Movement IDEA EXTENSOR FLEXOR Owner's Manual page 71

5
ASSEMBLY
STEP 13
2
NAME
Flat washer - M8
NAME
N2
Pulley support with encoder
21
N1
TOOLS
Screw threader
Allen n° 6 medium torque
17
Qty NAME
2x
Screw Hex. Socket Cyl. Head
M8X25
P1
Hole
2 2
N2
Board
100%
Qty
2
17
DANGER!
Encoder board should be facing to
the user as picture above
24
NAME
N1
2x
Pulley support
NOTE
The support of the pulley with encoder
accompanies only the IDEA PLUS line
The pulley support should
be mounted in the holes in
highlights as shown
DANGER!
in figure 1
