NAVIGATION AND
COMMUNICATION
MFD BEZEL PANEL
1 - WEATHER RADAR DISPLAY SELECTOR BUTTON
− Alternate pressing of the weather radar display selector button
allows the weather radar to be displayed or removed from the
MFD. Control of all other weather radar functions is
accomplished by the radar control panel. When the weather
radar is selected, the WX label on the MFD menu, above this
button, will be highlighted by a white box.
− The weather radar can only be selected for display in map
format. If the weather radar is selected with plan format already
selected on the MFD, it will force the display to revert to map
format.
2 - MAP/PLAN FORMATS CONTROL BUTTON
− Alternate pressing of the map/plan formats control button will
cause the MFD to toggle between map and plan formats. A
white box around will highlight the selected MFD format.
− If the weather radar is displayed on the MFD and the plan
format is selected, the weather radar will be removed from the
display. However, if the MFD map format is selected again, the
weather radar display will be restored on the MFD.
