8 LED Operator Option Fault Diagnostics

8 LED Operator Option Fault Diagnostics
◆
Error Code and Connection Messages
Fault/Error code text will appear on the LED Operator (JVOP-182) display to indicate a
specific fault. The fault codes in
and/or the LED Operator (JVOP-182) displays. For information on the fault codes not listed
in Table 9, refer to the drive technical manual.
When an LED Operator (JVOP-182) fault occurs, ensure that the communication cable is
properly connected to the LED Operator (JVOP-182) and it is not loose.
Contact your nearest Yaskawa representative or sales department if the cable appears to be
connect properly but still no message appears to indicate the error.
LED Operator
(JVOP-182)
Cause
Communication cable between the LED
Operator (JVOP-182) and the drive is not
properly connected.
Problem with the LED Operator (JVOP-182). Replace the LED Operator (JVOP-182).
Problem with the control circuit in the drive.
LED Operator
(JVOP-182)
Cause
Connector on the LED Operator (JVOP-
182) cable is loose or damaged.
Problem with the LED Operator (JVOP-
182).
Problem with the control circuit in the drive.
26 YASKAWA ELECTRIC TOBP C730600 35B YASKAWA AC Drive Option LED Operator Installation Manual
Table 9 are displayed on the LED operator built in the drive
Table 9 Fault/Error Code Displays
LED Operator
(Drive built-in)
<1>
• Cycle power to the drive.
• Replace the drive.
LED Operator
(Drive built-in)
<1>
• Cycle power to the drive.
• Replace the drive.
Description
LED Operator (JVOP-182) Communication Error 1
Occurs when the drive cannot communicate with the
LED Operator (JVOP-182) within 5 seconds after the
power is switched on.
Possible Solution
Remove the LED Operator (JVOP-182) and then
reconnect it again.
Description
LED Operator (JVOP-182) Communication Error 2
Occurs if the drive does not respond to the LED
Operator (JVOP-182) for over 2 seconds.
Possible Solution
Remove the LED Operator (JVOP-182) and then
reconnect it again.
Replace the LED Operator (JVOP-182).
