- Page 1 Operating Instructions XGS 116(w)/126(w)/136(w)
-
Page 2: Security Symbols
Operating Instructions Foreword We are pleased to welcome you as a new customer of our Sophos XGS appliances. To install and configure the hardware appliance you can use the following documents: Hardware Quick Start Guide: Connection to the system peripherals in a few steps... -
Page 3: Operating Elements And Connections
Operating Instructions CE Labeling, FCC and Approvals The XGS 116(w)/126(w)/136(w) appliance comply with CB, CE, UL, FCC Class B, ISED, VCCI, CCC, KC, BSMI, RCM, NOM, Anatel. Important Note: For computer systems to remain CE and FCC compliant, only CE and FCC compliant parts may be used. -
Page 4: Technical Specifications
Type Speed Comment 1–8 RJ45 10/100/1000 Mbps Port 8 on XGS 116(w) can be used to power a connected device (e.g. access point, IP camera, or IP Phone) via PoE with upto 30W (PoE 802.3at). 9–10 RJ45 100/1000 Mbps (XGS 126(w)/136(w) only) 11–12... -
Page 5: Led Status
UPS, 3G/4G dongles). Expansion Bay Comment 3G/4G Module Can be used for Sophos XGS 3G/4G Module, which is optionally available from your Sophos partner. WiFi Module Can be used for Sophos XGS WiFi Module, which is optionally available from your Sophos partner. -
Page 6: Putting Into Operation
The supplied parts are indicated in the Hardware Quick Start Guide. Mounting Instructions The XGS 116/126/136 appliance can be placed on a stable horizontal surface or can be mounted to a rack or you can hang it on the wall by using the optionally available rackmount kit. -
Page 7: Connection And Configuration
Library). Serial Console You can connect a serial console to either of the COM ports of the Sophos XGS hardware appliances. You can use, for instance, the Hyperterminal terminal program which is included with most versions of Microsoft Windows to log on to the appliance console. Use an RJ45 to DB9 adapter cable or the provided USB cable to connect the console to your hardware appliance. - Page 8 Registered in England and Wales No. 2096520, The Pentagon, Abingdon Science Park, Abingdon, OX14 3YP, UK Sophos is the registered trademark of Sophos Ltd. All other product and company names mentioned are trademarks or registered trademarks of their respective owners.
