Assemble the Wheel Carriage

Assemble the Wheel Carriage
Required Parts:
• Kit 3
• Scrap Wood Board
• 9/16" Socket Wrench or Wrench
• Mallet
C
PREPARE THE BASE FOR THE WHEELS
1. Attach the u-bracket (17) to the
cross member (21) using the
bolts (25), washers (33), and
nuts (30).
IMPORTANT
NOTE THE ORIENTATION OF THE
BRACKET.
Completed Wheel Carriage Assembly:
#30
18
#25
#33
#17
#21
