3 - MODE SELECT BUTTONS
NAV - Displays the navigation function pages. This mode
normally contains two pages, but when another NAV
mode is selected there are two or more pages available
by pressing the PREV or NEXT button.
DTO - Displays the DTO (Direct to) function.
FPL - Displays the Flight Plan pages or stored arrivals and
routes.
VNAV - Provides access to the VNAV function.
LIST - Provides a list of options appropriated to input data.
MENU - Displays a list of alternate formats or options for FUEL,
FPL, or TUNE.
PERF - Displays Performance pages. The first page PERF 1/1
provides a synopsis of pertinent in-flight performance
information.
DATA - Provides information concerning the FMS, NAV Data
Base and operating attached sensors, as well as their
status.
FUEL - Displays all fuel management functions.
TUNE - Provides access to the TUNE function.
4 - FUNCTION BUTTONS
MSG - Displays the activated message when the MSG
annunciation appears on display.
PWR DIM- Turns on and off the FMS and provides the dimming
function.
PREV - Changes the current page to the previous page.
NEXT - Changes the current page to the next page.
BACK - Deletes an alphanumeric entry, if over it, and serves as
backspace function.
ENTER - Stores input data each time it is pressed. It is required
for all data entries.
5 - ALPHANUMERIC BUTTONS
Consist of alphabet letters, the numbers 0 through 9 and a +/-
button. They are used to enter inputs to the FMS.
