U-Line H-6991 Quick Start Manual page 2

3. Align armrest mounting bracket with holes on seat
cushion and use four bolts with washers to attach.
Insert armrest into mounting bracket and use armrest
knob to secure. Repeat on opposite side.
(See Figure 3)
Mounting
Bracket
Armrest Knob
Figure 3
4. Insert back cushion post into corresponding slot
in mechanism on bottom of seat. Tighten knob to
secure. (See Figure 4)
Figure 4
Back
Cushion
Post
PAGE 2 OF 9
ASSEMBLY CONTINUED
Bolts
Armrest
Seat
Knob
5. Slide footring onto the gas lift and tighten knob to
secure. (See Figure 5)
Figure 5
Footring
Gas Lift
6. Slowly lower stool assembly onto the gas lift. Press
down on seat to secure. (See Figure 6)
Figure 6
Stool
Assembly
Gas Lift
Knob
0621 IH-6991
