Sophos XGS 116 Quick Start Manual

Sophos XGS 116 Quick Start Manual

Hide thumbs Also See for XGS 116:

Advertisement

Quick Links

Download this manual
Quick Start Guide
XGS 116(w)/126(w)/136(w)

Advertisement

loading
Need help?

Need help?

Do you have a question about the XGS 116 and is the answer not in the manual?

Questions and answers

Related Manuals for Sophos XGS 116

Summary of Contents for Sophos XGS 116

  • Page 1 Quick Start Guide XGS 116(w)/126(w)/136(w)
  • Page 2 ISP. 1. Before Deploying Congratulations on the purchase of your Sophos XGS appliance. This Quick Start Guide describes in short steps how to connect your appliance and explains how to open the web-based Admin Console from your administration PC.
  • Page 3 ENGLISH b) Appliance images: front and back XGS 116(w) XGS 126(w)/136(w) Status LEDs Status LEDs (w-model has (w-model has USB 2.0 additional WiFi LED) USB 2.0 additional WiFi LED) 1 x COM 1 x COM Micro USB Micro USB 2 x external antenna...
  • Page 4 Expansion Bay Comment Cellular Module Can be used for Sophos XGS 3G/4G or 4G/5G Module, which is optionally available from your Sophos partner. WiFi Module Can be used for Sophos XGS WiFi Module, which is optionally available from your Sophos partner.
  • Page 5 Default Gateway DHCP Service DHCP DHCP Enabled Mount the appliance to the rack If you want to mount the device within a rack please use the optionally available rackmount kit for this device. Quick Start Guide XGS 116(w)/126(w)/136(w)

  • Page 6: Power Up The Appliance

    Start the browser and enter the IP address of the appliance’s LAN port that your PC is connected to: https:/ /172.16.16.16:4444 Switch Login with the default details below: Username: admin Password: admin Internal network admin client PC Quick Start Guide XGS 116(w)/126(w)/136(w)
  • Page 7 Synchronize license Click ‘Initiate License Synchronization’ to get the license information from Sophos onto the appliance. After synchronization, you will see a screen with the message, “Synchronization with server was successful. ” Quick Start Guide...
  • Page 8 ENGLISH 6. Connecting PoE Powered Devices Ports 8 (on XGS 116(w) and 11/12 (on XGS 126(w)/136(w) are able to provide power over Ethernet (PoE) to a connected PoE device which conforms to the standards 802.3af (max. 15.4W) or 802.3at (max.
  • Page 9 WiFi is inactive. Power 1 Green Solid Power adapter 1 in normal operation. Solid Power adapter 1 failed or disconnected. Power 2 Green Solid Power adapter 2 in normal operation. Solid Power adapter 2 failed or disconnected. Quick Start Guide XGS 116(w)/126(w)/136(w)

  • Page 10: Support And Documentation

    For more information and technical support, please visit www.sophos.com/en-us/support or contact your local Sophos reseller. Check our Getting Started resources to find out how you can get the most out of your purchase www.sophos.com/get-started-firewall * The blinking behavior is an on/off cycle approx. once every 0.3 seconds.
  • Page 11 Registered in England and Wales No. 2096520, The Pentagon, Abingdon Science Park, Abingdon, OX14 3YP, UK Sophos is the registered trademark of Sophos Ltd. All other product and company names mentioned are trademarks or registered trademarks of their respective owners.
