Anritsu Spectrum Master MS2721A Maintenance Manual page 41

Part Number
905-2639P Screw, Pan, M3 x 6, Phillips, SS, PCH
905-2642P Screw, Pan, M3 x 12, Phillips, SS, PCHL
905-2633P Screw, Pan, M2 x 6, Phillips, SS, PCHL
905-2663 M3 x 0.5 KEP Nut
905-2684P Screw, M2 x 14 MM, 18-8 SS
905-2685 Screw, 4 MM, Phillips, SS, Shoulder
410-101 Encoder
58211 Cable Assembly, BNC-MCX
61370-1 Cable Assembly, 3IN, INV BD
61465 Cable, Ribbon
61466-1 100 MHZ Coax Cable
61466-2 37.8 MHZ Coax Cable
Part Number
ND64730 Case Replacement Kit, Aluminum to Plastic (see Appendix B)
64126 Top Case, Plastic
64127 Bottom Case, Plastic
61379-1 Battery Door, Plastic Case
61363-1 Keypad Bezel, Numeric, Plastic Case
61378-1 Function Key Bezel, Plastic Case
61360-1 Encoder Knob, Plastic Case
61368 LCD Protective Cover
61381 Fan Bracket
ND64383 Fan Assembly
800-473 Battery Cable, Connector
61463 ID Label, Model MS2721A
Spectrum Master MM
Hardware
Description
Case Parts
Description
Qty
16
4
14
4
47
2
1
1
1
1
1
1
Qty
1
1
1
1
1
1
1
1
1
1
1
1
37
