NAVIGATION AND
COMMUNICATION
NAVIGATION BACKUP PAGE
NOTE: - Navigation information presented on the Navigation Backup
Page is operationally identical to that normally presented on
the PFD.
- The compass card is presented only in arc partial format.
- The selected course and the DME distance to station are
boxed.
- NAV and ADF active frequencies are also presented.
1 - ACTIVE NAV FREQUENCY
2 - BEARING 1 POINTER
3 - BEARING 2 POINTER
4 - ACTIVE ADF FREQUENCY
5 - COURSE DEVIATION BAR
6 - COURSE DEVIATION SCALE
7 - DME DISTANCE TO STATION
8 - MARKER BEACON DISPLAY
9 - SELECTED COURSE
10 - BEARING 2 SOURCE ANNUNCIATION
11 - BEARING 1 SOURCE ANNUNCIATION
12 - COMPASS CARD DISPLAY
