Casio G'zOne Commando User Manual page 17

5.
Press down firmly on all sides of the battery
cover at each arrow point, as shown in the right
figure.
6.
Slide the Battery Cover Lock to the right to
the LOCK position, as shown in the
figure.
Warning!
• Do not twist the battery cover as shown in the
right figure. Doing so can damage the
phone and the battery cover.
• Do not press hard on the battery cover
if the tabs are not properly inserted into the slots of the phone.
Doing this may cause damage to the battery cover tabs.
• Be careful not to get the tab of the battery caught between the
edges of the battery cover and the phone. Failure of proper
battery installation will result in the loss of water resistance.
• If you are using a wrist strap (sold separately), be careful not to
get it caught between the battery cover and the phone. Failure of
proper battery installation will result in the loss of water resistance.
• Do not leave the removed battery in direct sunlight, or near heat
sources such as an open flame or stove. Doing this may cause
phone malfunction or cause a fire by the battery bursting or
igniting. Do not hit, or exert excessive shock on the battery, as it
may ignite or break.
15
