INSTRUCTION MANUAL
Vacuum Cleaner
MCS1825GB Pro
PLEASE READ THE
MANUAL CAREFULLY
BEFORE USING AND
KEEP IT PROPERLY
FOR FUTURE USE
Warning notices: Before
using this product, please
read this manual carefullly
and keep it for future
reference.
The design and
specifications are subject to
change without prior notice
for product improvement.
Consult with your dealer or
manufacturer for details.
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MCS1825GB Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Midea MCS1825GB Pro

Summary of Contents for Midea MCS1825GB Pro

  • Page 1 INSTRUCTION MANUAL Vacuum Cleaner MCS1825GB Pro PLEASE READ THE MANUAL CAREFULLY BEFORE USING AND KEEP IT PROPERLY FOR FUTURE USE Warning notices: Before using this product, please read this manual carefullly and keep it for future reference. The design and specifications are subject to...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions invalidates the given warranty. • This appliance complies with international safety standards. • Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS • Use the appliance only with the power adapter supplied. • Do not use the appliance without filters fitted, otherwise it can get damaged. • If you keep the packaging materials, store them out of the reach of children.

  • Page 5: Product Overview

    PRODUCT OVERVIEW Floor head wall bracket Adaptor/charger Combination nozzle Extension tube Wall fixings Crevice nozzle Part identification Accessory attachment point Collection container lid Dust release button Dust container release button Battery indicator light Low/high mode button Power on/off button Handle Filter cover 10 Motor filter 11 Mounting Recess...

  • Page 6: Operation

    Operation Charging the Vacuum This vacuum uses a rechargeable 25.2V Lithium battery. We recommend to fully charge before using for the first time. It takes 3-5 hours. 1. Place the body of the cleaner onto a flat surface either a table or fit into the wall bracket.

  • Page 7: Assembling Your Vacuum

    Operation Assembling your vacuum Bringing it all together Safety • Before drilling into wall surface, check for hidden cables or pipes. • Wear safety goggles and dust mask when drilling. • The use of a residual current device (RCD) is recommended when working with power tools.
  • Page 8 Operation 2. Place the bracket in the desired position and using a pencil, mark the position for the two screw holes. Using a ruler, draw a line joining the points marked for the two screws and using a spirit level, check that it is on the same level.
  • Page 9 Operation Assembly 1. Insert the extension tube onto the body of the vacuum as shown (fig. 8) and push to secure, a click will be heard. 2. Push fit the floor head onto the etexnsion tube (fig. 8), a click will be heard.

  • Page 10: Getting Started

    Operation Fig. 9 4. To remove the all parts press the release button and accessories firmly pull apart. Getting started 1. Fit the correct nozzle for the cleaning application, ensure that the battery has sufficient charge. Power button 2. Click power button once to start, the Low/High button LED lights on the floor head (if fitted) Low/High indicator lights*...

  • Page 11: Maintenance

    MAINTENANCE Maintenance Disconnect the charger from the vacuum cleaner before carrying out cleaning and maintenance. To ensure your vacuum cleaner works at optimum efficiency, keep the ventilation holes and vacuum cleaner surface free from dirt. Ensure that the dust container is emptied and the air filters are washed regularly.

  • Page 12: Cleaning The Filters

    MAINTENANCE Cleaning the filters 1. The frequency that the filters should be cleaned will depend on appliance usage. For maximum efficiency the filter within the dust container should be cleaned every time the dust container is emptied and the exhaust filter at the top every three months. 2.
  • Page 13 MAINTENANCE 4. Tap the filter against a dustbin to remove most of the dust and then wash the filter in cold running water until the water runs clear. Allow to air dry fully. Using a damp or wet filter will reduce the suction and damage the motor.

  • Page 14: Cleaning The Brush

    MAINTENANCE Cleaning the brush 1. The frequency that the brush should be cleaned will depend on appliance usage. Always stop the vacuum and clean the brush head if the indicators turn white or if the floor head brush stops rotating. 2.

  • Page 15: Technical Data

    TECHNICAL DATA Motor Power: 350W Adaptor Input: 100-240V~ 50-60Hz 0.5A 25.0V 0.5A 12.5W Output: 29.0V 0.5A 14.5W Battery Type: 25.2V, 2000mAh, Li-ion battery Charging Time: 3-5 hours Dust Bin Volume: 0.65L Running T Max Power Mode: 20mins Min Power Mode: 60mins Follow the instructions by paying attention to all the information and warnings in the user manual.

  • Page 16: Troubleshooting

    TROUBLESHOOTING Common failure Possible cause Solutions Product has powered off or Please charge the product battery is low before use The vacuum doesn’t work Cleaning product suction Product suction port is blocked mouth Dust barrel & filter assembly is Clean the dustbin and filter dusty/full material Rolling brush is wrapped...
