NAVIGATION AND
COMMUNICATION
JOYSTICK MENU BUTTONS FUNCTION AT MAP MODE
− SKIP ("SKP") button: Skips the designator to the position of the next
waypoint in the flight plan in case of the designator is co-located
with a plan waypoint. Otherwise, the designator broken line tail
skips to the next waypoint in the flight plan.
− RECALL ("RCL") button: Positions the designator at the present
position of the airplane and removes the designator box from the
display in case of the designator is co-located with the flight plan
waypoint. Otherwise, the designator is positioned over the waypoint
from which the designator line is extended and the designator line is
removed from the display.
− ENTER ("ENT") button: The latitude and longitude coordinates of
the designator are transmitted to the selected FMS scratchpad as a
requested waypoint.
JOYSTICK MENU BUTTONS FUNCTION AT PLAN MODE
− SKIP ("SKP") button: Positions the flight plan so the next waypoint
is displayed over the designator in case of the designator is co-
located with a flight plan waypoint. Otherwise, skips the tail of the
designator line to the next waypoint in the flight plan.
− RECALL ("RCL") button: Positions the designator at the present
position of the airplane and removes the designator box from the
display in case of the designator is co-located with a flight plan
waypoint. Otherwise, it positions the designator over the waypoint
from which the designator line is extended and removes the
designator line from the display.
− ENTER ("ENT") button: The latitude and longitude coordinates of
the designator are transmitted to the selected FMS scratchpad as a
requested waypoint.
