NAVIGATION AND
COMMUNICATION
COMPARISON MONITORS
1 - ATTITUDE COMPARISON MONITOR DISPLAY
− Label: ROL, PIT or ATT.
− Color: Amber.
− If roll information deviates by more than 6 degrees between
PFD 1 and PFD 2, a ROL comparison monitor will be displayed
inside the attitude sphere.
− If pitch information deviates by more than 5 degrees between
PFD 1 and PFD 2, a PIT comparison monitor will be displayed in
the upper-left portion of the attitude sphere.
Simultaneous activation of the both pitch and roll comparison
monitors will be announced by an ATT label displayed in the
upper-left portion of the attitude sphere, in the same field of the
ROL and PIT comparison monitors.
2 - ATTITUDE FAILURE DISPLAY
− Removal of the pitch scale and roll pointer.
− Coloring the attitude sphere all blue.
− A red ATT FAIL label is displayed on the top center of the
attitude sphere.
3 - ATTITUDE SOURCE ANNUNCIATION
− Label: ATT1 for AHRS 1 and ATT2 for AHRS 2.
− Color: Amber when one AHRS supplies both sides or both
AHRS are supplying cross-side.
− Annunciations are removed when both AHRS are supplying on-
side PFDs.
4 - HEADING SOURCE ANNUNCIATION
− Label:
− MAG1 or MAG2 when AHRS heading source is magnetic.
− DG1 or DG2 when AHRS heading source is the directional
gyro.
− Color:
– For MAG: amber when the same AHRS is supplying both
Page
22
2-18-30
AIRPLANE
OPERATIONS
MANUAL
sides or both AHRS are supplying cross-side.
Code
01
MARCH 30, 2001
