32
en | Installing
4.14
Tamper protection
To protect the AMC2 against unauthorized access and so prevent tampering with sensitive
data, the AMC2 provides an additional interface to connect external tamper contacts. This
interface is a potential-free 2-pin pluggable screw connector marked with T. When not in use
this tamper contact should be shorted.
Figure 4.22: Location of the tamper protection contact
2021-04 | V04 | IM
Installation manual
Access Modular Controller 2
Bosch Security Systems B.V.
