- Page 1 NOTE: Parts are no longer available for this tool. The manual will continue on the next page.
- Page 2 Form No. A1041C Date 12-91 INSTRUCTIONS & PARTS LIST FOR 1449HPG DRILL (SERIAL C) AIR SUPPLY The efficiency and life of this tool depend on the proper supply of clean, dry, lubricated air at about 90 lbs. P.S.I., although higher or lower pressures may be used. The use of an air line filter, pressure regulator and lubricator is recommended.
- Page 4 PARTS LIST FOR 1449HPG 3/8" DRILL NON-REV 350 R.P.M. (SERIAL C) Fig- Part Fig- Part Name Name 21133 Chuck (1/16"—3/8" Cap) 63359 Ass’y—Trigger 64003 Case—Gear 11600 Body—Valve 30375 Fitting—Grease 54222 Valve 63390 Ass’y—Planetary Reduction 54968 Retainer—Exhaust 19266 Gear—Ri n g 54955 Adaptor—Inlet...
- Page 5 REMOVE ADJUSTING KEYS AND WRENCHES: Form habit of checking to see that keys and adjusting wrenches are removed form tool before turning it on. CAUTION: The use of an accessory with this tool not provided or specified by SIOUX TOOLS may be hazardous. Printed in U.S.A.
- Page 6 This pdf incorporates the following model numbers: 1449HPG...
