SpectraMax M3, M4, M5, and M5e Microplate Reader User Guide
Connecting Instrument Cables
The power cord and USB cable connect to the ports on the rear of the instrument.
Part Number
1-2100-0548
4400-0002
To connect the instrument cables:
1. Turn the instrument around so that the rear of the instrument faces you.
2. Make sure that the power switch is in the Off position.
3. Connect the appropriate end of the supplied USB cable to the USB port, and then
connect the other end to a USB port on the computer.
4. Connect the supplied power adapter to the power cord port, and then connect the other
end to a grounded electrical wall outlet.
5. Turn the instrument around so that the front of the instrument faces you.
14
Description
USB computer connection cable, 3 meter (9.8 foot)
Power cord, 1 meter (3.3 foot) See
power cord part numbers.
Note: Before you connect or disconnect the power cord, make sure that the power
switch that is on the rear of the instrument is in the Off position.
Note: Ensure no cables run beneath the instrument.
Accessories on page 57
for international
0112-0115 G
