figure 6).
Figure 6. Setup Wizard Welcome Window
2. Select a destination folder for the SDP drivers and click
Install (see Figure 7).
Figure 7. Choose Install Location Window
3. Click Install again to proceed with the installation (see
Figure 8).
Figure 8. Windows Security Dialog Box
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
evaluation board software installation is
EVAL-SDP-CB1Z SDP board drivers.
4. When the SDP drivers installation completes, click Finish
(see Figure 9).
Figure 9. Completion of Installation Window
After the evaluation software installation is complete, connect the
EVAL-AD7605-4SDZ/EVAL-AD7606SDZ/EVAL-AD7606-6SDZ/
EVAL-AD7606-4SDZ/EVAL-AD7607SDZ/EVAL-AD7608SDZ
evaluation board to the
in the Evaluation Board Hardware section.
When first plugging in the
the USB cable provided, allow the Found Hardware Wizard
to run. After the drivers are installed, check that the evaluation
board is connected correctly by looking at the Device Manager
of the PC. The Device Manager can be found by right-clicking
My Computer > Manage > Device Manager from the list of
System Tools.
The EVAL-SDP-CB1Z
Development Tools, shown in Figure 10.
Rev. A | Page 7 of 15
EVAL-SDP-CB1Z SDP board as described
EVAL-SDP-CB1Z SDP board via
SDP board appears under ADI
Figure 10. Device Manager
UG-851
