Page 1: Installation Instructions
® Dryflow™ Filter Equipped with AEM No Oil Required! INSTALLATION INSTRUCTIONS PART NUMBER: 21-433 2005 MITSUBISHI Eclipse L4-2.4L SEE * NOTE 2000 – 2004 MITSUBISHI Eclipse L4-2.4L C.A.R.B. E.O. # D-670... -
Page 2: Parts List
PARTS LIST Description Qty. Part Number Air Filter Assy. 2.75 X 5" Dry Ele. 21-202DK Upper Pipe 2-448 Lower Pipe 2-447 Adaptor, MAF 2-606 Hose; 3/8"ID X 6.5"L 5-10065 Nut, M6 Hex Serrated 444.460.04 Washer, 6mm Soft Mount 559999 Mount, Rubber 1" X 6mm 1228599 Bolt, Hex M6 X 1.0 X 16mm 1-2030... - Page 3 Read and understand these instructions BEFORE attempting to install this product. Failure to follow installation instructions and not using the provided hardware may damage the intake tube, throttle body and engine. 1. Preparing Vehicle a. Make sure vehicle is parked on level surface. b.
- Page 4 c. Unplug the MAF sensor. Remove stock inlet pipe. d. Loosen the four nuts that hold the MAF sensor to Release four clamps on the air box and remove the air box. Carefully set aside the MAF sensor. upper air box from the vehicle. e.
- Page 5 ® 3. Installation of AEM intake system. a. When installing the intake system, do not completely tighten the hose clamps or mounting hardware until instructed to do so. Size 52 clamp b. Attach MAF adapter to MAF sensor using the c.
- Page 6 f. Install the supplied breather hose as shown. g. Attach the bracket on the upper pipe to engine Secure both ends with supplied ¾” hose clamps. using the supplied 6mm bolt and washer. Place the pipe’s tab behind the stock plastic tab. Also attach the MAF sensor to pipe utilizing the rubber adapter as shown.
-
Page 7: Service And Maintenance
Use AEM Dryflow cleaning kit part # 21-110. b. Use aluminum polish to clean your polished AEM intake tube. c. Use window cleaner to clean your powder coated AEM intake tube. (NOTE: DO NOT USE aluminum polish on powder coated AEM intake tubes) - Page 8 The powder coating should only be cleaned with a mild soap and water solution. Proof of purchase of both the vehicle and AEM intake system is required for redemption of a warranty claim.
