YASKAWA AC Drive 1000-Series Option Analog Monitor Installation Manual Type AO-A3 To properly use the product, read this manual thoroughly and retain for easy reference, inspection, and maintenance. Ensure the end user receives this manual. 安川インバータ 1000シリーズ オプション アナログモニタ 取扱説明書 形式 AO-A3 製品を安全にお使い頂くために,この取扱説明書を必ずお読みください。...
Page 2
Yaskawa. No patent liability is assumed with respect to the use of the information contained herein. Moreover, because Yaskawa is constantly striving to improve its high-quality products, the information contained in this manual is subject to change without notice.
The selection and application of Yaskawa products remain the responsibility of the equipment manufacturer or end user. Yaskawa accepts no responsibility for the way its products are incorporated into the final system design. Under no circumstances should any Yaskawa product be incorporated into any product or design as the exclusive or sole safety control.
Page 5
Indicates a hazardous situation, which, if not avoided, could result in death or serious injury. CAUTION Indicates a hazardous situation, which, if not avoided, could result in minor or moderate injury. NOTICE Indicates an equipment damage message. YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
Page 6
• When ordering new copies of the manual, contact a Yaskawa representative or the nearest Yaskawa sales office and provide the manual number shown on the front cover.
-10 to 10 Vdc non-isolated output voltage. ◆ Applicable Models The option can be used with the drive models in Table Table 1 Applicable Models Drive Series Drive Model Number A1000 All models L1000A All models YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
• A pair of diagonal cutting pliers. • A small file or medium-grit sandpaper. Note: Tools required to prepare option cables for wiring are not listed in this manual. YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
Figure 1 Analog Monitor AO-A3 Option Components ◆ Terminal Block TB1 V1 AC V2 AC Refer to Table 4 on page for details on TB1 terminal functions and signal levels. YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
Do not touch circuit boards while the power to the drive is on. Failure to comply could result in death or serious injury. YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
Page 11
Failure to comply may prevent proper operation and possibly damage equipment. Check wiring to ensure that all connections are correct after installing the option and connecting any other devices. Failure to comply may result in damage to the option. YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
Page 12
D – Digital operator J – Connector CN5-A E – Terminal cover K – Connector CN5-B F – Removable tabs for wire routing L – Connector CN5-C Figure 2 Drive Components with Option YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
Page 13
NOTICE: Damage to Equipment. Observe proper electrostatic discharge procedures (ESD) when handling the option, drive, and circuit boards. Failure to comply may result in ESD damage to circuitry. Figure 3 Figure 3 Remove the Front Covers and Digital Operator YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
Page 14
Insert the option card (B) into the CN5-A (J), CN5-B (K), or CN5-C (L) connector located on the drive and fasten it into place using one of the included screws (G). Figure 4 Figure 4 Insert the Option Card YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
Page 15
2. There are two screw holes on the drive for use as ground terminals (I). When connecting three options, two ground wires will need to share the same drive ground terminal. YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
Page 16
Loosen the screws and insert the wire into the Terminal block TB1 opening on the terminal block. To customer circuit (do not solder ends) Figure 7 Preparing and Connecting Cable Wiring YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
Page 17
Figure 8 Option Connection Diagram NOTICE: Do not adjust the potentiometers on the option. The potentiometers are factory set and may change the voltage output characteristics and cause output signal inaccuracy if misadjusted. YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
Page 18
Figure 9-B for drives that do not require routing through the front cover. Refer to the Peripheral Devices & Options section of the Yaskawa AC Drive Technical Manual for more information. Figure 9 A – Route wires through the openings B –...
Page 19
Note: Take proper precautions when wiring the option so that the front covers will easily fit back onto the drive. Make sure cables are not pinched between the front covers and the drive when replacing the covers. Set drive parameters in Table 5 for proper option performance. YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
Page 20
0.25 to 1.5 (24 to 16 AWG) Crimp Terminals ■ Yaskawa recommends using CRIMPFOX 6 by Phoenix Contact or equivalent to crimp the terminals with the specifications listed in Table 3 to ensure proper connections. Note: Properly trim wire ends so loose wire ends do not extend from the crimp terminals.
Terminal V2 Signal Level (398) Range: 0, 1 <1> The drive outputs voltage while this parameter is being adjusted. Voltage levels can be adjusted to match the specifications of an external meter. YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
Option connection error at drive port CN5-C Cause Possible Solution Option at drive port CN5-C was changed during Turn the power off and check the connectors between the drive run. and option. YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
Page 23
• Limit the length of wiring under 50 m (164 ft.). • Separate the control wiring to the option, main circuit wiring, and power lines. Interface Circuit ■ Figure 11 – V1, V2 Signal processor Figure 11 Output Interface Circuit YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
-20 °C to +60 °C (-4 °F to 140 °F) allowed for short-term transport of the product Storage Temperature Area of use Indoor (free of corrosive gas, airborne particles, etc.) Altitude 1000 m (3280 ft.) or lower YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
Page 25
Back cover Revision: Address Entire Document Edited for procedural clarity and readability. July 2010 Back cover Revision: Address May 2010 Back cover Revision: Address − − July 2008 First edition YASKAWA ELECTRIC TOBP C730600 40B 1000-Series Option AO-A3 Installation Manual...
Page 26
Phone: 81-3-5402-4502 Fax: 81-3-5402-4580 http://www.yaskawa.co.jp YASKAWA AMERICA, INC. 2121 Norman Drive South, Waukegan, IL 60085, U.S.A. Phone: (800) YASKAWA (927-5292) or 1-847-887-7000 Fax: 1-847-887-7310 http://www.yaskawa.com YASKAWA ELÉTRICO DO BRASIL LTDA. Avenda Fagundes Filho, 620 Bairro Saude, São Paulo, SP04304-000, Brasil Phone: 55-11-3585-1100 Fax: 55-11-5581-8795 http://www.yaskawa.com.br...
