INSTRUCTIONS AND PARTS LIST FOR 1453ES DRILL
Read and understand "Safety Instructions For Air Tools" and these instructions before
AIR SUPPLY
The efficiency of the tool is dependent on the proper supply of clean dry air at 90 psig (6.2 bar). The use of a line filter,
pressure regulator, and lubricator will insure maximum output and life of tools. Before connecting tool, blow out the air line
to remove water and dirt which may have accumulated.
HOSE AND HOSE CONNECTIONS
Supply hose should be not less than 3/8" (10mm) I.D. Extension hoses should be at least 1/2" (13mm) I.D. Use couplings
and fittings with at least 3/8" (10mm) I.D.
LUBRICATION
Use SIOUX No. 288 air motor oil. An airline lubricator, set to deliver 2 to 4 drops per minute, is recommended. If a lubricator
is not used, add .04 oz. (1.2cc, 12 to 15 drops) of oil into the air inlet twice daily.
Lubricate the gearing every 100 hours of operation with SIOUX No. 289A grease.
GENERAL OPERATION
This tool is equipped with a teasing throttle. By slightly depressing the trigger the chuck will rotate slowly. This is useful for
starting a drill bit without first spotting with a punch. The tool will run at maximum speed when the trigger is fully depressed.
If the gear case is removed or loosened, re-tighten to 35 ft-Ib.
We, Sioux Tools Inc., 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, declare under our sole responsibility that the products
to which this declaration relates are in conformity with the following standard or standards or other normative document or documents:
July 1, 2003
Murphy, North Carolina, USA
Date and place of issues
(SERIAL "A")
operating this tool.
SOUND AND VIBRATION READINGS
*Sound Pressure
Catalog No.
dBA
1453ES
78.0
*per PN8NTC1
DECLARATION OF CONFORMITY
1453ES
EN 792 (draft), EN 292 Parts 1&2, ISO 8662, Pneurop PN8NTC1
following the provisions of
89/392/EEC as amended by 91/368/EEC & 93/44/EC Directives.
Gerald E. Seebeck
President
Sioux Tools Inc.
Name and position of issuer
*Sound Power
*Vibration
dBA
m/s
2
90.0
Less than 2.5
*per PN8NTC1
*per ISO 8662
1
Form ZCE562
Date 2003July21/C
Page 1 of 10
Signature of issuer
Printed In U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1453ES and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sioux Tools 1453ES

Summary of Contents for Sioux Tools 1453ES

  • Page 1 *per ISO 8662 DECLARATION OF CONFORMITY We, Sioux Tools Inc., 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, declare under our sole responsibility that the products 1453ES to which this declaration relates are in conformity with the following standard or standards or other normative document or documents: EN 792 (draft), EN 292 Parts 1&2, ISO 8662, Pneurop PN8NTC1...

  • Page 2: Allgemeiner Betrieb

    *per ISO 8662 KONFORMITÄTSERKLÄRUNG Wir, Sioux Tools, Inc., 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, erklären hiermit alleinverantwortlich, daß die Produkte 1453ES auf die sich diese Erklärung bezieht, mit den Anforderungen der folgenden Standards oder Normen oder Dokumenten übereinstimmen: EN 792 (Entwurf) EN 292 Teile 1&2, ISO 8662, Pneurop PN8NTC1...

  • Page 3: Suministro De Aire

    PN8NTC1 ISO 8662 DECLARACION DE CONFORMIDAD Nosotros, Sioux Tools, Inc., 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, declaramos bajo nuestra única responsabilidad que los productos 1453ES con los cuales se relaciona esta Declaración están en conformidad con las siguientes norma(s), u otros documento(s) normativos:...
  • Page 4 PN8NTC1 ISO 8662 DICHIARAZIONE DI CONFORMITA’ La Sioux Tools, Inc, con sede al 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, solennemente dichiara sotto la propria e sola responsabilità che i prodotti 1453ES ai quali la presente dichiarazione si riferisce sono conformi ai requisiti delle seguenti normative e direttive:...

  • Page 5: Alimentation En Air

    ISO 8662 DÉCLARATION DE CONFORMITÉ La société Sioux Tools, Inc., située à : 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, affirme que les produits 1453ES visés par cette déclaration sont conformes aux normes ou aux documents normatifs suivants : EN 792 (version préliminaire), EN 292 Parties 1 et 2, ISO 8662, PNEUROP PN8NTC1...
  • Page 6 PN8NTC1 ISO 8662 CONFORMITEITSVERKLARING Ondergetekende, Sioux Tools, Inc., 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, verklaart met inachtneming van de eigen aansprakelijkheid desbetreffend, dat de produkten 1453ES producten waarop deze verklaring van toepassing is, conform zijn met de hierna genoemde norm, normen en/of andere regels en voorschriften: EN 792 (voorstel), EN 292 onderdelen 1&2, ISO 8662, Pneurop PN8NTC1...
  • Page 7 PN8NTC1 ISO 8662 FÖRSÄKRAN OM ÖVERENSSTÄMMELSE Vi, Sioux Tools, Inc., 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, förklarar under eget ansvar att produkterna 1453ES som denna försäkran gäller uppfyller följande standard eller standarder eller andra normgivande dokument:...

  • Page 8: Complete Assembly

    PARTS LIST FOR 1453ES DRILL (SERIAL “A”) *Order Quantity As Needed FURNISH CATALOG, SERIAL, AND MODEL NUMBER WHEN ORDERING PARTS Fig. Part Fig. Part Description Description 2352 Ass’y—1/4" Hex Quick Change Adapter 64057 Cylinder 21077 Chuck (0-1/4" Cap)(3/8” Thread) 67855 Rotor—6 Tooth 21133 Chuck (1/16"-3/8"...
  • Page 9 NOTES...
  • Page 10 Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to cause cancer, birth defects or other reproductive harm. Der durch Elektrosanden, -sägen, -schleifen und -bohren sowie durch andere Bauarbeiten anfallende Staub enthält Chemikalien, die nachweislich Krebs sowie Geburts- bzw. andere Fortpflanzungsschäden hervorrufen.
