Omcan MS-IT-0370-H Instruction Manual page 20

Parts Breakdown
Model MS-IT-0370-H
Item No. Description
16900 Sharpening Assembly for 38915
Ring EL.Benzing 6 Stainless Steel for
36536
38915
16902 Ring EL.Benzing 8 for 38915
17281 Ring EL.Seeger Ext.25 for 38915
Ring EL.Seeger Est.25 Ser.Heavy for
77585
38915
19484 Ring 52 for 38915
19612 Ring 33 for 38915
17283 Oil Seal 25x52x10 for 38915
77601 Oil Seal OR 2010 for 38915
17287 O-Ring 123 17.86x2.62 for 38915
77602 O-Ring OR 4500 for 38915
77547 Pin Stop Ring for 38915
77502 Shaft Sealing Ring Ø98x42 for 38915
36546 Carriage Rod for 38915
77548 Tray Rod for 38915
77533 Quadra Bar for 38915
36548 Shock Absorber Bar 12x170 for 38915
77549 Plate Rod for 38915
19508 Carriage Rod for 38915
79260 Body for 38915
16904 Bushing Sharpener for 38915
16905 Bushing DU 16x18x15 for 38915
17304 Bushing for 38915
17305 Bushing DU 18x20x15 for 38915
19514 Bushing Guard A310 for 38915
16906 Bush Sharpening for 38915
16907 Bush Sharpening for 38915
17307 Bushing Sharp for 38915
19630 Bushing Fastener for 38915
78265 Bushing Funnel for 38915
77550 Bushing DU 10x12x10 for 38915
Bushing Fastener Guard Knife A310A
77588
for 38915
17312 Bushing 22x25x20 for 38915
36563 Carriage Bushing for 38915
Bushing for Carriage Support lg.23mm
36564
for 38915
38915
Position Item No. Description
Bushing to Hold Carriage Springs for
A1026 36566
38915
A5404X 36567 Bushing DU 12x14x25 for 38915
A5406 77551 Bushing for Plate Ø16x19 for 38915
A5453 36569 Fixing Lever Bushing for 38915
A5454 17313 Bushing DU 14x15x16 for 38915
A5485 23646 Sharpener Pivot Ferrule for 38915
A5495 77552 Bushing for Plate for 38915
A5809 17303 Bushing DU 12x14x15 for 38915
A5848 77553 Pusher Arm for 38915
A5852 77554 Pusher Arm Assembly for 38915
A5857 77518 Sharpener Cover for 38915
A5921 36591 Carriage Support for 38915
A5946 65141 Flat Cart for 38915
B1024 77534 Cart Assembly for 38915
B1038 77605 Assy Wiring 6 Poles LG.400 for 38915
B1081 79263 Contact Pin for 38915
B1251 36601 Rivet 1.9x5 for 38915
B1258 36607 Blade Cover Bolt Keeper 14x14 for 38915
B1376 36609 Capacitor 20µF 250V for 38915
B1808 20458 Capacitor 20uF for 38915
B6048 74403 Connector Faston 2 Poles Male for 38915
B6053 77611 P.C.B. Cover Box for 38915
Cover Anter.Motor H (Diam.135) for
B6056 36614
38915
B6057 36615 Back Motor Cover for 38915
B6061 36617 Motor Fan Cover for 38915
B6075 19534 Housing Sharpener H for 38915
B6076 19536 Rack for 38915
B6083 17334 Bearing 2Z-6205 25x52x15 for 38915
B6104B 16925 Bearing 2RS-6204 20x47x14 for 38915
B6110 36630 Bearing 5x16x6.5 for 38915
B6111 36631 Bearing 2RS-6205 25x52x15 for 38915
B6140 16926 Bearing 2RS-6000 (10x26x8) for 38915
B6211 60423 Touch Pad Gasket for 38915
B6213 19637 Nut M3 for 38915
B6214 77504 Stainless Steel Nut U5587 M4 for 38915
Position Item No.
B6221 77612
B6222 77535
B6231 16928
B6239 19639
B6244 36638
B6256 77508
B6332 19646
B6336 66365
B7825 19642
B7919 36643
C1616 36646
C185404 36647
C1885 36648
C1904 36649
C3236 36651
C3352 79264
C4640 77506
C5007 19648
C5814 77556
C5815 36656
C6010 17341
C644680 36661
C6464 36665
C6466 77519
C6573 77557
C6807 65168
C7244 36677
C8011 77590
C8024 77558
C8035 19564
C8056 36680
C8067 77614
C8242 36682
D0101 77591
D0102X 17349
20
Description Position
Self-Locking Nut M3 UNI7473 for 38915 D0110
Special Nut M10 for 38915 D0116
Nut U5589 M6 for 38915 D0133
Nut M8 for 38915 D0135
Nut U5589 M10 Stainless Steel for
D0137X
38915
Stainless Steel Nut U5588 M12 for
D014215
38915
Nut U5588 M16 Stainless Steel for
D0144X
38915
Domed Nut DIN 917 M8 Stainless Steel
D014515
for 38915
Nut M8 for 38915 D0155X
Nut U5588 M5 for 38915 D0160
Nut U5588 M6 Stainless Steel for 38915 D0163X
Nut U5588 M8 for 38915 D0165
Nut U5588 M8 for 38915 D0165X
Nut U5588 M10 Stainless Steel for
D0167X
38915
Sharpener Support Nut for 38915 D0183
Blade Support Screw for 38915 D5454
Spacer Ø22x22 for 38915 D5465
Knife Spacer for 38915 D5602
Right Spacer INT90 for 38915 D5624
Motor Spacer for 38915 D5640
Spacer D.10.5x14 H.9 for 38915 D5643
Carriage Shock Absorber Spacer for
D5762
38915
Locknut Spacer for 38915 D577018
Spacer Eccentrico for 38915 D577141
Spacer Supp.Bar Post. for 38915 D5834
Eccentric Cusc. Cart lg.43 for 38915 E145801
Cam Pin for 38915 E1460
Cam for Sharpener for 38915 E1461
Eccentric for 38915 E1471
Metal Cam 25mm (Old Style) for 38915 E1474
Carriage Felt for 38915 F1606
Nylon Cable Tie (Diam.45x200) for
F2815
38915
Unhook Friction Clasp 12x22x8 for
F3015
38915
Support Blade Flange for 38915 F6039
Handle Flange for 38915 F609076
