Pressure Adjust HT/WT Method

Use HT/WT pre-set method to set an appropriate air pressure based on patient's height and
weight. HT/WT pre-sets can be adjusted from 0.6 m (2 ft 0 in) to 2 m (6 ft 8 in) by 2.54 cm (1-inch) increments and from
22 kg (50 lb) to 136 kg (300 lb) by 2 kg (5 lb) increments.
1. Press left arrow button under HT/WT. The display shown at right will appear.
• Press left arrow button under DECR to decrease height.
• Press right arrow button under INCR to increase height.
• Press center oval button under ENTER to enter selected height.
Display shown at right will appear.
• Press left arrow button under DECR to decrease weight.
• Press right arrow button under INCR to increase weight.
• Press center oval button under ENTER to enter selected weight.
• Press center oval under EXIT to return to Home Display.

Air Pressure Adjustment

Each therapeutic surface is constructed with three sections: HEAD, BODY, and LEG which can be independently
adjusted to meet patient needs.
Use Pressure Adjust button to adjust pressure in each individual section of therapeutic surface. Air pressures are set by
using either HT/WT pre-set or manual method.
1. Press PRESSURE ADJUST button shown at right.
2. Display shown at right will appear.

Pressure Adjust Manual Method

Use manual method to make major adjustments in existing pressures.
1. With Pressure Adjust display showing, press right arrow button under MANUAL.
Display shown at right will appear.
• Press left arrow button to decrease head section pressure.
• Press right arrow button to increase head section pressure.
• Press center oval button to enter selected head section pressure. Display shown
at right will appear.
• Press left arrow button to decrease body section pressure.
• Press right arrow button to increase body section pressure
• Press center oval button to enter selected body section pressure. Display shown
at right will appear.
• Press left arrow button to decrease leg section pressure.
• Press right arrow button to increase leg section pressure.
• Press center oval button to enter selected leg section pressure. Display shown at right will appear.
• Press center oval button under EXIT to return to Home Display.
i
If HT/WT display is accessed after adjustments have been made using MANUAL,
the MANUAL pressures will automatically be replaced with previous HT/WT
pressures.
PRESSURE ADJUST
HT/WT EXIT MANUAL
HEAD SECTION ADJUST
BODY SECTION ADJUST
PRESSURE ADJUST
HT/WT EXIT
MANUAL
15
