Friedrich PTAC ZONEAIRE PREMIER Service & Parts Manual page 116

PDE07K, PDE07R, PDE09K, PDE09R, PDE12K, PDE12R, PDE15K, PDE15R
ITEM PART PART DESCRIPTION
NUMBER
67 69700444 Capacitor CBB61S
68 69700442 Capacitor CBB61
68 69700449 Capacitor CBB61
68 69700444 Capacitor CBB61
68 69700443 Capacitor CBB61
69 68700156 Terminal Board
70 68700157 Radiator
71 69700451 Fuse
71 69700452 Fuse
72 68700155 Wiring Terminal
73 68700154 Wiring Terminal
74 69700450 Pwer cord
74 69700453 Pwer cord
74 69700454 Pwer cord
74 69700455 Pwer cord
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME
116
PARTS CATALOG
USED ON MODEL
PDE07R3SG, PDE09R3SG, PDE12R3SG, PDE15R5SG
PDE07K3SG, PDE09K3SG
PDE07R3SG, PDE07R3SG
PDE09K3SG, PDE09R3SG
PDE12R3SG, PDE12K3SG, PDE15K5SG, PDE15R5SG
PDE07K3SG, PDE07R3SG, PDE09K3SG, PDE09R3SG,
PDE12K3SG, PDE12R3SG, PDE15K5SG, PDE15R5SG
PDE07K3SG, PDE07R3SG, PDE09K3SG, PDE09R3SG,
PDE12K3SG, PDE12R3SG, PDE15K5SG, PDE15R5SG
PDE07K3SG, PDE09K3SG
PDE07R3SG, PDE09R3SG, PDE12K3SG, PDE12R3SG,
PDE15K5SG, PDE15R5SG
PDE07K3SG, PDE07R3SG, PDE09K3SG, PDE09R3SG,
PDE12K3SG, PDE12R3SG, PDE15K5SG, PDE15R5SG
PDE07K3SG, PDE07R3SG, PDE09K3SG, PDE09R3SG,
PDE12K3SG, PDE12R3SG, PDE15K5SG, PDE15R5SG
PDE07K3SG, PDE09K3SG, PDE12K3SG
PDE07R3SG, PDE09R3SG, PDE12R3SG
PDE15K5SG
PDE15R5SG
Figure 901
QTY
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
