Tools & Materials for Assembly
STADIUM PAD ASSEMBLY
#68
#67
48 Label, Height Indicator (x1)
68 Stadium Pad, Top (x1)
KIT 8 – BOARD PAD HARDWARE – AC00002
#29
29 Bolt, Carriage, 3/8-16x2.75L (x10)
Tools & Materials for Assembly
2 Capable Adults
Phillips
Tape Measure Screwdriver
#3
57 Label, Height Adjustment and Moving (x1)
69 Ground Stake (x1)
30 Nut, Hex-Flange, 3/8-16 (x10)
Bolt, Carriage, 3/8-16 x 2-3/4
206011
Mallet Safety Glasses
Sawhorse Step Ladder (8 ft.) Scrap Wood Board Sand/Garden Hose
#69
#48
#30
Socket Wrench Socket Wrench
1/2", 9/16", 3/4"
10
HEIGHT
ADJUSTMENT
#57
Rotate crank
handle to raise
and lower
backboard.
Do not over crank
handle beyond the
manufactured height
indicator range of
7-1/2 - 10 feet.
Damage may be
caused to the screw
B
jack's internal
adjustment
mechanism if
adjusted over 10 or
under 7-1/2 feet.
MOVING SYSTEM
1. Adjust basketball backboard height to
lowest postion.
2. Rotate handle forward until wheels
engage ground.
3. Move basketball system to desired location.
4. Rotate handle back to original position.
5. Check system for stability.
1
3 2
574090 12/06
LABEL AS APPROVED BY HUFFY SPORTS ENGINEERING
FOR OUTDOOR APPLICATION
67 Stadium Pad, Bottom (x1)
203041
NUT, HEX FLANGE, 3/ 8- 16
Wrench
Extension 1/2", 9/16", 3/4"
(OPTIONAL)
Adjustable
Wrenches
A
2-5/8" Wide x 7-1/8" Long
