AEM GDI Series Setup Manual

SETUP GUIDE
Supported Devices
CAN Bus Wiring
AEM CD has 2 separate CAN ports. For 3rd party devices, AEM recommends you use AEM CAN Bus 2, whose
connections are contained in a 2 pin Deutsch DTM connector. On older harnesses it may be in an unterminated,
twisted/shielded flying lead in the dash harness.
Life CAN High AEM CD "CAN 2" Pin 1 (CAN 2+), Gray wire in twisted/shielded pair
Life CAN Low AEM CD "CAN 2" Pin 2 (CAN 2-), Black wire in twisted/shielded pair
ECU Software Setup
The CD Dash supports the default Life Racing CAN output. However, some cal files may not have the CAN output
activated or may not support all the channels contained in the default setup. You must confirm the setup before
proceeding. To do this, start by opening the "Datastreams" group in the calibration and confirm the following
settings:
"Datastream Select" is set to "Custom CAN"
"CAN 1 BUS Speed" is set to 1MHZ
The "Frame Identifier" table contains these values for frames 1-18;
600h,601h,602h,603h,604h,605h,606h,607h,608h,609h,60ah,60bh,60ch,60dh,60eh,60fh,610h,611h
The "Frame Frequency" table contains these values for frames 1-18;
50Hz,50Hz,50Hz,10Hz,10Hz,5Hz,5Hz,10Hz,10Hz,5Hz,5Hz,5Hz,5Hz,5Hz,50Hz50Hz,50Hz,50Hz
The "Frame Content" table contains these values for frames 1-18
This product is legal in California for racing vehicles only and should never be used on public
highways. AEM Performance Electronics, 2205 W. 126th Street Unit A, Hawthorne, CA 90250,
Life Racing ECUs to CD Dash
F42, F88, F90 & GDI Series ECU's
Phone: (310) 484-2322 Fax: (310) 484-0152
