Page 1: Installation Instructions
® Equipped with AEM Dryflow™ Filter No Oil Required! INSTALLATION INSTRUCTIONS PART NUMBER 21-794C (GUN METAL GRAY FINISH) 2014-15 Chevrolet Malibu 2.0T C.A.R.B E.O # D-670-24... - Page 2 ITEM NO. PART NUMBER DESCRIPTION QTY. 21-2157DK AIR FILTER 2-3/4" FLG, 5-1/2"B, 4-3/4T DRYFLOW HEAT SHIELD; CHEVROLET MALIBU 2.0L TURBO 20-8581 2014, MIL STL, TB/PC INTAKE TUBE; 2.75"OD X 8", 21-794, GUNMETAL 2-1572C GREY 5-227 COUPLER, 2.25/2.75"X3" 102470 EDGE TRIM; 3/4 BULB, 57"L 8-186-1 MOUNT, PLASTIC AIRBOX, NYLON 08160...
- Page 3 Read and understand these instructions BEFORE attempting to install this product. Failure to follow installation instructions and not using the provided hardware may damage the intake tube, throttle body and engine. If you need any assistance please call1-800-858-3333 to speak with a representative in our Customer Service Center before returning the product.
- Page 4 e. Pull up and remove the air box and tube assembly f. Engine compartment without factory air box assem- bly. from the engine compartment. The tube will slip off of the turbo after lifting up on air box. h. Loosen and remove the 15mm bolt on the engine g.
- Page 5 When installing the intake system, do not completely tighten the hose clamps or mounting hardware until instructed to do so. a. Install the MAF sensor into the AEM intake tube with b. Install the edge trims and mounting hardware on the the supplied M4 bolts.
- Page 6 e. Install the complete intake assembly into the engine f. Line up the tab on the heat shield and secure with the compartment. Line up the intake tube to the turbo hose 15mm bolt that was removed in step 2h. and push in the plastic stand-off into the grommet.
-
Page 7: Service And Maintenance
5. Service and Maintenance a. AEM Induction Systems requires cleaning the intake system’s air filter element every 100,000 miles. When used in dusty or off-road environments, our filters will require cleaning more often. We recommend that you visually inspect your filter once every 25,000 miles to determine if the screen is still visible. - Page 8 The powder coating should ® only be cleaned with a mild soap and water solution. Proof of purchase of both the vehicle and AEM intake system is required for redemption of a warranty claim.
