Introduction:

1. When setting up Profort multiGuard units outside Denmark, special handling is
required which at certain points differs from normal national (DK) setup.
2. The telephone selection number must always start with a +, for example
+46(0)xxxxxxxx (zero is omitted) for Sweden.
3. The startup procedure can be performed either at Step 1.1: sms/short
message -> device or Step 1.2: PC web-portal
device.

Prerequisites:

1. The mobile system must be type 2G (GSM) or 3G (UMTS) with mobile data. SIM
cards must also be able to send / receive sms messages.
2. The signal strength is checked by sending a sms with OK. The return value
must be at least 30% at 2G and minimum 20% at 3G.
Global overview of Telephone-pre-dialing numbers
Contents
Introduction: .................................................................................................. - 1 -
Prerequisites: ................................................................................................. - 1 -
Step 1.1 - Mobile Phone -> Device: ................................................................... - 2 -
Step 1.2 - Web software www.setup.masterview.dk-> device: ............................. - 3 -
Step 2 - Web server <-> device: ...................................................................... - 5 -
Step 3 - Test data connection to the device: ...................................................... - 6 -
File:
Web opsætning af multiGuard ekstern GB
How to start up
a Profort multiGuard unit outside Denmark
www.setup.masterview.dk
KAP side:
dato: 03. marts 2021
->
- 1 - af 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the multiGuard Master IO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Profort multiGuard Master IO

Summary of Contents for Profort multiGuard Master IO

  • Page 1 Profort multiGuard unit outside Denmark Introduction: 1. When setting up Profort multiGuard units outside Denmark, special handling is required which at certain points differs from normal national (DK) setup. 2. The telephone selection number must always start with a +, for example +46(0)xxxxxxxx (zero is omitted) for Sweden.
  • Page 2 = device username and yyyyyyyy = device mobile number without preset countries self-dialing codes. Profort recommends using the same username as the mobile phone number. The instruction enables Internet access with EH User name and creates N0 own number.
  • Page 3 Step 1.2 - Web software www.setup.masterview.dk-> device: 1. Press Create new 2. Select device 3. Enter mobile number with the preset country code indication + 4. Enter Description 5. Enter the APN *) for the SIM card 6. If required by the mobile operator, submit APN User *) 7.
  • Page 4 *): You can google the 'term' APN to find the correct APN, user & password in your location. The website apnchanger.org is a great help here, alternatively ask the SIM card provider directly. eg. Lycamobile Sweden - 4 - af 6 File: KAP side: Web programming international GB...
  • Page 5 Step 2 - Web server <-> device: 1. If working from Step 1.1 - Open in any browser, web server www.setup.masterview.dk 2. Select language DK or GB by pressing the flag in the upper right corner. 3. Press Control Units 4.
  • Page 6 4. The issued command is sent to the device as Data (blue) 5. The device is now operating on data  6. Continued programming of device from here by pressing Setup Go enjoy and thank you for choosing Profort Own notes: ______________________________________________________________...
