Product Profile
DIGITAL PACKAGED TERMINAL AIR CONDITIONERS
Over 40 standard features
Exceptional energy effi ciency
Diamonblue anticorrosion treatment
Digital temperature display
Rated quietest by hotel guests
One touch operation
Quiet start/stop fan delay
Internal diagnostic program
Q U A L I T Y
Remote thermostat operation
Desk control ready
Ultraquiet air system
Antimicrobial air fi lters
Fits most ptac sleeves
5 Year limited warranty
Ships individually palletized
www.friedrich.com
HEAT PUMP
ELECTRIC HEAT
COOL ONLY
Advertisement
Table of Contents
Related Manuals for Friedrich PDE07K
Summary of Contents for Friedrich PDE07K
-
Page 1: Heat Pump
Internal diagnostic program Q U A L I T Y Remote thermostat operation Desk control ready Ultraquiet air system Antimicrobial air fi lters Fits most ptac sleeves 5 Year limited warranty Ships individually palletized www.friedrich.com HEAT PUMP ELECTRIC HEAT COOL ONLY... -
Page 2: Digital Control Features
30 seconds after the compressor. REMOTE THERMOSTAT Some applications require the use of a wall-mounted thermostat. All new Friedrich PTACs may be switched from OPERATION unit control to remote thermostat control easily without the need to order a special model or accessory kit. -
Page 3: General Product Features
High effi ciency rotary compressors are used on all Friedrich PTACs to maximize durability and effi ciency. The Friedrich PTAC features a 24V AC terminal for connection to an auxiliary fan that may be used to trans- AUXILIARY FAN READY fer air to adjoining rooms. -
Page 4: Chassis Specifications
Chassis Specifi cations PDE Series Chassis Specifi cations PDE07K P E R F O R M A N C E D A T A Cooling BTUh 7500/7300 Power (Watts) 615/598 12.2 Dehumidification Sensible Heat Ratio 0.76 E L E C T R I C A L D A T A... - Page 5 Cooling & Heating Performance PDE - Extended Cooling Performance BTUh 8820 8483 WATTS PDE07 AMPS 0.52 0.71 BTUh 10819 10405 WATTS PDE09 AMPS 0.51 BTUh 14112 13572 WATTS PDE12 AMPS 0.49 0.67 BTUh 17640 16965 WATTS 1288 1309 PDE15 AMPS 0.51 PDH - Extended Cooling Performance BTUh...
- Page 6 MINIMUM CIRCUIT AMPACITY 14.1 BRANCH CIRCUIT FUSE (AMPS) PTAC/PTHP Model Identifi cation Guide Series PD = Friedrich Digital PTAC System X = Accessory E = Cooling with or without electric heat H = Heat Pump with Auxiliary Heat NOMINAL CAPACITY...
-
Page 7: Installation
Installation Typical Wall Sleeve Installation (PDXWS) Lintel Us s ed To Support Main Studs Jack Stud No holes are permitted in th of the sleeve. (Ex cep tion: P Extended Wall Sleeve In stal la tion and Seal ant Locations (PXWE) Wall Sleeve Extension, 42"... -
Page 8: Accessory Installation
Accessory Installation Internal Drain Kit Location and Installation (PXDR10) Wall Sleeve Bottom F F oam m G Gasket Mo o unti i ng g Plate Tube Screw Screw 1/2" O.D. Tube " O.D Mounting Plate ing Plat Gasket Gask External Drain When using an external drain system, the con den sate is removed through either of two drain holes on the back of the wall sleeve. - Page 9 The basic unit shall not exceed 16" high x 42" wide. Overall depth of the unit from the rear of the Friedrich wall sleeve to the front of the decorative front cover shall not exceed 21 ¼". The unit shall be designed so that room intrusion may be as little as 7 ½".
- Page 10 Thermostat is hard wired and can be battery powered or unit powered. Features backlit display and multiple confi guration modes. For use on PD-series Friedrich PTACs only. REMOTE THERMOSTAT ESCUTCHEON KIT This kit contains ten escutcheons...
-
Page 11: Additional Accessories
PXSE sleeve extension attached to the room side of the sleeve to allow for the installation of a PD-Series Friedrich PTAC in a T-Series sleeve. LATERAL DUCT ADAPTER Attaches to the PTAC/PTHP unit and provides a transition to direct up to 35% of the total CFM to a secondary PDXDA room, either left or right of the unit. -
Page 12: Limited Warranty
For international warranty information, contact the Friedrich Air Conditioning Company - International Division. Reasonable proof must be presented to establish the original purchase date, otherwise the beginning date of this certificate will be considered to be our shipment date plus sixty days.
