2.1 Applications

Sverker 750/760 is intended primarily for testing
relay protection equipment, but it can also be used
for many other purposes. Virtually all single-phase
relay protection equipment that does not require
variable frequency can be tested, and Sverker 750/
760 can also test three-phase relay protection
equipment that can be tested phase by phase.
Moreover, many relay protection systems that
require phase shifting can be tested.
Items that can be tested using Sverker 750/760
include:
Type of relay
Overcurrent relay
Inverse time overcurrent relay
Undercurrent relay
Ground fault relay
Directional overcurrent relay
Directional ground fault relay
Overvoltage relay
Undervoltage relay
Directional voltage relay
Directional power relay
Power factor relay
Differential protection
(differential circuit)
Distance protection
equipment (phase by phase)
Negative sequence overcurrent
relay
Motor overload protection
Automatic reclosing devices
Tripping relays
Voltage regulating relay
Overimpedance relay
(Z greater than ...)
Underimpedance relay
(Z less than ...)
Thermal relay
Time-delay relay
Other applications
P r o g r a m m a E l e c t r i c A B
Z P - C D 0 1 E R 0 5 A

2 Introduction

IEEE standard
code
50/76
51
37
50
67
67N
59
27
91
32
55
87
21
46N
51/86
79
94
Plotting excitation curves
Current and voltage transformation ratio tests
Burden measurement for relay protection equip-
ment
Impedance measurement
Efficiency tests
Polarity (direction) tests
S V E R K E R 7 5 0 / 7 6 0
