PARTS DESCRIPTION (FIG A.) ...................................................... 3
2
PACKAGE CONTENT LIST ............................................................. 3
3
SYMBOLS MARKED ON THE PRODUCT ...................................... 3
4
GENERAL SAFETY RULES ............................................................ 4
5
ASSEMBLY ...................................................................................... 6
5.1
Folding handle ........................................................................................................ 6
5.2
Mounting and dismounting the grass bag ............................................................. 6
5.3
Starter handle .......................................................................................................... 6
5.4
Height of cut ............................................................................................................ 7
6
"1" Mowing with the grass catch box .................................................................... 7
6.1
"2" convert to mulching mower ............................................................................ 7
6.2
6.2.1
Mounting mulching wedge ......................................................................................... 7
"3" convert to side-discharge mower ................................................................... 8
6.3
6.4
return to normal mower .......................................................................................... 8
7
OPERATING INSTRUCTIONS ........................................................ 9
7.1
Before starting ........................................................................................................ 9
7.2
To start engine and engage blade .......................................................................... 9
7.3
Operation procedures ............................................................................................. 9
7.4
To stop engine ...................................................................................................... 10
7.5
Connection for auto move .................................................................................... 10
7.6
For the best results when mulching (pow xg6010 only) ..................................... 10
7.7
Grass collect bag .................................................................................................. 11
7.8
Deck ....................................................................................................................... 11
7.9
Height adjustment instructions ............................................................................ 11
8
MAINTENANCE INSTRUCTIONS ................................................. 11
9
LUBRICATION INSTRUCTIONS ................................................... 12
10
CLEANING ..................................................................................... 12
10.1
Engine air cleaner ................................................................................................. 12
10.2
Cutting blade ......................................................................................................... 13
Copyright © 2010 VARO
POWXG6010
P a g e
| 1
EN
www.varo.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Powerplus GARDENPRO POWXG6010
Summary of Contents for Powerplus GARDENPRO POWXG6010
-
Page 1: Table Of Contents
POWXG6010 PARTS DESCRIPTION (FIG A.) ............3 PACKAGE CONTENT LIST ............. 3 SYMBOLS MARKED ON THE PRODUCT ........3 GENERAL SAFETY RULES ............4 ASSEMBLY ..................6 Folding handle ......................6 Mounting and dismounting the grass bag ............. 6 Starter handle ......................6 Height of cut ...................... - Page 2 POWXG6010 10.3 Blade mounting torque ..................13 10.4 Engine ........................13 STORAGE INSTRUCTIONS (OFF SEASON) ....... 14 TECHNICAL DATA ................ 14 TROUBLE SHOOTING ..............15 WARRANTY ................... 16 ENVIRONMENT ................16 DECLARATION OF CONFORMITY ..........17 Copyright © 2010 VARO www.varo.com P a g e...
-
Page 3: Parts Description (Fig A.)
POWXG6010 SELF TRACKTING GASOLINE LAWN MOWER 6,0HP POWXG6010 WARNING ! For your own safety please read this manual before attempting to operate your new unit. Failure to follow instructions can result in serious personal injury. Spend a few moments to familiarize yourself with your mower before each use. -
Page 4: General Safety Rules
POWXG6010 Fuel is flammable, keep Pay more attention to the fire away. Do not use this operator's hands and feet machine on slopes to avoid injury. greater than 16,7° Toxic fumes! Don't Wear hearing protection. operate inside house. Wear eye protection When repairing, please take out the spark plug. - Page 5 POWXG6010 Make sure the area to be mowed is cleared of sticks, stones, bones, wire and debris. They could be thrown by the blades. Store fuel in a cool place in a container specifically designed for that purpose. Handle fuel carefully.
