Crestron UC-CAM-UPGRD-300 Quick Start

UC-CAM-UPGRD-300
Camera Upgrade Solution for CCS-UC-1-AV W/PS
The UC-CAM-UPGRD-300 upgrades the CCS-CAM-USB-F-100 Logitech® C930e webcam
that is included with the CCS-UC-1-AV W/PS to the CCS-CAM-USB-F-300 Huddly™ GO
collaboration camera.
NOTE: This upgrade solution can be used to replace any CCS-CAM-USB-F-100 that is
connected to a Crestron Mercury® UC Tabletop Conference System.
The kit includes the camera, a UC-CAM-WMK wall mount kit, and a UC-HUB-USB 4-Port
USB 3.0 Hub with 2A USB Power Adapter to ensure the camera receives sufficient power.

Check the Box

Item
UC-CAM-UPGRD-300
CCS-CAM-USB-F-300 Huddly GO Collaboration Camera (P/N 6510481)
UC-CAM-WMK Wall Mount Kit for Crestron® Cameras (P/N 6510998)
UC-HUB-USB 4-Port USB 3.0 Hub with 2A USB Power Adapter (P/N 6510546)

Install the UC-CAM-WMK Wall Mount Kit

Install the UC-CAM-WMK wall mount kit as described in the quickstart guide that is included
with the UC-CAM-WMK (Doc. 8257). The quickstart can also be found at
manuals.

Connect the Device

Connect the camera and hub as shown in the following diagram.
NOTE: Other connections to the CCS-UC-1 are not shown for clarity.
CCS-UC-1
Qty
1. Connect the USB port on the CCS-CAM-USB-F-300 to a USB port on the
1
UC-HUB-USB with the USB cable included with the camera.
1 2. Connect the UC-HUB-USB to the USB/CAM port on the CCS-UC-1.
3. Connect the USB power adapter included with the UC-HUB-USB to the micro-USB
1
port on the UC-HUB-USB and an AC receptacle.
1

Additional Information

Scan or click the QR code for detailed product information.
crestron.com/
UC-CAM-UPGRD-300
CCS-CAM-USB-F-300
UC-HUB-USB
