16
en | Installing
4.3
Opening the case
Notice!
i
To open the controller, first remove all pluggable connectors.
The controller's case consists of a top cover mounted with a two-point snap-in closure on a
chassis. To open the case, push down the two snap-ins with a screwdriver, then swing the
cover down.
Figure 4.3: Opening the controller´s case
2021-04 | V04 | IM
Installation manual
Access Modular Controller 2
Bosch Security Systems B.V.