-
Page 6: Assembly
POWXG6010 5 ASSEMBLY Folding handle Fig 1a Fig 1b Insert the nether railings into the holes of unit body. (Fig. 1a) Lift the locking lever to release the handle bars for folding.(Fig. 1b) Push the locking lever closed to lock the handle bars in the operating position. ... -
Page 7: Height Of Cut
POWXG6010 Height of cut Apply outward pressure to disengage lever from rack. Move lever forward or back to adjust height. (Fig. 4) Fig 4 6 “3 IN 1” “1” Mowing with the grass catch box For mowing with the grass catch box : ... -
Page 8: 3" Convert To Side-Discharge Mower
POWXG6010 Fig 5A Fig 5B Lift the discharge flap and remove the grass collect box. Push the mulching wedge into the discharge channel.( Fig 5A). Lock the mulching wedge with housing. (the nose on the bottom side of the mulching wedge grip must snap into the opening in the housing. -
Page 9: Operating Instructions
POWXG6010 Make sure the motor stopped and blade has come to a complete stillstand!! Lift the side flap and remove the side discharge channel. The side flap is automatically closed by a spring. 7 OPERATING INSTRUCTIONS Before starting Service the engine with EU95 or 98 and oil as instructed in the separate engine manual packed in your mower. -
Page 10: To Stop Engine
POWXG6010 To stop engine CAUTION: The blade continues to rotate for a few seconds after the engine is shut off. Release the brake control handle to stop the engine and blade. Disconnect and ground the spark plug wire as instructed in the separate engine manual to prevent accidental starting while equipment is unattended. -
Page 11: Grass Collect Bag
POWXG6010 Grass collect bag Empty and clean the bag, make sure it is clean and ensure its meshwork is ventilated. (Fig. 8) fig 8 Deck The underside of the mower deck should be cleaned after each use to prevent a buildup of grass clippings, leaves, dirt or other matter. -
Page 12: Lubrication Instructions
POWXG6010 CAUTION: Do not over-tighten the spark plug as engine damage may occur. 9 LUBRICATION INSTRUCTIONS CAUTION: Disconnect spark plug wire before servicing. WHEELS-Lubricate the ball bearings in each wheel at least once a season with a light oil. ENGINE-Follow engine manual for lubrication instructions. BLADE CONTROL-Lubricate the pivot points on the blade control handle and the brake cable at least once a season with light oil. -
Page 13: Cutting Blade
POWXG6010 10.2 Cutting blade CAUTION: Be sure to disconnect and ground the spark plug wire before working on the cutting blade to prevent accidental engine starting. Protect hands by using heavy gloves or a rag to grasp the cutting blades. Tip mower : When the mower is tipped over onto its side, please take care that the air cleaner is on the top... -
Page 14: Storage Instructions (Off Season)
POWXG6010 Maintain engine oil as instructed in the separate engine manual packed with your unit. Read and follow instructions carefully. Service air cleaner as per separate engine manual under normal conditions. Clean every few hours under extremely dusty conditions. Poor engine performance and flooding usually indicates that the air cleaner should be serviced. -
Page 15: Trouble Shooting
POWXG6010 Level 7 61mm Level 8 67mm Level 9 73mm Level 10 80mm Fuel Consumption 431g/Kw.h Noise emission values measured according to relevant standard. LwA (Sound Power level) 98 dB(A) K=3 LpA (Sound Pressure Level) 84 dB(A) K=3 Measured Vibration 4.93 m/s²... -
Page 16: Warranty
POWXG6010 PROBLEM PROBABLE CAUSE CORRECTIVE ACTION Cooling fins and air passages Remove debris from cooling fins under engine blower housing are and air passages. blocked. Engine skips at high Gap between electrodes of spark Set gap between electrodes at 0.6 speed. -
Page 17: Declaration Of Conformity
VARO N.V. - Joseph Van Instraat 9 - BE2500 Lier - BELGIUM, declares that, product : Gasoline Lawnmower 6HP trade mark : POWERplus model : POWXG6010 is in conformity with the essential requirements and other relevant provisions of the applicable European Directives, based on the application of European harmonized standards.
